Symptoms
You walk in Monday morning and the helpdesk queue is already stacked with tickets: clients on VLAN 30 can't get an IP address. Windows machines are sitting on 169.254.x.x APIPA addresses. Linux hosts running
dhclientjust spin and time out. The DHCP server itself is running fine — you can confirm that by testing from its own subnet — but anything going through the relay is dead in the water.
The tell-tale signs of a broken DHCP relay are consistent: client logs show repeated DHCPDISCOVER packets sent with no DHCPOFFER coming back, IPAM shows zero new leases being issued for that scope, and a packet capture on the client VLAN shows broadcasts going out but no unicast replies returning. If you're seeing any combination of these, the relay chain is broken somewhere. Let's work through every place it can break.
Root Cause 1: ip helper-address Missing or Misconfigured
Why It Happens
This is the most common cause I've seen, and it almost always happens after a network change — a new VLAN gets provisioned, the SVI goes up, routing is confirmed, and then someone marks the ticket done without adding the helper. By default, IOS and IOS-XE silently drop UDP broadcast packets. A DHCP Discover goes out as a layer-2 broadcast (destination MAC ff:ff:ff:ff:ff:ff, destination IP 255.255.255.255). Without
ip helper-addresson the SVI, that packet hits the L3 interface and gets discarded. No error, no log message — just silence.
The
ip helper-addresscommand does two things: it intercepts the UDP broadcast on the ingress interface and re-encapsulates it as a unicast packet destined for the configured DHCP server, and it fills in the giaddr (Gateway IP Address) field in the DHCP packet header so the server knows which subnet pool to allocate from. Without it, neither of those things happens and the client never hears back.
How to Identify It
Check the SVI configuration directly. If you're troubleshooting VLAN 30 (client network 10.10.30.0/24), run:
sw-infrarunbook-01# show running-config interface vlan 30
Building configuration...
Current configuration : 96 bytes
!
interface Vlan30
ip address 10.10.30.1 255.255.255.0
no ip proxy-arp
endNo
ip helper-addressline — that's your problem. You can also confirm from the server side by enabling DHCP packet debugging. If the server sees nothing arriving, the relay is not forwarding:
sw-infrarunbook-01# debug ip dhcp server packet
DHCP server packet debugging is on.
! ... time passes, clients retry DHCPDISCOVER ... nothing appears on serverHow to Fix It
Add the helper address under the SVI, pointing to your DHCP server at 10.10.20.100:
sw-infrarunbook-01# configure terminal
sw-infrarunbook-01(config)# interface vlan 30
sw-infrarunbook-01(config-if)# ip helper-address 10.10.20.100
sw-infrarunbook-01(config-if)# end
sw-infrarunbook-01# write memoryAfter adding this, trigger a new DHCP request from a client and watch the debug output. You should immediately see the relay in action:
DHCPD: DHCPDISCOVER received from client 0100.50b6.1234.56 on interface Vlan30.
DHCPD: Sending DHCPOFFER to 10.10.30.10 (10.10.30.10).
DHCPD: unicasting DHCPOFFER to client 0100.50b6.1234.56 at 10.10.30.10.If you need redundancy or have multiple DHCP servers, you can stack multiple
ip helper-addressstatements on the same interface. IOS will forward the DHCP packet to all configured destinations simultaneously.
Root Cause 2: DHCP Server Not Reachable from the Relay Agent
Why It Happens
The helper address is configured, but the relay agent can't actually reach the DHCP server. The relay converts the broadcast to a unicast packet and fires it off, but that packet either has no route, hits a dead next-hop, or is pointed at the wrong IP entirely. This is surprisingly common when DHCP servers get migrated to new subnets and someone updates the server config but forgets to update every
ip helper-addressacross every SVI on every switch in the environment.
In my experience, it also happens in environments where the DHCP server sits behind a firewall and a routing policy or firewall rule change silently breaks the path. The relay switch never knows — it faithfully forwards relayed packets into a void.
How to Identify It
First, verify the route to the DHCP server exists on the relay device:
sw-infrarunbook-01# show ip route 10.10.20.100
Routing entry for 10.10.20.100/32
Known via "ospf 1", distance 110, metric 20, type intra area
Last update from 10.10.10.2 on GigabitEthernet1/0/1, 00:15:43 ago
Routing Descriptor Blocks:
* 10.10.10.2, from 10.10.10.2, 00:15:43 ago, via GigabitEthernet1/0/1
Route metric is 20, traffic share count is 1If the route is missing, you'll see:
sw-infrarunbook-01# show ip route 10.10.20.100
% Network not in tableThen test reachability with a sourced ping from the SVI that's doing the relay. This step matters — the DHCP relay packet is sourced from the ingress SVI IP, which becomes the giaddr, so the return path must work for that source specifically:
sw-infrarunbook-01# ping 10.10.20.100 source vlan 30
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 10.10.20.100, timeout is 2 seconds:
Packet sent with a source address of 10.10.30.1
.....
Success rate is 0 percent (0/5)Zero percent. The relay can't reach the server. Also verify the helper-address IP itself — is it actually pointing at the right server?
sw-infrarunbook-01# show running-config | include helper
ip helper-address 10.10.20.101The server moved to 10.10.20.100 but the helper still says .101. The switch is faithfully relaying packets to an IP that no longer answers DHCP. This kind of stale config after a server migration is one of the most common root causes I've dealt with in larger environments.
How to Fix It
Correct the helper address, then verify end-to-end reachability before testing client renewals:
sw-infrarunbook-01(config)# interface vlan 30
sw-infrarunbook-01(config-if)# no ip helper-address 10.10.20.101
sw-infrarunbook-01(config-if)# ip helper-address 10.10.20.100
sw-infrarunbook-01(config-if)# end
sw-infrarunbook-01# write memoryRe-run the sourced ping. Once it returns 100% success, trigger a client DHCP request and confirm leases are being issued.
Root Cause 3: Relay Agent Not Forwarding
Why It Happens
The helper is configured, the server is reachable, but packets still aren't getting forwarded. The most common culprit here is
no service dhcphaving been added to the device globally. This single command disables all DHCP services — including relay forwarding — in one shot. It's often introduced by automated CIS hardening scripts that confuse disabling the local DHCP server function with disabling relay. The scripts see "DHCP server" as a service to turn off, run
no service dhcp, and break relay without realizing it. There's no error, no syslog event. It just stops working.
A second cause is a conflict with DHCP relay information, also known as Option 82. If the switch inserts Option 82 into relayed packets but the upstream DHCP server isn't configured to accept or trust it, the server will silently drop the packets. Some servers treat unrecognized or untrusted Option 82 as a policy violation.
How to Identify It
Check whether the DHCP service has been globally disabled:
sw-infrarunbook-01# show running-config | include service dhcp
no service dhcpThat single line shuts down everything. To investigate Option 82 settings:
sw-infrarunbook-01# show ip dhcp relay information
DHCP relay agent is enabled
Relay option 82 insertion : enabled
Relay option 82 removal : disabled
Relay option 82 checking : enabled
Circuit-ID format : vlan-mod-portIf Option 82 checking is enabled and the server doesn't trust the option, it drops the packet. Enable relay debugging to see both directions of the relay conversation:
sw-infrarunbook-01# debug ip dhcp relay packet
DHCPD: relay forwarding DHCPDISCOVER from 0.0.0.0 to 10.10.20.100
DHCPD: relay - received DHCPOFFER from 10.10.20.100
DHCPD: relay forwarding DHCPOFFER to 10.10.30.1If you see the forward lines but no replies returning from the server, the problem is between the relay and the server. If you see absolutely nothing despite clients actively sending Discovers, the relay service itself is either disabled or the SVI isn't seeing the broadcasts at the layer-2 level (see Root Cause 4).
How to Fix It
Re-enable the DHCP service globally:
sw-infrarunbook-01(config)# service dhcpIf Option 82 is causing issues with a DHCP server that doesn't support it, disable the insertion:
sw-infrarunbook-01(config)# no ip dhcp relay information optionIf your topology uses cascaded or stacked relays and you need the device to trust incoming packets that already contain Option 82:
sw-infrarunbook-01(config)# ip dhcp relay information trust-allRoot Cause 4: Broadcast Not Reaching the Relay Agent
Why It Happens
The relay is perfectly configured, but the client's DHCP Discover broadcast never reaches the SVI in the first place. This is a pure layer-2 problem: the VLAN may not be active on the switch, the SVI may be down, the access port may be assigned to the wrong VLAN, or the trunk between the access layer and the distribution layer may not be carrying that VLAN ID. The relay agent on the SVI never sees DHCPDISCOVER because the frame simply doesn't make it there.
This one trips people up because the relay configuration can be absolutely correct and you'll still get nothing. All the debugging on the relay side shows zero activity — from the relay's perspective, nobody is asking for an address. The problem is entirely below it in the stack.
How to Identify It
Start by verifying the SVI state:
sw-infrarunbook-01# show interface vlan 30
Vlan30 is down, line protocol is down
Hardware is EtherSVI, address is 0c75.bd12.3400 (bia 0c75.bd12.3400)
Internet address is 10.10.30.1/24
MTU 1500 bytes, BW 1000000 Kbit/sec, DLY 10 usecDown/down on an SVI means there are no active, forwarding ports in VLAN 30 on this switch. Check the VLAN database and trunk configuration:
sw-infrarunbook-01# show vlan id 30
VLAN Name Status Ports
---- -------------------------------- --------- -------------------------------
30 CLIENT_VLAN active
sw-infrarunbook-01# show interfaces trunk | include 30
! No output -- VLAN 30 is not in any trunk's allowed listVLAN 30 has no member ports and isn't carried on any trunk. Broadcasts from clients stay local to the access switch and never reach the SVI on the distribution layer. Also confirm the client's access port is in the right VLAN:
sw-infrarunbook-01# show interface GigabitEthernet1/0/5 switchport
Name: Gi1/0/5
Switchport: Enabled
Administrative Mode: static access
Operational Mode: static access
Access Mode VLAN: 20 <-- should be 30!The port is in VLAN 20, not 30. Client broadcasts go into the wrong VLAN, where either a different relay is configured or no relay exists at all. This is a classic fat-finger during port provisioning — the type of thing that's easy to miss when you're doing a batch of port configs late in the day.
How to Fix It
Correct the access port VLAN assignment:
sw-infrarunbook-01(config)# interface GigabitEthernet1/0/5
sw-infrarunbook-01(config-if)# switchport access vlan 30
sw-infrarunbook-01(config-if)# endIf VLAN 30 wasn't in the allowed list on the uplink trunk, add it explicitly:
sw-infrarunbook-01(config)# interface GigabitEthernet1/0/1
sw-infrarunbook-01(config-if)# switchport trunk allowed vlan add 30
sw-infrarunbook-01(config-if)# endAfter fixing the layer-2 path, the SVI will transition to up/up within a few seconds as active ports join VLAN 30, and client DHCP Discovers will start reaching the relay agent.
Root Cause 5: ACL Blocking DHCP Traffic
Why It Happens
Everything in the relay configuration looks correct, but an access control list is silently dropping the packets. ACLs on SVIs are common — they enforce inter-VLAN access policies. If the ACL was written without explicit provisions for DHCP traffic (UDP ports 67 and 68), the packets hit the implicit deny at the end of every IOS ACL and disappear. Because DHCP drops don't generate syslog entries by default unless you've explicitly appended
logto the deny ACE, these drops leave no trace in the logs.
I've also seen this bite teams on outbound ACLs applied to the routed uplink toward the DHCP server — the relayed unicast packet from the switch gets dropped before it even leaves the device. Both directions matter: inbound on the client SVI blocks DHCPDISCOVER and DHCPREQUEST, and outbound toward the server blocks the relayed unicast. Either failure mode presents identically to the client.
How to Identify It
Check whether ACLs are applied to the relevant interface:
sw-infrarunbook-01# show ip interface vlan 30
Vlan30 is up, line protocol is up
Internet address is 10.10.30.1/24
Broadcast address is 255.255.255.255
Inbound access list is CLIENT_IN
Outbound access list is not setThere's an inbound ACL named CLIENT_IN. Inspect its contents and hit counters:
sw-infrarunbook-01# show ip access-lists CLIENT_IN
Extended IP access list CLIENT_IN
10 permit tcp 10.10.30.0 0.0.0.255 any eq 80
20 permit tcp 10.10.30.0 0.0.0.255 any eq 443
30 permit tcp 10.10.30.0 0.0.0.255 any eq 22
40 deny ip any any (4821 matches)No permit for UDP 67 or 68. That 4821-match deny line is the smoking gun — DHCP broadcasts are in there. To confirm that DHCP traffic specifically is hitting the deny, use IP packet debug briefly:
sw-infrarunbook-01# debug ip packet detail
! Trigger a DHCP renew from a client, then watch:
IP: s=0.0.0.0 (Vlan30), d=255.255.255.255, len 328, rcvd 0
UDP src=68, dst=67
IP: tableid=0, s=0.0.0.0 (Vlan30), d=255.255.255.255, len 328
access-list CLIENT_IN deniedConfirmed. Turn off the debug immediately after collecting that output —
debug ip packeton a busy switch will spike the control plane CPU and make the outage worse:
sw-infrarunbook-01# no debug ip packetHow to Fix It
Insert a permit rule for DHCP before the deny. A DHCPDISCOVER comes from source IP 0.0.0.0 destined for 255.255.255.255, UDP source port 68, destination port 67. Sequence number 5 puts it at the top of the list:
sw-infrarunbook-01(config)# ip access-list extended CLIENT_IN
sw-infrarunbook-01(config-ext-nacl)# 5 permit udp any host 255.255.255.255 eq 67
sw-infrarunbook-01(config-ext-nacl)# endVerify the updated ACL and confirm the deny count has stopped climbing:
sw-infrarunbook-01# show ip access-lists CLIENT_IN
Extended IP access list CLIENT_IN
5 permit udp any host 255.255.255.255 eq 67 (22 matches)
10 permit tcp 10.10.30.0 0.0.0.255 any eq 80
20 permit tcp 10.10.30.0 0.0.0.255 any eq 443
30 permit tcp 10.10.30.0 0.0.0.255 any eq 22
40 deny ip any any (4821 matches)The deny count is frozen and the new DHCP permit is accumulating matches. Clients should start receiving offers within seconds.
Additional Causes Worth Checking
DHCP Snooping Dropping Relay Replies
If DHCP snooping is enabled globally and the uplink carrying relayed server replies isn't configured as a trusted port, the switch will silently drop DHCP OFFERs and ACKs arriving from the server direction. This is a common oversight when deploying DHCP snooping for the first time. Any port carrying server-sourced DHCP traffic — including uplinks to a core router doing relay — must be explicitly trusted:
sw-infrarunbook-01(config)# interface GigabitEthernet1/0/1
sw-infrarunbook-01(config-if)# ip dhcp snooping trustNo Matching Scope on the DHCP Server
The server receives the relayed packet, but has no scope matching the giaddr. Server logs will show something like "No subnet defined for 10.10.30.1" and the request is dropped without an offer. This isn't a relay problem — it's a server configuration problem — but it presents identically from the client's perspective. Always confirm the DHCP server has a scope covering the client subnet (10.10.30.0/24) with the default gateway option pointing to 10.10.30.1 before assuming the relay is at fault.
Prevention
Most DHCP relay failures are preventable with consistent operational habits. Build your VLAN provisioning runbooks so that
ip helper-addressis a required, checklist-verified step — not an afterthought. The single most common failure mode is a new VLAN being stood up correctly in every other way except for that one line. If you use configuration management tooling like Ansible or NSO, add a compliance check that flags any client-facing SVI missing a helper address and run it weekly. Catching drift before users do is always cheaper than troubleshooting at 2 AM.
For ACLs, establish a team standard: every SVI ACL must include an explicit DHCP permit as one of the first entries — treat it the same way you'd treat a mandatory ICMP permit. Network change reviews should verify this before approval. Some teams keep a standard named ACL object-group for DHCP that gets imported into every new SVI policy automatically.
On the server side, configure SNMP traps or syslog alerting for scope exhaustion and failed allocation events such as "no subnet defined." These server-side signals often surface relay problems faster than waiting for a helpdesk ticket. Pair this with IPAM monitoring so scope utilization is visible in a dashboard — if a scope that's normally 60% utilized drops to zero new assignments overnight, something upstream broke.
When migrating a DHCP server to a new IP, run a global audit before cutting over:
show running-config | include helper-addressacross every L3 switch and router in the environment. Find every reference to the old IP, update them all, then migrate the server. That five-minute audit prevents the scenario where clients in three VLANs lose DHCP because someone only updated the primary distribution switch and forgot about the two access-layer SVIs doing local relay.
Document your relay topology in your IPAM or CMDB: which SVIs relay to which servers, which VLANs are affected, and which physical devices are in the path. When DHCP stops working under pressure, having that map lets you go straight to the right config instead of hunting across dozens of devices hoping to find the misconfiguration before the next escalation call.
