Envoy Access Log Not Writing

Symptoms

You've deployed Envoy — maybe as a sidecar, maybe as a standalone edge proxy in front of your backend services — and the access log file is completely silent. Requests are flowing through. You can see upstream metrics climbing on the admin endpoint at

:9901/stats

. But

/var/log/envoy/access.log

stays at zero bytes, or the file doesn't exist at all.

Sometimes the file gets created at startup and then nothing ever lands in it. Other times it's absent entirely. You tail it, you watch it, curl a few requests through, and still nothing. No errors from Envoy itself, no obvious crash, just dead silence from a log sink that should be chatty.

In Kubernetes environments this can be even more confusing — the pod looks healthy, the service responds, but the log path is on a hostPath volume that appears mounted yet never accumulates entries. This guide covers every common reason this happens, how to identify each one quickly, and how to fix it without guessing.

---

Root Cause 1: Access Log Path Wrong

Why it happens: Envoy's access log destination is configured inside the bootstrap file or pushed via xDS, and a simple typo in the path is more common than it sounds. A path like

/var/log/enovy/access.log

instead of

/var/log/envoy/access.log

will cause Envoy to attempt writes to a nonexistent directory. In older Envoy releases this failure was silent — the log just never materialized and the process kept running. Newer builds do surface this at startup, but only if you're watching stderr closely.

How to identify it: Start by confirming the directory actually exists on the host.

ls -la /var/log/envoy/

If you get back:

ls: cannot access '/var/log/envoy/': No such file or directory

That's your answer. To confirm what path Envoy thinks it's writing to, pull the live config dump:

curl -s http://127.0.0.1:9901/config_dump | python3 -m json.tool | grep -A 8 "access_log"

You might see something like this buried inside the listener config:

"access_log": [
  {
    "name": "envoy.access_loggers.file",
    "typed_config": {
      "@type": "type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog",
      "path": "/var/log/enovy/access.log"
    }
  }
]

There it is —

enovy

instead of

envoy

. Also check startup stderr for any path-related errors:

journalctl -u envoy --no-pager | grep -iE "access_log|path|error" | head -30

In a container environment:

docker logs envoy-proxy 2>&1 | grep -iE "access|path|error" | head -30

How to fix it: Create the missing directory and assign ownership, then correct the config.

mkdir -p /var/log/envoy
chown envoy:envoy /var/log/envoy

In your

envoy.yaml

, find and correct the path. Before:

access_log:
  - name: envoy.access_loggers.file
    typed_config:
      "@type": type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog
      path: /var/log/enovy/access.log

After:

access_log:
  - name: envoy.access_loggers.file
    typed_config:
      "@type": type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog
      path: /var/log/envoy/access.log

Reload Envoy and verify a log line appears immediately:

kill -HUP $(pgrep envoy)
curl -s http://127.0.0.1:8080/
tail -5 /var/log/envoy/access.log

---

Root Cause 2: Permission Denied

Why it happens: Envoy runs as a non-root user — commonly

envoy

(UID 1337 in Istio setups) or a dedicated service account — and the log directory was created or locked down by root without granting write access to the service user. I've seen this happen repeatedly after security hardening passes where someone sets

/var/log

subdirectories to

700 root:root

and doesn't account for which services need write access.

How to identify it: Check what user Envoy is running as:

ps aux | grep envoy

envoy   1423  0.4  1.2 348920 24576 ?  Ssl  14:21   0:05 /usr/local/bin/envoy -c /etc/envoy/envoy.yaml

Now check the directory permissions:

ls -la /var/log/ | grep envoy

drwxr-x--- 2 root root 4096 Apr 19 14:00 envoy

Mode

750

, owned by root. The

envoy

user has execute but not write access. You can confirm this definitively with:

sudo -u envoy touch /var/log/envoy/test.log

touch: cannot touch '/var/log/envoy/test.log': Permission denied

If Envoy surfaces this at startup, the critical log line looks like:

[2026-04-19 14:21:33.412][1][critical][main] [source/server/server.cc:888]
  error initializing access log file '/var/log/envoy/access.log': Permission denied

How to fix it: The cleanest fix is correcting ownership on the log directory:

chown envoy:envoy /var/log/envoy
chmod 755 /var/log/envoy

If the log file itself was previously created by root while the process was running as root:

chown envoy:envoy /var/log/envoy/access.log

In Kubernetes with a hostPath volume, the node-level directory must be writable by the UID set in

securityContext.runAsUser

. An init container handles this cleanly:

initContainers:
- name: fix-log-perms
  image: busybox:1.36
  command: ["sh", "-c", "mkdir -p /var/log/envoy && chmod 777 /var/log/envoy"]
  volumeMounts:
  - name: envoy-logs
    mountPath: /var/log/envoy

After fixing permissions, verify the write test passes before reloading Envoy:

sudo -u envoy touch /var/log/envoy/writetest && echo "Write OK" && rm /var/log/envoy/writetest

---

Root Cause 3: Filter Not Configured

Why it happens: This is the most common root cause I encounter, and it catches engineers who are transitioning to Envoy from other proxies where logging is a global setting. In Envoy, access logging is not global. It lives inside the

HttpConnectionManager

(HCM) filter chain on each individual listener, or inside the

tcp_proxy

filter for TCP listeners. If you define a route, configure a cluster, and wire up the listener but forget to add the

access_log

stanza inside the HCM block, you'll get exactly zero log entries. No errors, no warnings — the proxy works perfectly, requests route correctly, nothing gets logged.

How to identify it: Pull the config dump and look at what's inside each HCM block:

curl -s http://127.0.0.1:9901/config_dump | python3 -m json.tool > /tmp/envoy-config.json
grep -n "http_connection_manager\|access_log" /tmp/envoy-config.json | head -40

If you see

http_connection_manager

sections with no

access_log

key underneath them, that's the problem. A listener without logging configured looks like this:

{
  "name": "envoy.filters.network.http_connection_manager",
  "typed_config": {
    "@type": "type.googleapis.com/envoy.extensions.filters.network.http_connection_manager.v3.HttpConnectionManager",
    "stat_prefix": "ingress_http",
    "route_config": { "..." },
    "http_filters": ["..."]
  }
}

No

access_log

key. Compare that to a correctly configured HCM:

{
  "name": "envoy.filters.network.http_connection_manager",
  "typed_config": {
    "@type": "...",
    "stat_prefix": "ingress_http",
    "access_log": [
      {
        "name": "envoy.access_loggers.file",
        "typed_config": {
          "@type": "type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog",
          "path": "/var/log/envoy/access.log"
        }
      }
    ],
    "route_config": { "..." },
    "http_filters": ["..."]
  }
}

How to fix it: Add the

access_log

stanza directly inside the HCM

typed_config

block in your YAML. Here's the complete minimal correct structure:

- name: envoy.filters.network.http_connection_manager
  typed_config:
    "@type": type.googleapis.com/envoy.extensions.filters.network.http_connection_manager.v3.HttpConnectionManager
    stat_prefix: ingress_http
    access_log:
      - name: envoy.access_loggers.file
        typed_config:
          "@type": type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog
          path: /var/log/envoy/access.log
    route_config:
      name: local_route
      virtual_hosts:
        - name: backend
          domains: ["*"]
          routes:
            - match: { prefix: "/" }
              route: { cluster: backend_cluster }
    http_filters:
      - name: envoy.filters.http.router
        typed_config:
          "@type": type.googleapis.com/envoy.extensions.filters.http.router.v3.Router

After updating and reloading, send a test request and confirm the log file gets written:

kill -HUP $(pgrep envoy)
curl -s http://192.168.1.100:8080/health
tail -1 /var/log/envoy/access.log

---

Root Cause 4: Format String Error

Why it happens: Envoy supports custom access log formats through the

log_format

block using either

text_format_source

or

json_format

. A malformed command operator — for example

%REQ(:AUTHORITY%

instead of

%REQ(:AUTHORITY)%

, with the closing parenthesis missing — will usually cause Envoy to reject the config at startup. But subtler format errors are more insidious. An invalid operator in a

json_format

block may pass YAML syntax validation yet fail at Envoy's internal config parsing stage, causing the access logger to be skipped entirely without a clean error message bubbling up to the surface.

In my experience, the JSON format variant is where engineers run into the most trouble. People copy operator strings from blog posts written against Envoy v2 and paste them into v3 configs where the operator names have changed, or they build format strings dynamically in Helm templates and introduce rendering artifacts like unclosed brackets.

How to identify it: Check startup output first:

journalctl -u envoy --no-pager -n 100 | grep -iE "error|invalid|format|access_log"

A format parse error at startup looks like:

[2026-04-19 14:35:10.112][1][critical][main] [source/extensions/access_loggers/common/access_log_impl.cc:42]
  error: invalid access log format string: unexpected end of format string
  at position 22 in '%REQ(:AUTHORITY%'

Always validate your config file before deploying:

envoy --mode validate -c /etc/envoy/envoy.yaml 2>&1

Output on a bad format string:

error initializing configuration '/etc/envoy/envoy.yaml':
  Field 'json_format' has invalid operator '%START_TIME(%Y-%m-%dT%H:%M:%S%'
  - unmatched parenthesis

If validation passes, double-check for subtle v2-to-v3 naming discrepancies:

grep -n "RESPONS_CODE\|UPSTREAM_CLUSER\|DURATION_MS" /etc/envoy/envoy.yaml

How to fix it: The most common mistakes are missing closing parentheses in

%START_TIME(...)%

, misspelled operator names like

%RESPONS_CODE%

(missing the E), and v2 operator names used in v3 configs. A correct minimal text format string:

typed_config:
  "@type": type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog
  path: /var/log/envoy/access.log
  log_format:
    text_format_source:
      inline_string: "[%START_TIME%] \"%REQ(:METHOD)% %REQ(X-ENVOY-ORIGINAL-PATH?:PATH)% %PROTOCOL%\" %RESPONSE_CODE% %BYTES_SENT% \"%REQ(:AUTHORITY)%\" %DURATION%\n"

A correct JSON format block:

typed_config:
  "@type": type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog
  path: /var/log/envoy/access.log
  log_format:
    json_format:
      timestamp: "%START_TIME%"
      method: "%REQ(:METHOD)%"
      path: "%REQ(X-ENVOY-ORIGINAL-PATH?:PATH)%"
      response_code: "%RESPONSE_CODE%"
      duration_ms: "%DURATION%"
      upstream_host: "%UPSTREAM_HOST%"

Always validate before applying:

envoy --mode validate -c /etc/envoy/envoy.yaml && echo "Config is valid"

---

Root Cause 5: Disk Full

Why it happens: When the filesystem holding

/var/log

reaches 100% capacity, Envoy can't write new log entries. The process keeps running, requests proxy without issue, but every write syscall to the log file returns

ENOSPC

and the entry is silently dropped. There's no Envoy-level alerting on this condition — the proxy doesn't crash, it doesn't emit a warning to stderr, the log file just stops accumulating new lines. In long-running environments without proper log rotation this is surprisingly common, especially when access log verbosity is high and request volume is heavy.

How to identify it:

df -h /var/log/envoy/

Filesystem      Size  Used Avail Use% Mounted on
/dev/sda1        20G   20G     0 100% /

Confirm a write from the Envoy user fails:

sudo -u envoy dd if=/dev/zero of=/var/log/envoy/writetest bs=1k count=1

dd: error writing '/var/log/envoy/writetest': No space left on device
0+0 records in
0+0 records out

Find what's consuming the space:

du -sh /var/log/* | sort -rh | head -20
ls -lhS /var/log/envoy/

How to fix it: First, free up space immediately so logging can resume. Don't remove the open file while Envoy has it open — truncate it instead:

# Truncate the current log file safely (Envoy keeps the file descriptor open)
> /var/log/envoy/access.log

# Compress any rotated logs that are still uncompressed
gzip /var/log/envoy/access.log.1 2>/dev/null

# Remove old compressed logs if safe to do so
find /var/log/envoy/ -name "*.gz" -mtime +14 -delete

Then configure logrotate to prevent this from happening again. Create

/etc/logrotate.d/envoy

on

sw-infrarunbook-01

:

/var/log/envoy/access.log {
    daily
    rotate 7
    compress
    delaycompress
    missingok
    notifempty
    sharedscripts
    postrotate
        kill -USR1 $(pgrep envoy) 2>/dev/null || true
    endscript
}

Test the logrotate config:

logrotate -d /etc/logrotate.d/envoy

For Kubernetes, ship logs off-node with Fluent Bit or Fluentd as a DaemonSet and set a

terminationMessagePath

and ephemeral storage limit on the pod to prevent runaway log growth from filling node disk.

---

Root Cause 6: Access Log Filter Blocking All Entries

Why it happens: Envoy access log configurations support runtime filter conditions — you can restrict logging to only certain HTTP status codes, minimum durations, or a random sampling fraction. These filters are a powerful way to reduce log volume in high-traffic environments. But if someone added a filter with an overly aggressive condition — or introduced a typo that makes the filter unmatchable — you end up with a perfectly configured access logger that never emits a single line.

How to identify it: Look for a

filter

key inside the

access_log

stanza in the config dump:

curl -s http://127.0.0.1:9901/config_dump | python3 -m json.tool | grep -B2 -A20 '"access_log"'

A misconfigured filter that will never match looks like this:

"access_log": [
  {
    "name": "envoy.access_loggers.file",
    "filter": {
      "status_code_filter": {
        "comparison": {
          "op": "GE",
          "value": {
            "default_value": 9999,
            "runtime_key": "access_log.min_status_code"
          }
        }
      }
    },
    "typed_config": { "..." }
  }
]

A

status_code_filter

with

GE 9999

will never match any real HTTP status code. Nothing gets logged. Similarly, a

runtime_fraction

filter with

numerator: 0

will sample zero percent of requests.

How to fix it: If you want to log everything, remove the

filter

block entirely. If you want selective logging, correct the filter. To log only 5xx responses:

access_log:
  - name: envoy.access_loggers.file
    filter:
      status_code_filter:
        comparison:
          op: GE
          value:
            default_value: 500
            runtime_key: access_log.min_status_code
    typed_config:
      "@type": type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog
      path: /var/log/envoy/access.log

To log all requests without filtering, the stanza has no

filter

key at all — just

name

and

typed_config

.

---

Root Cause 7: Extension Not Registered or Wrong API Version

Why it happens: Envoy's v3 API requires the correct

@type

URL for every

typed_config

block. If you copy a config from an older blog post targeting the v2 API, or use a custom-built Envoy image with the file access logger extension disabled, the logger simply won't initialize. This is less common than the other causes but I have seen it in environments running stripped-down Envoy builds for binary size or CVE-surface reasons.

How to identify it: Check what Envoy version and extensions are present:

envoy --version
curl -s http://127.0.0.1:9901/server_info | python3 -m json.tool | grep -i "access_log"

If the file access logger extension isn't listed in

server_info

, it wasn't compiled in. Startup stderr will show:

[critical] Didn't find a registered implementation for type:
  'envoy.extensions.access_loggers.file.v3.FileAccessLog'

Also check that you're using the correct v3

@type

string:

grep -n "@type" /etc/envoy/envoy.yaml | grep access

The correct v3 type URL is:

type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog

Not the old v2 path, which was

envoy.file_access_log

as a string name rather than a typed URL.

How to fix it: Update the

@type

to the correct v3 URL shown above. If the extension genuinely isn't compiled in, switch to an official Envoy image which always includes all standard extensions:

docker pull envoyproxy/envoy:v1.29-latest
docker run --rm envoyproxy/envoy:v1.29-latest envoy --version

---

Prevention

Most of these failures are preventable with a few consistent practices. The single most effective habit is running

envoy --mode validate

against every config change before deploying it anywhere — this catches format string errors, wrong type URLs, and structural mistakes that would otherwise only surface at runtime.

envoy --mode validate -c /etc/envoy/envoy.yaml && echo "Config OK"

For path and permission issues, add a smoke test to your deployment pipeline that sends one request immediately after Envoy starts and checks that the log file has grown:

BEFORE=$(stat -c %s /var/log/envoy/access.log 2>/dev/null || echo 0)
curl -s http://192.168.1.100:8080/healthz > /dev/null
sleep 1
AFTER=$(stat -c %s /var/log/envoy/access.log 2>/dev/null || echo 0)
[ "$AFTER" -gt "$BEFORE" ] && echo "Logging OK" || echo "WARNING: log file did not grow"

Set up logrotate from day one — not after the first disk-full incident. Mount the log directory on a dedicated partition with a fixed size and a

df

-based alert at 80% capacity. In Kubernetes, set ephemeral storage limits and run a log shipping DaemonSet so logs leave the node before they fill it.

Monitor the

access_log.log_count

stat via the admin API. If requests are flowing but this counter stays flat, something is wrong with the log sink:

curl -s http://127.0.0.1:9901/stats | grep access_log

Finally, keep access log configs explicit. Don't inherit log settings from a shared base config if you don't fully understand what's in it, and always confirm after each config change that log entries are actually appearing before you declare the deployment successful. Two minutes of verification after a deploy saves hours of debugging later.
