Why do I see both routers as HSRP Active (split-brain)?

Both routers show Active when HSRP hellos are not reaching the peer. Common causes include the VLAN not being trunked between switches, mismatched HSRP version or authentication, or an ACL blocking multicast 224.0.0.2 (v1) or 224.0.0.102 (v2) UDP port 1985.

Cisco HSRP and VRRP Configuration: Complete Run Book for First Hop Redundancy on IOS/IOS-XE

Q: What is the default HSRP priority and how does election work?

The default HSRP priority is 100. The router with the highest priority becomes Active. If priorities are equal, the router with the highest IP address on the HSRP interface wins the election.

Q: Does VRRP preempt by default?

Yes. Unlike HSRP where preemption is disabled by default, VRRP has preemption enabled by default. You must explicitly configure 'no vrrp preempt' to disable it.

Q: Can HSRP and VRRP run on the same interface?

Technically yes, they are independent protocols. However, running both on the same interface creates unnecessary complexity. Best practice is to choose one FHRP per interface and maintain consistency across the network.

Q: How fast can HSRP failover be?

With millisecond timers (hello 250 ms, hold 750 ms), failover occurs in under 1 second. With BFD integration (standby bfd), failure detection can be as fast as 150 ms using a 50 ms interval with a multiplier of 3.

Q: How do I achieve active/active load balancing with HSRP?

Create two or more HSRP groups on the same interface, each with a different virtual IP. Make different routers Active for different groups by adjusting priorities. Distribute clients across the virtual IPs using separate DHCP pools or DNS round-robin.

Q: What happens if the tracked interface flaps rapidly?

Without dampening, the HSRP/VRRP priority fluctuates causing repeated failovers. Use 'track delay down 10 up 30' to require the tracked object to be down for 10 seconds before decrementing priority and up for 30 seconds before restoring it, preventing flapping.

Introduction

First Hop Redundancy Protocols (FHRPs) ensure default-gateway availability when a Layer 3 switch or router fails. Cisco supports three main FHRPs: Hot Standby Router Protocol (HSRP) — a Cisco-proprietary protocol, Virtual Router Redundancy Protocol (VRRP) — an IETF standard (RFC 5798), and Gateway Load Balancing Protocol (GLBP). This run book focuses on the two most widely deployed: HSRP and VRRP, with production configurations, verification, and troubleshooting for IOS and IOS-XE.

1 — HSRP vs VRRP: Key Differences at a Glance

Feature	HSRP	VRRP
Standard	Cisco proprietary	IETF RFC 5798
Virtual MAC (v2/v3)	0000.0c9f.fXXX	0000.5e00.01XX
Default Priority	100	100
Preemption Default	Disabled	Enabled
Hello / Hold Timers	3 s / 10 s	1 s / 3× hello
Multicast Address (IPv4)	224.0.0.2 (v1) / 224.0.0.102 (v2)	224.0.0.18
Group Range	0-255 (v1), 0-4095 (v2)	0-255 (v2), 1-255 (v3)
IPv6 Support	HSRPv2	VRRPv3

2 — Lab Topology

All examples use the following topology:

              +--- sw-infrarunbook-01 (Active / Master) ---+
              |        Gi1/0/1  — Uplink                    |
Clients ------+        VLAN 10: 10.10.10.0/24               +---- Core / WAN
              |        Gi1/0/1  — Uplink                    |
              +--- sw-infrarunbook-02 (Standby / Backup) ---+

Virtual IP: 10.10.10.1
sw-infrarunbook-01 real IP: 10.10.10.2
sw-infrarunbook-02 real IP: 10.10.10.3

3 — HSRP Version 1 — Basic Configuration

3.1 — sw-infrarunbook-01 (Active)

hostname sw-infrarunbook-01
!
interface Vlan10
 description infrarunbook-prod gateway
 ip address 10.10.10.2 255.255.255.0
 standby version 1
 standby 10 ip 10.10.10.1
 standby 10 priority 110
 standby 10 preempt
 standby 10 timers 3 10
 standby 10 authentication infrarunbook
 no shutdown

3.2 — sw-infrarunbook-02 (Standby)

hostname sw-infrarunbook-02
!
interface Vlan10
 description infrarunbook-prod gateway
 ip address 10.10.10.3 255.255.255.0
 standby version 1
 standby 10 ip 10.10.10.1
 standby 10 priority 90
 standby 10 preempt
 standby 10 timers 3 10
 standby 10 authentication infrarunbook
 no shutdown

Key points:

priority 110 on sw-infrarunbook-01 wins the election (default is 100).
preempt allows the higher-priority router to reclaim Active when it recovers.
authentication uses plain-text in v1 — for production, prefer HSRPv2 with MD5.

4 — HSRP Version 2 — Recommended Production Config

HSRPv2 supports groups 0-4095, IPv6, and MD5 authentication. Always prefer v2 unless you have a legacy constraint.

4.1 — sw-infrarunbook-01 (Active)

interface Vlan10
 description infrarunbook-prod gateway
 ip address 10.10.10.2 255.255.255.0
 standby version 2
 standby 10 ip 10.10.10.1
 standby 10 priority 110
 standby 10 preempt delay minimum 30 reload 60
 standby 10 timers msec 250 msec 750
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026
 standby 10 name INFRARUNBOOK-GW
 no shutdown

4.2 — sw-infrarunbook-02 (Standby)

interface Vlan10
 description infrarunbook-prod gateway
 ip address 10.10.10.3 255.255.255.0
 standby version 2
 standby 10 ip 10.10.10.1
 standby 10 priority 90
 standby 10 preempt delay minimum 30 reload 60
 standby 10 timers msec 250 msec 750
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026
 standby 10 name INFRARUNBOOK-GW
 no shutdown

Configuration notes:

preempt delay minimum 30 reload 60 — after a failover or reload, wait 30 s (or 60 s after reload) before preempting back. This allows routing protocols time to converge.
timers msec 250 msec 750 — sub-second hello (250 ms) and hold (750 ms) for faster failover.
MD5 key-string — prevents spoofed HSRP peers.

5 — HSRP Interface Tracking

Track an uplink or a remote destination so that when a tracked object goes down, the priority decrements and failover occurs.

5.1 — Track an Interface

! Track uplink interface on sw-infrarunbook-01
track 1 interface GigabitEthernet1/0/1 line-protocol
!
interface Vlan10
 standby 10 track 1 decrement 30

If Gi1/0/1 goes down, the effective priority becomes 110 − 30 = 80, which is lower than 90, so sw-infrarunbook-02 takes over.

5.2 — Track a Remote IP via IP SLA

ip sla 1
 icmp-echo 203.0.113.1 source-ip 10.10.10.2
 frequency 5
 threshold 1000
ip sla schedule 1 life forever start-time now
!
track 2 ip sla 1 reachability
 delay down 10 up 30
!
interface Vlan10
 standby 10 track 2 decrement 30

This pings the upstream gateway 203.0.113.1 every 5 seconds. If it becomes unreachable for 10 seconds, the priority drops by 30.

6 — HSRP Load Balancing with Multiple Groups

True active/active load sharing uses two HSRP groups, each with a different Active router. Clients are split across two gateways (or use two DHCP pools).

! sw-infrarunbook-01
interface Vlan10
 standby version 2
 ! Group 10 — Active on sw-infrarunbook-01
 standby 10 ip 10.10.10.1
 standby 10 priority 110
 standby 10 preempt delay minimum 30
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026
 ! Group 20 — Standby on sw-infrarunbook-01
 standby 20 ip 10.10.10.4
 standby 20 priority 90
 standby 20 preempt delay minimum 30
 standby 20 authentication md5 key-string 0 Infr@RunB00k!2026

! sw-infrarunbook-02
interface Vlan10
 standby version 2
 ! Group 10 — Standby on sw-infrarunbook-02
 standby 10 ip 10.10.10.1
 standby 10 priority 90
 standby 10 preempt delay minimum 30
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026
 ! Group 20 — Active on sw-infrarunbook-02
 standby 20 ip 10.10.10.4
 standby 20 priority 110
 standby 20 preempt delay minimum 30
 standby 20 authentication md5 key-string 0 Infr@RunB00k!2026

DHCP pool A hands out 10.10.10.1; pool B hands out 10.10.10.4. Traffic is balanced across both switches.

7 — HSRPv2 with IPv6

! sw-infrarunbook-01
interface Vlan10
 ipv6 address 2001:db8:10::2/64
 standby version 2
 standby 10 ipv6 2001:db8:10::1/64
 standby 10 priority 110
 standby 10 preempt
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026

! sw-infrarunbook-02
interface Vlan10
 ipv6 address 2001:db8:10::3/64
 standby version 2
 standby 10 ipv6 2001:db8:10::1/64
 standby 10 priority 90
 standby 10 preempt
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026

8 — HSRP Verification and Troubleshooting

8.1 — Show Commands

show standby
show standby brief
show standby vlan 10
show standby vlan 10 10
show track
show track brief

8.2 — Sample Output: show standby brief

sw-infrarunbook-01# show standby brief
                     P indicates configured to preempt.
                     |
Interface   Grp  Pri P State    Active          Standby         Virtual IP
Vl10        10   110 P Active   local           10.10.10.3      10.10.10.1

8.3 — Debug Commands

debug standby
debug standby events
debug standby packets
debug standby errors
debug standby terse

Warning: Never leave debugs running on production switches for extended periods. Always use
terminal monitor
from a VTY session and disable promptly:
undebug all
.

8.4 — Common HSRP Issues Checklist

Both routers show Active: Authentication mismatch, ACL blocking multicast 224.0.0.102, or VLAN pruning.
Failover not occurring: Preempt not configured on standby, or track decrement too low.
Version mismatch: v1 and v2 on same group do NOT interoperate — both peers must match.
Duplicate IP warning: Ensure the virtual IP is not assigned to any physical interface.
Flapping: Check for STP convergence issues or unstable uplink causing track objects to bounce.

9 — VRRP Version 2 — Basic Configuration

VRRP is the standards-based alternative (RFC 3768 for v2, RFC 5798 for v3). Useful in multi-vendor environments.

9.1 — sw-infrarunbook-01 (Master)

interface Vlan10
 description infrarunbook-prod gateway
 ip address 10.10.10.2 255.255.255.0
 vrrp 10 ip 10.10.10.1
 vrrp 10 priority 110
 vrrp 10 preempt delay minimum 30
 vrrp 10 timers advertise 1
 vrrp 10 authentication md5 key-string Infr@RunB00k!2026
 no shutdown

9.2 — sw-infrarunbook-02 (Backup)

interface Vlan10
 description infrarunbook-prod gateway
 ip address 10.10.10.3 255.255.255.0
 vrrp 10 ip 10.10.10.1
 vrrp 10 priority 90
 vrrp 10 preempt delay minimum 30
 vrrp 10 timers advertise 1
 vrrp 10 authentication md5 key-string Infr@RunB00k!2026
 no shutdown

Key differences from HSRP:

VRRP preempt is enabled by default.
Only the Master sends advertisements; Backup routers listen.
The virtual IP can be the same as a real interface IP (the owner router always has priority 255).

10 — VRRPv3 (Unified for IPv4 and IPv6)

VRRPv3 uses the

fhrp version vrrp v3

global command on IOS-XE and provides a unified address family model.

10.1 — sw-infrarunbook-01

fhrp version vrrp v3
!
interface Vlan10
 ip address 10.10.10.2 255.255.255.0
 ipv6 address 2001:db8:10::2/64
 !
 vrrp 10 address-family ipv4
  address 10.10.10.1 primary
  priority 110
  preempt delay minimum 30
  timers advertise 100
  track 1 decrement 30
  exit-vrrp
 !
 vrrp 10 address-family ipv6
  address 2001:db8:10::1/64 primary
  priority 110
  preempt delay minimum 30
  timers advertise 100
  exit-vrrp

10.2 — sw-infrarunbook-02

fhrp version vrrp v3
!
interface Vlan10
 ip address 10.10.10.3 255.255.255.0
 ipv6 address 2001:db8:10::3/64
 !
 vrrp 10 address-family ipv4
  address 10.10.10.1 primary
  priority 90
  preempt delay minimum 30
  timers advertise 100
  exit-vrrp
 !
 vrrp 10 address-family ipv6
  address 2001:db8:10::1/64 primary
  priority 90
  preempt delay minimum 30
  timers advertise 100
  exit-vrrp

Note: VRRPv3

timers advertise

is in milliseconds (100 = 100 ms). VRRPv3 does not support authentication natively per RFC 5798.

11 — VRRP Interface Tracking

track 1 interface GigabitEthernet1/0/1 line-protocol
!
interface Vlan10
 vrrp 10 track 1 decrement 30

For VRRPv3, tracking is configured inside the

vrrp 10 address-family ipv4

block as shown in section 10.1.

12 — VRRP Verification and Troubleshooting

show vrrp
show vrrp brief
show vrrp interface vlan 10
show vrrp all

12.1 — Sample Output

sw-infrarunbook-01# show vrrp brief
Interface          Grp Pri Time  Own Pre State   Master addr     Group addr
Vl10               10  110 3218       Y  Master  10.10.10.2      10.10.10.1

12.2 — Debug Commands

debug vrrp all
debug vrrp events
debug vrrp packets

13 — Security Hardening for FHRP

Always enable authentication. For HSRP, use MD5 key-string or key-chain. VRRP v2 supports MD5; VRRPv3 does not (use ACLs instead).
Filter FHRP traffic on access ports. Prevent rogue devices from injecting HSRP/VRRP hellos:

! Example: ACL on access-facing L3 interface
ip access-list extended BLOCK-FHRP-FROM-ACCESS
 deny   udp any host 224.0.0.102 eq 1985
 deny   udp any host 224.0.0.18 eq 112
 permit ip any any
!
interface Vlan20
 ip access-group BLOCK-FHRP-FROM-ACCESS in

Use CoPP (Control Plane Policing) to rate-limit HSRP/VRRP to the CPU.
Enable BFD (Bidirectional Forwarding Detection) for sub-second failure detection alongside FHRP:

interface Vlan10
 bfd interval 50 min_rx 50 multiplier 3
 standby 10 bfd

14 — FHRP Delay on Boot

Prevent a switch from becoming Active/Master before routing adjacencies are fully formed after a reload:

! Global FHRP delay (IOS-XE 16.x+)
fhrp delay minimum 30 reload 120

This delays FHRP initialization by 30 seconds (or 120 seconds after a full reload).

15 — Choosing Between HSRP and VRRP

Criteria	Use HSRP	Use VRRP
All-Cisco environment	✅ Preferred — tighter integration, ISSU support	Works, but no extra benefit
Multi-vendor environment	❌ Proprietary	✅ Standards-based
Need >255 groups per interface	✅ HSRPv2 supports 0-4095	❌ Max 255
Sub-second failover	✅ With BFD or msec timers	✅ With BFD or msec timers
IPv6 support	✅ HSRPv2	✅ VRRPv3

16 — Full Production Template: HSRPv2 with Tracking and BFD

! ============================================
! sw-infrarunbook-01 — HSRPv2 Production Config
! ============================================
!
fhrp delay minimum 30 reload 120
!
ip sla 1
 icmp-echo 203.0.113.1 source-ip 10.10.10.2
 frequency 5
ip sla schedule 1 life forever start-time now
!
track 1 interface GigabitEthernet1/0/1 line-protocol
track 2 ip sla 1 reachability
 delay down 10 up 30
!
track 10 list boolean and
 object 1
 object 2
!
interface Vlan10
 description infrarunbook-prod | HSRP Active
 ip address 10.10.10.2 255.255.255.0
 bfd interval 50 min_rx 50 multiplier 3
 standby version 2
 standby 10 ip 10.10.10.1
 standby 10 priority 110
 standby 10 preempt delay minimum 30 reload 60
 standby 10 timers msec 250 msec 750
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026
 standby 10 track 10 decrement 30
 standby 10 bfd
 standby 10 name INFRARUNBOOK-GW
 no shutdown

! ============================================
! sw-infrarunbook-02 — HSRPv2 Production Config
! ============================================
!
fhrp delay minimum 30 reload 120
!
ip sla 1
 icmp-echo 203.0.113.1 source-ip 10.10.10.3
 frequency 5
ip sla schedule 1 life forever start-time now
!
track 1 interface GigabitEthernet1/0/1 line-protocol
track 2 ip sla 1 reachability
 delay down 10 up 30
!
track 10 list boolean and
 object 1
 object 2
!
interface Vlan10
 description infrarunbook-prod | HSRP Standby
 ip address 10.10.10.3 255.255.255.0
 bfd interval 50 min_rx 50 multiplier 3
 standby version 2
 standby 10 ip 10.10.10.1
 standby 10 priority 90
 standby 10 preempt delay minimum 30 reload 60
 standby 10 timers msec 250 msec 750
 standby 10 authentication md5 key-string 0 Infr@RunB00k!2026
 standby 10 track 10 decrement 30
 standby 10 bfd
 standby 10 name INFRARUNBOOK-GW
 no shutdown

17 — Frequently Asked Questions (FAQ)

Q1: What is the default HSRP priority and how does election work?

The default HSRP priority is 100. The router with the highest priority becomes Active. If priorities are equal, the router with the highest IP address on the HSRP interface wins.

Q2: Why do I see both routers as HSRP Active?

This is a "split-brain" scenario, usually caused by HSRP hellos not reaching the peer. Common causes: VLAN not trunked between switches, mismatched HSRP version, mismatched authentication, or an ACL/firewall blocking multicast 224.0.0.2 (v1) or 224.0.0.102 (v2) UDP port 1985.

Q3: Does VRRP preempt by default?

Yes. Unlike HSRP, VRRP has preemption enabled by default. You must explicitly configure

no vrrp 10 preempt

if you want to disable it.

Q4: Can I use the virtual IP as the real interface IP in VRRP?

Yes. In VRRP, if a router's real IP matches the virtual IP, it becomes the "owner" with an automatic priority of 255 and always wins the election. This is not possible with HSRP — the virtual IP must be different from any real IP.

Q5: What is the preempt delay and why should I use it?

Preempt delay introduces a waiting period before a recovered router takes back the Active/Master role. This ensures routing tables (OSPF, EIGRP, BGP) have converged before the router starts forwarding traffic. A typical value is 30-60 seconds for minimum and 60-120 seconds for reload delay.

Q6: Can HSRP and VRRP run on the same interface?

Technically yes — they are independent protocols. However, this creates unnecessary complexity and potential confusion. Best practice: choose one FHRP per interface and be consistent across the network.

Q7: How fast can HSRP failover be?

With millisecond timers (e.g., hello 250 ms, hold 750 ms), failover can occur in under 1 second. With BFD integration (

standby 10 bfd

), detection can be as fast as 150 ms (50 ms × 3 multiplier).

Q8: Does VRRPv3 support authentication?

No. RFC 5798 explicitly removed authentication from VRRPv3, stating it provided a false sense of security. Protect VRRPv3 with infrastructure ACLs, CoPP, and securing access to the Layer 2 domain.

Q9: How do I achieve active/active load balancing with HSRP?

Create two (or more) HSRP groups on the same interface, each with a different virtual IP. Assign different groups as Active on different routers. Distribute clients across the virtual IPs via DHCP pools or DNS round-robin.

Q10: What happens if the tracked interface flaps rapidly?

Without dampening, HSRP/VRRP priority will fluctuate, causing repeated failovers. Use

track delay down 10 up 30

to require the tracked object to be down for 10 seconds before decrementing and up for 30 seconds before restoring priority.

18 — Quick Reference: All Commands at a Glance

! HSRP Show
show standby
show standby brief
show standby vlan 10 10
show track
show track brief

! VRRP Show
show vrrp
show vrrp brief
show vrrp interface vlan 10

! HSRP Debug
debug standby events
debug standby packets

! VRRP Debug
debug vrrp events
debug vrrp packets

! Clear
clear standby vlan 10 10

! BFD Verify
show bfd neighbors
show bfd neighbors details

Revision: 2026-02-17 — Initial publication for IOS 15.x and IOS-XE 16.x/17.x platforms.
