Cisco BGP Configuration: Complete Run Book for eBGP and iBGP on IOS-XE (ASR/ISR)

Introduction

Border Gateway Protocol (BGP) is the routing protocol that holds the Internet together. Whether you are peering with upstream ISPs, connecting multiple data-centre sites over a private WAN, or building an MPLS backbone, BGP is the control plane you rely on. This run book provides complete, copy-paste-ready configurations for both external BGP (eBGP) and internal BGP (iBGP) on Cisco IOS-XE platforms — specifically the ASR 1000 series and ISR 4000 series — but the syntax applies to any IOS-XE device running 16.x or 17.x code.

We will walk through every building block: basic neighbour establishment, prefix-lists, route-maps, communities, local-preference, MED, AS-path prepending, route reflectors, soft reconfiguration, and operational verification. Every example uses the InfraRunBook lab topology so you can replicate it on real hardware or CML.

---

Lab Topology

The topology used throughout this guide consists of four routers:

• rtr-infrarunbook-01 — AS 65001, Loopback0: 10.255.0.1/32, border router peering eBGP with ISP
• rtr-infrarunbook-02 — AS 65001, Loopback0: 10.255.0.2/32, iBGP peer and route reflector client
• rtr-infrarunbook-03 — AS 65001, Loopback0: 10.255.0.3/32, iBGP peer and route reflector client
• rtr-infrarunbook-isp — AS 65002, simulated ISP peer at 203.0.113.1/30

Point-to-point links use 10.0.12.0/30, 10.0.13.0/30, and 10.0.23.0/30 subnets. OSPF area 0 provides the IGP underlay for iBGP next-hop reachability. The eBGP peering between rtr-infrarunbook-01 and rtr-infrarunbook-isp uses the 203.0.113.0/30 transit link.

---

1 — Prerequisites and IGP Underlay

Before BGP neighbours can form, iBGP peers need an IGP (OSPF, IS-IS, or static routes) to resolve each other's loopback addresses. We assume OSPF is already running per our OSPF Run Book. Verify reachability first:

! On rtr-infrarunbook-01
ping 10.255.0.2 source 10.255.0.1
ping 10.255.0.3 source 10.255.0.1

Both pings must succeed before proceeding. If they fail, check OSPF adjacencies with

show ip ospf neighbor

.

---

2 — Basic eBGP Configuration

2.1 — Establishing the eBGP Peer

! rtr-infrarunbook-01
router bgp 65001
 bgp router-id 10.255.0.1
 bgp log-neighbor-changes
 no bgp default ipv4-unicast
 !
 neighbor 203.0.113.1 remote-as 65002
 neighbor 203.0.113.1 description eBGP_to_infrarunbook-isp
 neighbor 203.0.113.1 password 7 InfraRunBook$ecure!
 neighbor 203.0.113.1 timers 10 30
 !
 address-family ipv4 unicast
  neighbor 203.0.113.1 activate
  neighbor 203.0.113.1 soft-reconfiguration inbound
  network 172.16.0.0 mask 255.255.0.0
  network 10.255.0.1 mask 255.255.255.255
 exit-address-family

2.2 — ISP Side (for lab simulation)

! rtr-infrarunbook-isp
router bgp 65002
 bgp router-id 203.0.113.1
 bgp log-neighbor-changes
 no bgp default ipv4-unicast
 !
 neighbor 203.0.113.2 remote-as 65001
 neighbor 203.0.113.2 description eBGP_to_infrarunbook-01
 neighbor 203.0.113.2 password 7 InfraRunBook$ecure!
 !
 address-family ipv4 unicast
  neighbor 203.0.113.2 activate
  neighbor 203.0.113.2 soft-reconfiguration inbound
  network 0.0.0.0
  network 203.0.113.0 mask 255.255.255.252
 exit-address-family

Key points:

• no bgp default ipv4-unicast

  prevents all neighbours from being auto-activated in IPv4 — best practice on IOS-XE.
• MD5 authentication protects the TCP session from spoofed RST attacks.
• Timers 10/30 are aggressive; production ISP peerings typically use 60/180 or BFD.

---

3 — Basic iBGP Configuration

3.1 — Full-Mesh iBGP (before Route Reflectors)

! rtr-infrarunbook-01
router bgp 65001
 neighbor 10.255.0.2 remote-as 65001
 neighbor 10.255.0.2 description iBGP_to_infrarunbook-02
 neighbor 10.255.0.2 update-source Loopback0
 neighbor 10.255.0.2 next-hop-self
 !
 neighbor 10.255.0.3 remote-as 65001
 neighbor 10.255.0.3 description iBGP_to_infrarunbook-03
 neighbor 10.255.0.3 update-source Loopback0
 neighbor 10.255.0.3 next-hop-self
 !
 address-family ipv4 unicast
  neighbor 10.255.0.2 activate
  neighbor 10.255.0.2 soft-reconfiguration inbound
  neighbor 10.255.0.3 activate
  neighbor 10.255.0.3 soft-reconfiguration inbound
 exit-address-family

! rtr-infrarunbook-02
router bgp 65001
 bgp router-id 10.255.0.2
 bgp log-neighbor-changes
 no bgp default ipv4-unicast
 !
 neighbor 10.255.0.1 remote-as 65001
 neighbor 10.255.0.1 description iBGP_to_infrarunbook-01
 neighbor 10.255.0.1 update-source Loopback0
 !
 neighbor 10.255.0.3 remote-as 65001
 neighbor 10.255.0.3 description iBGP_to_infrarunbook-03
 neighbor 10.255.0.3 update-source Loopback0
 !
 address-family ipv4 unicast
  neighbor 10.255.0.1 activate
  neighbor 10.255.0.1 soft-reconfiguration inbound
  neighbor 10.255.0.3 activate
  neighbor 10.255.0.3 soft-reconfiguration inbound
  network 172.16.10.0 mask 255.255.255.0
 exit-address-family

Repeat a similar config on rtr-infrarunbook-03 with appropriate neighbour statements to both 10.255.0.1 and 10.255.0.2.

Why

next-hop-self

? When rtr-infrarunbook-01 advertises routes learned from the ISP (next-hop 203.0.113.1) to iBGP peers, those peers have no route to 203.0.113.1.

next-hop-self

rewrites the next-hop to the advertising router's loopback, which is reachable via OSPF.

---

4 — Route Reflectors

Full-mesh iBGP does not scale. With N routers you need N×(N−1)/2 sessions. Route reflectors (RR) solve this. We designate rtr-infrarunbook-01 as the route reflector and the other two as clients.

! rtr-infrarunbook-01 — Route Reflector
router bgp 65001
 address-family ipv4 unicast
  neighbor 10.255.0.2 route-reflector-client
  neighbor 10.255.0.3 route-reflector-client
 exit-address-family

On the clients (rtr-infrarunbook-02 and rtr-infrarunbook-03), remove the iBGP neighbour statements to each other — they only peer with the route reflector now:

! rtr-infrarunbook-02 — RR Client
router bgp 65001
 no neighbor 10.255.0.3 remote-as 65001

! rtr-infrarunbook-03 — RR Client
router bgp 65001
 no neighbor 10.255.0.2 remote-as 65001

Best practice: Deploy two route reflectors for redundancy. Add a second RR (e.g., rtr-infrarunbook-04) and have each client peer with both.

---

5 — Prefix-Lists

Prefix-lists are the most efficient way to filter BGP routes. They match on prefix and prefix length.

5.1 — Permit Only Your Aggregates Outbound

ip prefix-list INFRARUNBOOK-OUT seq 10 permit 172.16.0.0/16
ip prefix-list INFRARUNBOOK-OUT seq 20 permit 10.255.0.0/24 le 32
ip prefix-list INFRARUNBOOK-OUT seq 100 deny 0.0.0.0/0 le 32

5.2 — Accept Default + Specific Prefixes Inbound

ip prefix-list INFRARUNBOOK-IN seq 10 permit 0.0.0.0/0
ip prefix-list INFRARUNBOOK-IN seq 20 permit 203.0.113.0/24 le 30
ip prefix-list INFRARUNBOOK-IN seq 30 deny 0.0.0.0/0 le 32

5.3 — Bogon Filter (Deny RFC 1918 from ISP)

ip prefix-list BOGON-FILTER seq 10 deny 10.0.0.0/8 le 32
ip prefix-list BOGON-FILTER seq 20 deny 172.16.0.0/12 le 32
ip prefix-list BOGON-FILTER seq 30 deny 192.168.0.0/16 le 32
ip prefix-list BOGON-FILTER seq 40 deny 100.64.0.0/10 le 32
ip prefix-list BOGON-FILTER seq 50 deny 169.254.0.0/16 le 32
ip prefix-list BOGON-FILTER seq 60 deny 224.0.0.0/4 le 32
ip prefix-list BOGON-FILTER seq 100 permit 0.0.0.0/0 le 32

---

6 — Route-Maps

Route-maps combine matching (prefix-lists, AS-path ACLs, community lists) with actions (set local-preference, MED, community, prepend).

6.1 — Inbound from ISP: Set Local-Preference and Filter Bogons

route-map RM-INFRARUNBOOK-ISP-IN permit 10
 match ip address prefix-list BOGON-FILTER
 set local-preference 200
!
route-map RM-INFRARUNBOOK-ISP-IN deny 999

6.2 — Outbound to ISP: Advertise Only Your Prefixes

route-map RM-INFRARUNBOOK-ISP-OUT permit 10
 match ip address prefix-list INFRARUNBOOK-OUT
!
route-map RM-INFRARUNBOOK-ISP-OUT deny 999

6.3 — Apply Route-Maps to Neighbour

router bgp 65001
 address-family ipv4 unicast
  neighbor 203.0.113.1 route-map RM-INFRARUNBOOK-ISP-IN in
  neighbor 203.0.113.1 route-map RM-INFRARUNBOOK-ISP-OUT out
 exit-address-family

---

7 — AS-Path Prepending

AS-path prepending makes a path look longer so remote ASes prefer an alternative. Use it on the outbound direction of the less-preferred link.

route-map RM-INFRARUNBOOK-ISP-BACKUP-OUT permit 10
 match ip address prefix-list INFRARUNBOOK-OUT
 set as-path prepend 65001 65001 65001
!
router bgp 65001
 address-family ipv4 unicast
  neighbor 203.0.113.5 route-map RM-INFRARUNBOOK-ISP-BACKUP-OUT out
 exit-address-family

Warning: Never prepend more than 3-4 times. Excessive prepending has diminishing returns and exposes you to AS-path-based hijack attacks.

---

8 — BGP Communities

Communities are 32-bit tags attached to routes. They let you signal policy intent to upstream providers or between your own routers.

8.1 — Define Community Lists

ip community-list standard INFRARUNBOOK-INTERNAL permit 65001:100
ip community-list standard INFRARUNBOOK-CUSTOMER permit 65001:200
ip community-list standard INFRARUNBOOK-BLACKHOLE permit 65001:666

8.2 — Set Communities in a Route-Map

route-map RM-SET-COMMUNITY permit 10
 match ip address prefix-list INFRARUNBOOK-OUT
 set community 65001:100 additive

8.3 — Match and Act on Communities

route-map RM-COMMUNITY-LP permit 10
 match community INFRARUNBOOK-CUSTOMER
 set local-preference 300
!
route-map RM-COMMUNITY-LP permit 20

8.4 — Enable Community Sending to Neighbours

router bgp 65001
 address-family ipv4 unicast
  neighbor 203.0.113.1 send-community both
  neighbor 10.255.0.2 send-community both
  neighbor 10.255.0.3 send-community both
 exit-address-family

---

9 — MED (Multi-Exit Discriminator)

MED tells an eBGP neighbour which of your entry points to prefer when you are multi-homed to the same AS.

! Primary link — lower MED preferred
route-map RM-INFRARUNBOOK-ISP-PRIMARY-OUT permit 10
 match ip address prefix-list INFRARUNBOOK-OUT
 set metric 100
!
! Backup link
route-map RM-INFRARUNBOOK-ISP-BACKUP-OUT permit 10
 match ip address prefix-list INFRARUNBOOK-OUT
 set metric 200

Note: MED is only compared between paths received from the same AS, unless you enable

bgp always-compare-med

.

---

10 — BGP Best-Path Selection

Understanding the decision process is critical for troubleshooting. IOS-XE evaluates in this order:

1. Highest Weight (Cisco-proprietary, local to router)
2. Highest Local Preference (propagated within AS)
3. Locally originated (

   network

   ,

   redistribute

   ,

   aggregate

   )
4. Shortest AS-Path
5. Lowest Origin (IGP < EGP < incomplete)
6. Lowest MED (compared from same neighbouring AS)
7. eBGP over iBGP
8. Lowest IGP metric to next-hop
9. Oldest eBGP route
10. Lowest Router ID
11. Lowest Neighbour IP

Use

show ip bgp 172.16.0.0/16 bestpath

to see why a path was selected.

---

11 — Aggregation and Summarisation

router bgp 65001
 address-family ipv4 unicast
  aggregate-address 172.16.0.0 255.255.0.0 summary-only
 exit-address-family

summary-only

suppresses the more-specific routes. Without it, both the aggregate and the specifics are advertised. You can selectively unsuppress with a route-map:

route-map RM-UNSUPPRESS permit 10
 match ip address prefix-list INFRARUNBOOK-CRITICAL-SUBNETS
!
router bgp 65001
 address-family ipv4 unicast
  neighbor 203.0.113.1 unsuppress-map RM-UNSUPPRESS
 exit-address-family

---

12 — BFD for Fast Failure Detection

BGP default timers (60/180 seconds) are too slow. Bidirectional Forwarding Detection (BFD) detects link failures in milliseconds:

interface GigabitEthernet0/0/0
 description Link_to_infrarunbook-isp
 bfd interval 300 min_rx 300 multiplier 3
!
router bgp 65001
 neighbor 203.0.113.1 fall-over bfd

This gives a detection time of ~900 ms (300ms × 3). Adjust intervals based on your platform's control-plane capacity.

---

13 — Maximum Prefix Protection

Protect your router from a neighbour accidentally advertising the full Internet table when you only expect a default route:

router bgp 65001
 address-family ipv4 unicast
  neighbor 203.0.113.1 maximum-prefix 100 80 restart 5
 exit-address-family

This means: warn at 80% of 100 prefixes, tear down the session if 100 is exceeded, and auto-restart after 5 minutes.

---

14 — Graceful Shutdown

Before performing maintenance, signal your peers to de-prefer your routes using the GRACEFUL_SHUTDOWN community (RFC 8326):

! On the router being taken down
router bgp 65001
 address-family ipv4 unicast
  neighbor 203.0.113.1 send-community both
!
route-map RM-GRACEFUL-SHUTDOWN permit 10
 set community graceful-shutdown additive
 set local-preference 0
!
router bgp 65001
 address-family ipv4 unicast
  neighbor 203.0.113.1 route-map RM-GRACEFUL-SHUTDOWN out
!
! Wait for convergence (~60-90 seconds), then shut down

---

15 — Verification and Troubleshooting Commands

! Neighbour summary
show ip bgp summary

! Detailed neighbour info
show ip bgp neighbors 203.0.113.1

! BGP table for a specific prefix
show ip bgp 172.16.0.0/16

! Best path reason
show ip bgp 172.16.0.0/16 bestpath

! Routes received from a peer (before inbound policy)
show ip bgp neighbors 203.0.113.1 received-routes

! Routes advertised to a peer
show ip bgp neighbors 203.0.113.1 advertised-routes

! Routes accepted from a peer (after inbound policy)
show ip bgp neighbors 203.0.113.1 routes

! Check for dampened routes
show ip bgp dampening dampened-paths

! Clear soft inbound (apply new inbound policy without reset)
clear ip bgp 203.0.113.1 soft in

! BGP event debugging (use with caution in production)
debug ip bgp updates
debug ip bgp events

---

16 — Security Hardening Checklist

• MD5 authentication — always set on eBGP peers to prevent TCP RST attacks.
• TTL security (GTSM) — ensures packets arrive with expected TTL, defeating remote spoofing.
• Prefix limits —

  maximum-prefix

  on every eBGP peer.
• Bogon filtering — deny RFC 1918, RFC 6598, link-local, multicast inbound from ISP.
• Outbound filtering — only advertise your own prefixes. Never leak transit.
• RPKI/ROV — enable Route Origin Validation on IOS-XE 17.3+ for production.

TTL Security Example

router bgp 65001
 neighbor 203.0.113.1 ttl-security hops 1

This sets the expected TTL to 254 (1 hop). Packets with a lower TTL are silently dropped.

---

17 — Complete Running Configuration: rtr-infrarunbook-01

hostname rtr-infrarunbook-01
!
ip prefix-list INFRARUNBOOK-OUT seq 10 permit 172.16.0.0/16
ip prefix-list INFRARUNBOOK-OUT seq 100 deny 0.0.0.0/0 le 32
!
ip prefix-list BOGON-FILTER seq 10 deny 10.0.0.0/8 le 32
ip prefix-list BOGON-FILTER seq 20 deny 172.16.0.0/12 le 32
ip prefix-list BOGON-FILTER seq 30 deny 192.168.0.0/16 le 32
ip prefix-list BOGON-FILTER seq 40 deny 100.64.0.0/10 le 32
ip prefix-list BOGON-FILTER seq 100 permit 0.0.0.0/0 le 32
!
ip community-list standard INFRARUNBOOK-INTERNAL permit 65001:100
!
route-map RM-INFRARUNBOOK-ISP-IN permit 10
 match ip address prefix-list BOGON-FILTER
 set local-preference 200
!
route-map RM-INFRARUNBOOK-ISP-IN deny 999
!
route-map RM-INFRARUNBOOK-ISP-OUT permit 10
 match ip address prefix-list INFRARUNBOOK-OUT
 set community 65001:100 additive
!
route-map RM-INFRARUNBOOK-ISP-OUT deny 999
!
interface Loopback0
 ip address 10.255.0.1 255.255.255.255
!
interface GigabitEthernet0/0/0
 description Link_to_infrarunbook-isp
 ip address 203.0.113.2 255.255.255.252
 bfd interval 300 min_rx 300 multiplier 3
 no shutdown
!
interface GigabitEthernet0/0/1
 description Link_to_infrarunbook-02
 ip address 10.0.12.1 255.255.255.252
 no shutdown
!
interface GigabitEthernet0/0/2
 description Link_to_infrarunbook-03
 ip address 10.0.13.1 255.255.255.252
 no shutdown
!
router ospf 1
 router-id 10.255.0.1
 passive-interface Loopback0
 network 10.255.0.1 0.0.0.0 area 0
 network 10.0.12.0 0.0.0.3 area 0
 network 10.0.13.0 0.0.0.3 area 0
!
router bgp 65001
 bgp router-id 10.255.0.1
 bgp log-neighbor-changes
 no bgp default ipv4-unicast
 !
 neighbor 203.0.113.1 remote-as 65002
 neighbor 203.0.113.1 description eBGP_to_infrarunbook-isp
 neighbor 203.0.113.1 password InfraRunBook$ecure!
 neighbor 203.0.113.1 ttl-security hops 1
 neighbor 203.0.113.1 fall-over bfd
 !
 neighbor 10.255.0.2 remote-as 65001
 neighbor 10.255.0.2 description iBGP_to_infrarunbook-02
 neighbor 10.255.0.2 update-source Loopback0
 neighbor 10.255.0.2 next-hop-self
 !
 neighbor 10.255.0.3 remote-as 65001
 neighbor 10.255.0.3 description iBGP_to_infrarunbook-03
 neighbor 10.255.0.3 update-source Loopback0
 neighbor 10.255.0.3 next-hop-self
 !
 address-family ipv4 unicast
  neighbor 203.0.113.1 activate
  neighbor 203.0.113.1 soft-reconfiguration inbound
  neighbor 203.0.113.1 route-map RM-INFRARUNBOOK-ISP-IN in
  neighbor 203.0.113.1 route-map RM-INFRARUNBOOK-ISP-OUT out
  neighbor 203.0.113.1 maximum-prefix 100 80 restart 5
  neighbor 203.0.113.1 send-community both
  !
  neighbor 10.255.0.2 activate
  neighbor 10.255.0.2 soft-reconfiguration inbound
  neighbor 10.255.0.2 route-reflector-client
  neighbor 10.255.0.2 send-community both
  !
  neighbor 10.255.0.3 activate
  neighbor 10.255.0.3 soft-reconfiguration inbound
  neighbor 10.255.0.3 route-reflector-client
  neighbor 10.255.0.3 send-community both
  !
  network 172.16.0.0 mask 255.255.0.0
  aggregate-address 172.16.0.0 255.255.0.0 summary-only
 exit-address-family
!
end

---

18 — Monitoring with SNMP and Syslog

! SNMP for BGP MIB polling
snmp-server community infrarunbook-ro RO
snmp-server enable traps bgp
!
! Syslog
logging host 10.1.1.50
logging trap informational

Monitor these OIDs for neighbour state changes:

cbgpPeer2State

(CISCO-BGP4-MIB) and

bgpPeerState

(BGP4-MIB).

---

Frequently Asked Questions

Q1: What is the difference between eBGP and iBGP?

eBGP peers reside in different Autonomous Systems, while iBGP peers share the same AS number. eBGP increments the AS-path; iBGP does not. iBGP requires either a full mesh, route reflectors, or confederations to ensure all routers learn all routes.

Q2: Why do I need

next-hop-self

on iBGP sessions?

When a border router advertises an eBGP-learned route to iBGP peers, the next-hop is the external peer's IP. Internal routers have no route to that IP.

next-hop-self

rewrites the next-hop to the border router's loopback, which is reachable via the IGP.

Q3: How many route reflectors should I deploy?

At minimum two for redundancy. In large networks, deploy route reflectors in a hierarchy or cluster. Each cluster should have two RRs sharing the same

bgp cluster-id

.

Q4: How do I prevent my AS from becoming a transit AS?

Apply a strict outbound prefix-list or route-map that only permits prefixes you originate. Never redistribute eBGP-learned routes to another eBGP peer without explicit policy. The

INFRARUNBOOK-OUT

prefix-list in this guide achieves exactly this.

Q5: What is the purpose of

soft-reconfiguration inbound

?

It stores a copy of all routes received from a peer before your inbound policy is applied. This allows you to modify inbound route-maps and apply them with

clear ip bgp <peer> soft in

without tearing down the session. The trade-off is extra memory usage.

Q6: When should I use

weight

vs

local-preference

?

Weight is Cisco-proprietary and local to a single router — it is never propagated. Local-preference is a standard BGP attribute propagated to all iBGP peers within the AS. Use weight for per-router decisions and local-preference for AS-wide policy.

Q7: How does BFD improve BGP convergence?

BFD runs in the data plane and detects link failures in sub-second intervals (as low as 50ms × 3 = 150ms). Without BFD, BGP relies on its hold timer (default 180 seconds) to detect a dead peer, causing prolonged traffic black-holing.

Q8: Can I use BGP communities with eBGP peers?

Yes, but you must explicitly enable it with

neighbor <ip> send-community both

. By default, IOS-XE strips communities from eBGP updates. Many ISPs define action communities (e.g., no-export, blackhole) in their peering guides.

Q9: What is the

maximum-prefix restart

timer?

When a peer exceeds the maximum-prefix limit, the session is torn down. The

restart <minutes>

keyword automatically re-establishes the session after the specified interval. Without it, the session stays down until you manually clear it.

Q10: How do I verify which path BGP has selected and why?

Use

show ip bgp <prefix>

to see all paths, then

show ip bgp <prefix> bestpath

for the decision reason. You can also use

show ip bgp <prefix> longer-prefixes

to check for more-specific route leaks. For detailed comparison,

debug ip bgp updates

shows real-time update processing (use with caution in production).

Q11: Should I filter inbound routes from my ISP?

Absolutely. At a minimum, deny bogon prefixes (RFC 1918, RFC 6598, link-local, multicast, and your own prefixes). If you only need a default route, accept only 0.0.0.0/0 and deny everything else. Never trust an ISP not to leak routes accidentally.

Q12: What is RPKI/ROV and should I enable it?

Resource Public Key Infrastructure (RPKI) with Route Origin Validation (ROV) uses cryptographic certificates to verify that an AS is authorized to originate a prefix. IOS-XE 17.3+ supports it via

rpki server

configuration. It is strongly recommended for any network peering on the public Internet to mitigate BGP hijacking.
