Arista EVPN Routes Missing

Symptoms

You pull up

show bgp evpn

and the route table is sparse — or completely empty. Remote hosts aren't reachable across the fabric. Maybe the MAC/IP routes from a remote VTEP never showed up. Maybe the Type-5 IP prefix routes are missing from the L3 VRF. The underlay BGP sessions look fine, pings to loopbacks work, but the overlay is dark.

I've seen this surface in several ways depending on how far the control plane got before failing:

• show vxlan address-table

  shows only local MACs — no remote entries at all
• Traffic between VTEPs drops silently with no ICMP unreachable, just black holes

• show bgp evpn route-type mac-ip

  returns nothing for a VNI that should have remote learnings
• Type-2 or Type-5 routes appear in

  show bgp evpn

  but aren't installed in the RIB or hardware table

The frustrating part about EVPN troubleshooting is that BGP sessions can look perfectly healthy — all neighbors established, prefixes counted — and the overlay still doesn't work. Route targets, VNIs, RDs, and EVPN address family activation all have to line up exactly. Miss one piece and you get silence.

Let me walk through the causes I hit most often, in roughly the order I check them.

---

Root Cause 1: BGP EVPN Not Enabled

Why It Happens

BGP EVPN requires explicit activation of the L2VPN EVPN address family on each neighbor. A BGP session established for the underlay (IPv4 unicast) carries zero EVPN NLRIs unless you explicitly activate it. If the EVPN address family isn't turned on, the BGP session exists and looks healthy, but no EVPN routes are ever exchanged. This catches people who set up the underlay, confirm BGP is up, and assume EVPN is running when it isn't.

How to Identify It

Run

show bgp evpn summary

and compare it against

show bgp summary

. If a neighbor shows

Established

in the IPv4 table but

Idle

or

Active

in the EVPN table, the address family isn't activated.

sw-infrarunbook-01# show bgp evpn summary
BGP summary information for VRF default
Router identifier 10.0.0.1, local AS number 65001
Neighbor Status Codes: m - Under maintenance
  Description              Neighbor V AS           MsgRcvd   MsgSent  InQ OutQ  Up/Down State   PfxRcd PfxAcc
  sw-infrarunbook-02       10.0.0.2 4 65002              0         0    0    0 00:05:23 Idle         0      0

Then look at the BGP config to confirm the EVPN address family stanza is absent:

sw-infrarunbook-01# show running-config section router bgp
router bgp 65001
   router-id 10.0.0.1
   neighbor 10.0.0.2 remote-as 65002
   !
   address-family ipv4
      neighbor 10.0.0.2 activate

No

address-family evpn

block. That's the problem right there.

How to Fix It

Activate the EVPN address family on the neighbor and make sure extended communities are being sent — EVPN route targets ride as BGP extended communities, and without that knob they get stripped in transit.

sw-infrarunbook-01(config)# router bgp 65001
sw-infrarunbook-01(config-router-bgp)# neighbor 10.0.0.2 send-community extended
sw-infrarunbook-01(config-router-bgp)# address-family evpn
sw-infrarunbook-01(config-router-bgp-af)# neighbor 10.0.0.2 activate

After committing, confirm the session comes up and prefixes begin flowing:

sw-infrarunbook-01# show bgp evpn summary
  Description              Neighbor V AS           MsgRcvd   MsgSent  InQ OutQ  Up/Down State   PfxRcd PfxAcc
  sw-infrarunbook-02       10.0.0.2 4 65002            142       138    0    0 00:01:04 Estab        24     24

In my experience, using a BGP peer group for all VTEP neighbors makes this consistent. Define the peer group once with

send-community extended

and EVPN activated, and every new VTEP you add inherits it automatically.

---

Root Cause 2: Route Target Mismatch

Why It Happens

EVPN uses BGP extended communities called route targets to control which routes get imported into which VRFs and VNIs. The export RT on the sending VTEP must match the import RT on the receiving VTEP. If they don't match, routes get advertised and received correctly at the BGP level — but they're never imported. They sit in the BGP table marked as not best or rejected by import policy. This is the most common cause I encounter in manually configured fabrics or environments that evolved over time from multiple engineers touching the config.

How to Identify It

Compare the EVPN instance configuration on each VTEP side by side:

sw-infrarunbook-01# show bgp evpn instance vlan 10
EVPN instance: VLAN 10
  Route distinguisher: 10.0.0.1:10010
  Route target import: Route-Target-AS:65001:10010
  Route target export: Route-Target-AS:65001:10010
  Service interface: VLAN-based
  Local VXLAN IP address: 10.0.0.1
  VNI: 10010

sw-infrarunbook-02# show bgp evpn instance vlan 10
EVPN instance: VLAN 10
  Route distinguisher: 10.0.0.2:10010
  Route target import: Route-Target-AS:65001:1010
  Route target export: Route-Target-AS:65001:1010

sw-infrarunbook-01 exports

65001:10010

but sw-infrarunbook-02 is only importing

65001:1010

— a transposition. They'll never match. You can confirm by looking at the detailed route entry on the receiving side:

sw-infrarunbook-02# show bgp evpn route-type mac-ip detail
BGP routing table entry for mac-ip 10010 5000.0003.0001, Route Distinguisher: 10.0.0.1:10010
  Paths: 1 available
  Path from: 10.0.0.1 (65001)
    Extended community: Route-Target-AS:65001:10010 TunnelEncap:tunnelTypeVxlan
    Not selected: extended community not matching import policy

That

Not selected: extended community not matching import policy

line is the definitive tell.

How to Fix It

Align the route targets across the fabric. On Arista, this is set under the per-VLAN BGP EVPN stanza:

sw-infrarunbook-02(config)# router bgp 65002
sw-infrarunbook-02(config-router-bgp)# vlan 10
sw-infrarunbook-02(config-macvrf-10)# route-target both 65001:10010

For VRF-based Type-5 routing, fix it under the VRF:

sw-infrarunbook-02(config-router-bgp)# vrf PROD
sw-infrarunbook-02(config-router-bgp-vrf)# route-target import evpn 65001:50000
sw-infrarunbook-02(config-router-bgp-vrf)# route-target export evpn 65001:50000

After the fix,

show bgp evpn route-type mac-ip

should show routes moving from

not best

to

valid, active

.

---

Root Cause 3: VNI Not Advertised

Why It Happens

Even with BGP EVPN activated and route targets aligned, a VLAN's MAC/IP routes won't be advertised unless the VLAN is explicitly included in the BGP EVPN process. On Arista, this means the VLAN needs a

vlan <id>

stanza under

router bgp

(or membership in a vlan-aware-bundle) with

redistribute learned

configured. If that stanza is missing, the switch learns MACs on that VLAN locally but never puts them into BGP. From the perspective of the rest of the fabric, that VLAN is silent.

How to Identify It

Start by verifying the VXLAN VNI mapping exists on the interface:

sw-infrarunbook-01# show vxlan vni
VNI to VLAN Mapping for Vxlan1
VNI        VLAN       Source       Interface       802.1Q Tag
---------- ---------- ------------ --------------- ----------
10010      10         static       Ethernet5       untagged
                                   Vxlan1          10

The VNI-to-VLAN mapping exists. Now check whether BGP knows about it:

sw-infrarunbook-01# show bgp evpn instance
EVPN instance: VLAN 20
  Route distinguisher: 10.0.0.1:10020
  Route target import: Route-Target-AS:65001:10020
  Route target export: Route-Target-AS:65001:10020
  VNI: 10020
EVPN instance: VLAN 30
  Route distinguisher: 10.0.0.1:10030
  ...

VLAN 10 is completely absent from the EVPN instance list despite having a VNI mapping. Check the BGP running config:

sw-infrarunbook-01# show running-config section router bgp
router bgp 65001
   vlan-aware-bundle PROD
      vlan 20-30
      route-target both 65001:20000
      redistribute learned

VLAN 10 isn't in any bundle or standalone stanza. The VNI is mapped at the interface level but BGP has no instructions to advertise it.

How to Fix It

Add the VLAN to the BGP EVPN configuration. If you're using per-VLAN mode:

sw-infrarunbook-01(config)# router bgp 65001
sw-infrarunbook-01(config-router-bgp)# vlan 10
sw-infrarunbook-01(config-macvrf-10)# rd 10.0.0.1:10010
sw-infrarunbook-01(config-macvrf-10)# route-target both 65001:10010
sw-infrarunbook-01(config-macvrf-10)# redistribute learned

If you're using vlan-aware-bundle, add the VLAN to the existing bundle:

sw-infrarunbook-01(config-router-bgp)# vlan-aware-bundle PROD
sw-infrarunbook-01(config-macvrf-PROD)# vlan add 10

Verify routes begin propagating within a few seconds:

sw-infrarunbook-01# show bgp evpn route-type mac-ip vni 10010
          Network                Next Hop              Metric  LocPref Weight  Path
 * >      RD: 10.0.0.1:10010 mac-ip 5000.0003.0001
                                 -                     -       -       0       i
 * >      RD: 10.0.0.2:10010 mac-ip 5000.0004.0001
                                 10.0.0.2              -       100     0       65002 i

---

Root Cause 4: MAC Mobility Issue

Why It Happens

EVPN Type-2 routes carry a MAC mobility extended community that includes a sequence number. This is the mechanism EVPN uses to handle host moves — when a host migrates from one VTEP to another, the new VTEP advertises the MAC with a higher sequence number and all other VTEPs should prefer it and withdraw the stale remote entry. Problems arise when a MAC is being actively learned at two different VTEPs simultaneously — either because of a loop, a misconfigured dual-homing setup, or a VM migration where the hypervisor brought up the new instance before the old NIC went fully silent. When VTEPs see conflicting advertisements with equal sequence numbers, some routes end up stuck or oscillating.

How to Identify It

Look at the MAC mobility sequence numbers in the detailed EVPN route output:

sw-infrarunbook-01# show bgp evpn route-type mac-ip detail
BGP routing table entry for mac-ip 10010 5000.0005.0001 10.1.10.50, Route Distinguisher: 10.0.0.1:10010
  Paths: 2 available
  Path from: 10.0.0.1 (65001)
    Extended community: Route-Target-AS:65001:10010 TunnelEncap:tunnelTypeVxlan EvpnMacMobility:Seq:5
    Origin IGP, valid, redistributed, best, ECMP head
  Path from: 10.0.0.2 (65002)
    Extended community: Route-Target-AS:65001:10010 TunnelEncap:tunnelTypeVxlan EvpnMacMobility:Seq:3
    Origin IGP, valid, not best

Here sw-infrarunbook-01 holds seq 5 and sw-infrarunbook-02 holds seq 3, so sw-infrarunbook-01 wins — that's correct behavior after a move. But if you see both VTEPs advertising the same sequence number, or if syslog shows the mobility conflict message repeating rapidly, you have a genuine conflict:

sw-infrarunbook-01# show logging | grep "5000.0005.0001"
Apr 14 22:01:03 sw-infrarunbook-01 Bgp: %BGP-5-NOTIFICATION: MAC mobility conflict for MAC 5000.0005.0001 VNI 10010, seq 7 from 10.0.0.2 equals local seq 7
Apr 14 22:01:04 sw-infrarunbook-01 Bgp: %BGP-5-NOTIFICATION: MAC mobility conflict for MAC 5000.0005.0001 VNI 10010, seq 7 from 10.0.0.2 equals local seq 7

Rapid repetition of that log line means the MAC is actively oscillating between two VTEPs without either winning.

How to Fix It

First, track down where the MAC is physically learned. On each VTEP involved:

sw-infrarunbook-01# show mac address-table address 5000.0005.0001
          MAC Address    Type    Vlan  Interface
     5000.0005.0001   Dynamic    10    Ethernet3

If the same MAC is showing as locally learned on two different VTEPs simultaneously, you have a loop or a dual-active forwarding problem — not a control plane issue. Trace the physical topology and confirm the host has a single active uplink or is properly using MLAG with a consistent ESI. If the host genuinely migrated and the old VTEP just hasn't timed out yet, flush it manually:

sw-infrarunbook-02(config)# clear mac address-table dynamic address 5000.0005.0001

For MLAG-based dual-homing, both MLAG peers should advertise under a shared MLAG VTEP IP rather than their individual loopbacks. Advertising from two separate VTEP IPs with different RDs for the same MAC is what triggers the mobility conflict in the first place. Confirm the MLAG shared IP is configured under

interface Vxlan1

:

sw-infrarunbook-01# show running-config section interface Vxlan1
interface Vxlan1
   vxlan source-interface Loopback0
   vxlan virtual-router encapsulation mac-address mlag-system-id
   vxlan udp-port 4789
   vxlan vlan 10 vni 10010
   vxlan mlag vtep source-interface Loopback1

The

vxlan mlag vtep source-interface Loopback1

line tells the switch to use the MLAG shared loopback (Loopback1) for VTEP advertisements, ensuring both peers appear as a single VTEP to the rest of the fabric.

---

Root Cause 5: RD Conflict

Why It Happens

The Route Distinguisher makes EVPN routes globally unique within the BGP control plane. Arista auto-generates RDs in the format

<loopback-ip>:<vni>

or

<loopback-ip>:<vlan-id>

based on the switch's Loopback0 address. If two VTEPs share the same loopback IP — which I've seen happen when switches are cloned from a golden config template and someone forgets to update the loopback — their auto-generated RDs will be identical. BGP then treats routes from both VTEPs as if they came from the same source. One set of routes overwrites the other, or a route reflector starts rejecting duplicates, and you get sporadic or total loss of EVPN routes from one VTEP.

How to Identify It

In

show bgp evpn route-type mac-ip detail

, look at which RDs are present and which BGP peer they originated from:

sw-infrarunbook-01# show bgp evpn route-type mac-ip detail
BGP routing table entry for mac-ip 10010 5000.0006.0001, Route Distinguisher: 10.0.0.1:10010
  Paths: 1 available
  Path from: 10.0.0.2 (65002)
    Route Distinguisher: 10.0.0.1:10010
    Extended community: Route-Target-AS:65001:10010 TunnelEncap:tunnelTypeVxlan

The path arrived from peer 10.0.0.2 (sw-infrarunbook-02 based on its BGP router-id) but is carrying RD

10.0.0.1:10010

. That's the collision — sw-infrarunbook-02 is generating RDs as if its loopback is 10.0.0.1. Confirm by SSHing to the offending switch:

sw-infrarunbook-02# show interfaces Loopback0
Loopback0 is up, line protocol is up (connected)
  Hardware is Loopback
  Internet address is 10.0.0.1/32

Duplicate loopback. The cloned config was never updated.

How to Fix It

Assign the correct unique loopback to sw-infrarunbook-02 and update the BGP router-id to match:

sw-infrarunbook-02(config)# interface Loopback0
sw-infrarunbook-02(config-if-Lo0)# ip address 10.0.0.2/32
sw-infrarunbook-02(config)# router bgp 65002
sw-infrarunbook-02(config-router-bgp)# router-id 10.0.0.2

If RDs were manually configured rather than auto-generated, update each one:

sw-infrarunbook-02(config-router-bgp)# vlan 10
sw-infrarunbook-02(config-macvrf-10)# rd 10.0.0.2:10010

Then reset the EVPN sessions to force RD re-advertisement with the corrected values:

sw-infrarunbook-02# clear bgp evpn all

After recovery, verify the RDs are now unique across the fabric:

sw-infrarunbook-01# show bgp evpn route-type mac-ip detail | grep "Route Distinguisher"
  BGP routing table entry for mac-ip 10010 5000.0006.0001, Route Distinguisher: 10.0.0.1:10010
  BGP routing table entry for mac-ip 10010 5000.0007.0001, Route Distinguisher: 10.0.0.2:10010

Each VTEP now owns a distinct RD namespace. Routes from both VTEPs coexist cleanly in the BGP table.

---

Root Cause 6: VTEP Underlay Reachability

Why It Happens

This one is subtle because it looks like a control plane success but a data plane failure. EVPN routes can be correctly exchanged in BGP, show as best, and even get installed in the RIB — but traffic still black-holes if the VTEP loopback addresses aren't reachable via the underlay IGP or BGP. VXLAN encapsulation requires actual IP reachability between VTEP source IPs. If the underlay isn't advertising a VTEP's loopback, the remote VTEP tunnel destination is unreachable and the route doesn't get programmed into the forwarding ASIC even if it looks fine in software.

How to Identify It

sw-infrarunbook-01# show vxlan vtep
Remote VTEPS for Vxlan1:

VTEP            Tunnel Type(s)
--------------- --------------

Empty VTEP table despite having EVPN routes is the signature. Confirm the underlay has a gap:

sw-infrarunbook-01# show ip route 10.0.0.2
% Network not in table

Fix the underlay routing protocol to ensure all loopbacks are reachable before troubleshooting the EVPN overlay further. These two layers must be solved independently and in order — underlay first, overlay second.

---

Prevention

Most of these problems share a common thread: they're configuration inconsistencies that slip in during manual provisioning. The best prevention is reducing the surface area where humans can introduce those inconsistencies.

Automate RD and RT assignment. Don't let engineers manually type route distinguishers and route targets during provisioning. Build a consistent scheme —

<loopback>:<vni>

for RDs,

<ASN>:<vni>

for RTs — into your configuration templates and enforce it through CVP (CloudVision Portal) or a provisioning pipeline. Manually entered values are where typos and duplicates live.

Use BGP peer groups for EVPN neighbors. Define a single peer group that has

send-community extended

and EVPN address family activation baked in. Every new VTEP added to that group inherits the correct EVPN config automatically, rather than depending on someone remembering to configure four separate lines.

sw-infrarunbook-01(config)# router bgp 65001
sw-infrarunbook-01(config-router-bgp)# peer group VTEP-PEERS
sw-infrarunbook-01(config-router-bgp)# neighbor VTEP-PEERS send-community extended
sw-infrarunbook-01(config-router-bgp)# address-family evpn
sw-infrarunbook-01(config-router-bgp-af)# neighbor VTEP-PEERS activate

Validate loopback uniqueness before deploying. Before any EVPN config is applied to a new switch, confirm its Loopback0 is unique across the fabric and reachable from every existing VTEP. A simple pre-flight check — ping each VTEP loopback from the management network or via the underlay — catches duplicate IPs before they cause RD collisions. Starting EVPN configuration before the underlay is solid is a reliable way to end up chasing ghosts.

Monitor MAC mobility counters with telemetry. Set up streaming telemetry or periodic polling on MAC mobility sequence numbers. A MAC whose sequence number is incrementing rapidly is a host that's flapping between VTEPs — either a loop, a dual-active problem, or a hypervisor bug. Catching this early through monitoring prevents it from escalating into a fabric-wide forwarding incident.

Validate VNI changes in a staging environment first. Additions or modifications to VNI-to-VLAN mappings and route target changes can silently drop traffic on a production fabric if applied incorrectly. Arista's CloudVision change control workflow is genuinely useful here: it captures the config diff, stages the change, and can roll back automatically if health checks fail post-change. Don't push VNI config changes to production switches directly from a terminal window.

Make

show bgp evpn summary

,

show bgp evpn instance

, and

show vxlan vtep

your baseline trio. These three commands give you the full picture: whether the BGP EVPN control plane is active, whether EVPN instances are correctly defined, and whether the data-plane VTEP tunnels are resolving. Run them before and after any fabric change as a sanity check. If all three look right, you're in good shape. If any one of them is off, you know exactly which layer to dig into.
