    Introduction

    Spanning Tree Protocol (STP) is the foundational Layer 2 loop-prevention mechanism in every Cisco switched network. A single misconfiguration can cause broadcast storms that take down an entire campus in seconds. This run book covers every STP variant you will encounter on Cisco Catalyst switches — Classic STP (IEEE 802.1D), Rapid STP (IEEE 802.1w / Rapid PVST+), and Multiple Spanning Tree (IEEE 802.1s / MST) — with real commands, production configs, hardening best practices, and troubleshooting procedures for IOS 15.x and IOS-XE 16.x/17.x.


    1 — STP Fundamentals Refresher

    1.1 Why STP Exists

    Redundant Layer 2 links create switching loops. Without STP, a single broadcast frame is replicated endlessly, saturating bandwidth and crashing MAC address tables. STP builds a loop-free logical topology by electing a Root Bridge, calculating shortest paths, and placing redundant ports into a Blocking state.

    1.2 Key Terminology

    • Bridge ID (BID) — 2-byte priority + 48-bit MAC address. Lowest BID wins the Root Bridge election.
    • Root Port (RP) — The port on every non-root switch with the lowest cost path to the Root Bridge.
    • Designated Port (DP) — The port on each segment that forwards traffic toward the Root Bridge.
    • Alternate Port / Backup Port — Redundant ports placed in Blocking (STP) or Discarding (RSTP) state.
    • BPDU (Bridge Protocol Data Unit) — Frames exchanged between switches to build and maintain the tree.
    • Path Cost — Cumulative cost of links to reach the Root Bridge (lower is better).

    1.3 IEEE STP Path Cost Defaults (Short Mode)

    Link Speed    Short Cost    Long Cost
    --------------------------------------
    10 Mbps       100           2,000,000
    100 Mbps      19            200,000
    1 Gbps        4             20,000
    10 Gbps       2             2,000
    25 Gbps       —             800
    40 Gbps       —             500
    100 Gbps      —             200

    IOS uses short mode by default. IOS-XE 16.x+ and NX-OS use long mode. You can change this with

    spanning-tree pathcost method long
    .


    2 — STP Variants on Cisco Platforms

    VariantStandardCisco NamePer-VLAN?Convergence
    Classic STP802.1D-1998PVST+Yes30-50 sec
    Rapid STP802.1wRapid PVST+Yes1-2 sec
    Multiple STP802.1sMSTInstances (groups of VLANs)1-2 sec

    Recommendation: Use Rapid PVST+ for campus access/distribution layers. Use MST when you have hundreds of VLANs and need to reduce STP instance overhead.


    3 — Setting the STP Mode

    3.1 Rapid PVST+ (Recommended Default)

    Switch(config)# spanning-tree mode rapid-pvst

    This is a global command that affects all VLANs. All ports begin using 802.1w BPDUs immediately. Rapid PVST+ is backward-compatible with legacy 802.1D switches on a per-port basis — if a port receives legacy BPDUs it falls back to classic STP on that port.

    3.2 MST

    Switch(config)# spanning-tree mode mst

    3.3 Classic PVST+ (Legacy)

    Switch(config)# spanning-tree mode pvst

    Avoid classic PVST+ in new deployments. The 30-50 second convergence is unacceptable for modern networks.


    4 — Root Bridge Election and Tuning

    4.1 Designing Root Placement

    The Root Bridge should always be your distribution or core switch — never an access switch. Configure a primary root on one distribution switch and a secondary root on the other.

    4.2 Using the Macro Command

    ! Distribution Switch 1 — Primary Root
    DS1(config)# spanning-tree vlan 1,10,20,30 root primary

    ! Distribution Switch 2 — Secondary Root
    DS2(config)# spanning-tree vlan 1,10,20,30 root secondary

    The

    root primary
    macro sets the priority to 24576 (or 4096 less than the current root if it is already below 24576). The
    root secondary
    macro sets the priority to 28672.

    4.3 Manual Priority Assignment

    For deterministic control, set the priority manually. Priority must be a multiple of 4096 (0, 4096, 8192, … 61440).

    ! Make this switch the root for VLAN 10
    DS1(config)# spanning-tree vlan 10 priority 4096

    ! Make this switch the backup root for VLAN 10
    DS2(config)# spanning-tree vlan 10 priority 8192

    4.4 Load Balancing Across Distribution Pair

    Split VLANs across two root bridges to distribute traffic across uplinks:

    ! DS1 is root for odd VLANs
    DS1(config)# spanning-tree vlan 1,11,13,15,17,19 priority 4096
    DS1(config)# spanning-tree vlan 10,12,14,16,18,20 priority 8192

    ! DS2 is root for even VLANs
    DS2(config)# spanning-tree vlan 10,12,14,16,18,20 priority 4096
    DS2(config)# spanning-tree vlan 1,11,13,15,17,19 priority 8192

    4.5 Tuning Port Cost and Port Priority

    ! Override port cost on a specific interface
    Switch(config)# interface GigabitEthernet1/0/1
    Switch(config-if)# spanning-tree vlan 10 cost 2

    ! Override port priority (lower = preferred)
    Switch(config-if)# spanning-tree vlan 10 port-priority 64

    5 — STP Timers

    Default timers (set on the Root Bridge and propagated via BPDUs):

    Hello Time:      2 seconds
    Forward Delay:  15 seconds
    Max Age:        20 seconds

    To modify (only on the Root Bridge):

    DS1(config)# spanning-tree vlan 10 hello-time 1
    DS1(config)# spanning-tree vlan 10 forward-time 10
    DS1(config)# spanning-tree vlan 10 max-age 14
    Warning: Reducing timers increases CPU/BPDU overhead. Only tune timers if you understand the diameter formula:
    Max Age >= 2 × (Hello Time + 1)
    and
    Forward Delay >= (Max Age / 2) + 1
    . In most cases, leave timers at defaults and use Rapid PVST+ for fast convergence instead.

    6 — PortFast and Edge Ports

    6.1 PortFast on Access Ports

    PortFast skips the Listening and Learning states, bringing the port to Forwarding immediately. Use it only on ports connected to end hosts — never on switch-to-switch links.

    ! Per-interface
    Switch(config)# interface GigabitEthernet1/0/24
    Switch(config-if)# switchport mode access
    Switch(config-if)# switchport access vlan 10
    Switch(config-if)# spanning-tree portfast

    ! Global default for all access ports
    Switch(config)# spanning-tree portfast default

    With

    spanning-tree portfast default
    , every access port automatically gets PortFast. Trunk ports are excluded.

    6.2 PortFast on Trunk Ports (Use with Caution)

    Switch(config)# interface GigabitEthernet1/0/48
    Switch(config-if)# switchport mode trunk
    Switch(config-if)# spanning-tree portfast trunk

    This is sometimes needed for servers with 802.1Q trunks (e.g., VMware ESXi hosts), but always pair it with BPDU Guard.


    7 — STP Protection Mechanisms

    7.1 BPDU Guard

    If a PortFast-enabled port receives a BPDU, BPDU Guard immediately puts it into err-disabled state — preventing rogue switches from disrupting the topology.

    ! Global (recommended)
    Switch(config)# spanning-tree portfast bpduguard default

    ! Per-interface
    Switch(config-if)# spanning-tree bpduguard enable

    To auto-recover err-disabled ports:

    Switch(config)# errdisable recovery cause bpduguard
    Switch(config)# errdisable recovery interval 300

    7.2 BPDU Filter

    BPDU Filter suppresses BPDU transmission and reception on a port. Use with extreme caution — it effectively disables STP on that port.

    ! Per-interface only (global + portfast default has different behavior)
    Switch(config-if)# spanning-tree bpdufilter enable
    Best Practice: Prefer BPDU Guard over BPDU Filter. BPDU Filter can create undetected loops.

    7.3 Root Guard

    Root Guard prevents a port from becoming a Root Port. If superior BPDUs are received, the port enters root-inconsistent (blocking) state. Deploy on distribution switch downlinks toward access switches.

    Switch(config)# interface range GigabitEthernet1/0/1 - 24
    Switch(config-if-range)# spanning-tree guard root

    7.4 Loop Guard

    Loop Guard detects unidirectional link failures. If BPDUs stop arriving on a non-designated port, Loop Guard places the port into loop-inconsistent state instead of transitioning to Forwarding.

    ! Global (recommended)
    Switch(config)# spanning-tree loopguard default

    ! Per-interface
    Switch(config-if)# spanning-tree guard loop
    Note: Root Guard and Loop Guard are mutually exclusive on the same port. Use Root Guard on downlinks (distribution → access) and Loop Guard on interswitch links (redundant uplinks).

    7.5 UDLD (Unidirectional Link Detection)

    UDLD works alongside Loop Guard to detect unidirectional fiber failures:

    ! Enable aggressive UDLD globally on fiber ports
    Switch(config)# udld aggressive

    ! Per-interface
    Switch(config)# interface TenGigabitEthernet1/1/1
    Switch(config-if)# udld port aggressive

    8 — Rapid PVST+ Deep Dive

    8.1 Port Roles in RSTP

    • Root Port — Best path to Root Bridge (same as classic STP).
    • Designated Port — Forwards traffic on a segment (same as classic STP).
    • Alternate Port — Backup path to the Root Bridge (replaces Blocking port). Provides fast failover for Root Port loss.
    • Backup Port — Redundant path on the same switch to the same segment (rare).

    8.2 Port States in RSTP

    Classic STP          RSTP
    -----------          --------
    Disabled      →      Discarding
    Blocking      →      Discarding
    Listening     →      Discarding
    Learning      →      Learning
    Forwarding    →      Forwarding

    8.3 RSTP Convergence Mechanism

    RSTP achieves sub-second convergence through the proposal/agreement mechanism on point-to-point links. When a switch detects a link coming up, it sends a proposal BPDU. The downstream switch blocks all other ports and responds with an agreement, allowing the proposing port to move immediately to Forwarding — no timer waits.

    8.4 Link Type Configuration

    ! Force point-to-point (full-duplex links — usually auto-detected)
    Switch(config-if)# spanning-tree link-type point-to-point

    ! Force shared (half-duplex hub segments)
    Switch(config-if)# spanning-tree link-type shared

    The proposal/agreement mechanism only works on point-to-point links. Shared links fall back to classic timer-based convergence.


    9 — MST (Multiple Spanning Tree) Configuration

    9.1 When to Use MST

    With hundreds of VLANs, Rapid PVST+ runs a separate STP instance per VLAN, consuming significant CPU and memory. MST maps multiple VLANs to a smaller number of instances, reducing overhead.

    9.2 MST Region Configuration

    All switches in the same MST region must have identical region name, revision number, and VLAN-to-instance mapping.

    Switch(config)# spanning-tree mode mst

    Switch(config)# spanning-tree mst configuration
    Switch(config-mst)# name CAMPUS-MST
    Switch(config-mst)# revision 1
    Switch(config-mst)# instance 1 vlan 1-100
    Switch(config-mst)# instance 2 vlan 101-200
    Switch(config-mst)# instance 3 vlan 201-500
    Switch(config-mst)# exit

    VLANs not explicitly mapped go to Instance 0 (IST — Internal Spanning Tree).

    9.3 MST Root Bridge Election

    ! DS1 is root for Instance 1, backup for Instance 2
    DS1(config)# spanning-tree mst 1 priority 4096
    DS1(config)# spanning-tree mst 2 priority 8192

    ! DS2 is root for Instance 2, backup for Instance 1
    DS2(config)# spanning-tree mst 2 priority 4096
    DS2(config)# spanning-tree mst 1 priority 8192

    ! IST root (Instance 0)
    DS1(config)# spanning-tree mst 0 priority 4096

    9.4 Verifying MST Configuration

    Switch# show spanning-tree mst configuration
    Switch# show spanning-tree mst 1
    Switch# show spanning-tree mst 0 detail

    10 — Complete Production Configuration Example

    10.1 Distribution Switch 1 (DS1) — Rapid PVST+

    ! === Global STP Settings ===
    spanning-tree mode rapid-pvst
    spanning-tree pathcost method long
    spanning-tree portfast default
    spanning-tree portfast bpduguard default
    spanning-tree loopguard default
    spanning-tree vlan 1,10,20 priority 4096
    spanning-tree vlan 30,40,50 priority 8192

    ! === Uplinks to Core (Loop Guard via global default) ===
    interface range TenGigabitEthernet1/1/1 - 2
     description UPLINK-TO-CORE
     switchport mode trunk
     switchport trunk allowed vlan 1,10,20,30,40,50
     spanning-tree link-type point-to-point

    ! === Downlinks to Access Switches (Root Guard) ===
    interface range GigabitEthernet1/0/1 - 24
     description DOWNLINK-TO-ACCESS
     switchport mode trunk
     switchport trunk allowed vlan 1,10,20,30,40,50
     spanning-tree guard root

    ! === UDLD on Fiber Uplinks ===
    udld aggressive

    ! === Err-disable Recovery ===
    errdisable recovery cause bpduguard
    errdisable recovery cause udld
    errdisable recovery interval 300

    10.2 Access Switch Configuration

    ! === Global STP Settings ===
    spanning-tree mode rapid-pvst
    spanning-tree pathcost method long
    spanning-tree portfast default
    spanning-tree portfast bpduguard default
    spanning-tree loopguard default

    ! Leave priority at default (32768) — never root

    ! === Uplinks to Distribution ===
    interface range GigabitEthernet1/0/49 - 50
     description UPLINK-TO-DISTRIBUTION
     switchport mode trunk
     switchport trunk allowed vlan 1,10,20,30,40,50
     spanning-tree link-type point-to-point

    ! === Access Ports (PortFast + BPDU Guard via global) ===
    interface range GigabitEthernet1/0/1 - 48
     description USER-ACCESS
     switchport mode access
     switchport access vlan 10

    ! === Err-disable Recovery ===
    errdisable recovery cause bpduguard
    errdisable recovery interval 300

    11 — Verification and Show Commands

    11.1 STP Status Overview

    Switch# show spanning-tree
    Switch# show spanning-tree summary
    Switch# show spanning-tree vlan 10
    Switch# show spanning-tree vlan 10 detail

    11.2 Root Bridge Information

    Switch# show spanning-tree root

                                            Root    Hello Max Fwd
    Vlan                Root ID             Cost    Time  Age Dly  Root Port
    ------------------- -------------------- ------- ----- --- ---  --------
    VLAN0001            4097 aabb.cc00.0100        0    2  20  15
    VLAN0010            4106 aabb.cc00.0100        0    2  20  15
    VLAN0020            4116 aabb.cc00.0100        0    2  20  15

    11.3 Port Role and State

    Switch# show spanning-tree interface GigabitEthernet1/0/1 detail

     Port 1 (GigabitEthernet1/0/1) of VLAN0010 is designated forwarding
       Port path cost 20000, Port priority 128, Port Identifier 128.1.
       Designated root has priority 4106, address aabb.cc00.0100
       Designated bridge has priority 32778, address aabb.cc00.0200
       Number of transitions to forwarding state: 3
       Link type is point-to-point by default
       BPDU: sent 14523, received 0

    11.4 PortFast and Guard Status

    Switch# show spanning-tree summary totals

    Switch is in rapid-pvst mode
    Root bridge for: none

                             Portfast Default            is enabled
                             Portfast BPDU Guard Default  is enabled
                             Portfast BPDU Filter Default is disabled
                             Loopguard Default            is enabled

    Name                   Blocking Listening Learning Forwarding STP Active
    ---------------------- -------- --------- -------- ---------- ----------
    6 vlans                     2         0        0         50        52

    11.5 Inconsistent Ports

    Switch# show spanning-tree inconsistentports

    Name                 Interface              Inconsistency
    -------------------- ---------------------- ------------------
    VLAN0010             GigabitEthernet1/0/5   Root Inconsistent

    Number of inconsistent ports (segments) in the system : 1

    11.6 BPDU Counters

    Switch# show spanning-tree interface GigabitEthernet1/0/1 portfast
    Switch# show spanning-tree detail | include BPDU
    Switch# show spanning-tree vlan 10 bridge

    12 — Troubleshooting STP Issues

    12.1 Broadcast Storm / MAC Flapping

    1. Identify the symptom:
      show interfaces counters errors
      ,
      show mac address-table count
      — MAC table full.
    2. Check for loops:
      show spanning-tree blockedports
      — if empty, STP may have converged incorrectly.
    3. Check for err-disabled ports:
      show interfaces status err-disabled
      .
    4. Inspect BPDUs:
      show spanning-tree detail | include BPDU|from
      .
    5. Verify root bridge:
      show spanning-tree root
      — is an access switch the root?

    12.2 Root Bridge on Wrong Switch

    ! Identify current root
    Switch# show spanning-tree vlan 10 | include Root

    ! Fix: Lower priority on the correct switch
    DS1(config)# spanning-tree vlan 10 priority 0

    12.3 Port Stuck in Blocking

    ! Check port role and reason
    Switch# show spanning-tree interface Gi1/0/1 detail

    ! If loop-inconsistent, check for unidirectional link
    Switch# show udld interface Gi1/0/1

    ! Clear loop guard inconsistency (after fixing the link)
    Switch(config)# interface Gi1/0/1
    Switch(config-if)# shutdown
    Switch(config-if)# no shutdown

    12.4 Err-Disabled Recovery

    ! Check err-disabled status
    Switch# show errdisable recovery

    ! Manually recover a port
    Switch(config)# interface GigabitEthernet1/0/5
    Switch(config-if)# shutdown
    Switch(config-if)# no shutdown

    12.5 Debug Commands (Use Sparingly)

    Switch# debug spanning-tree events
    Switch# debug spanning-tree bpdu receive
    Switch# debug spanning-tree bpdu transmit

    ! Always disable when done
    Switch# undebug all

    13 — STP Hardening Checklist

    • ☐ Set STP mode to Rapid PVST+ or MST on all switches.
    • ☐ Manually assign Root Bridge priority on distribution/core switches.
    • ☐ Enable PortFast on all access ports (
      spanning-tree portfast default
      ).
    • ☐ Enable BPDU Guard globally (
      spanning-tree portfast bpduguard default
      ).
    • ☐ Enable Root Guard on all distribution downlinks toward access switches.
    • ☐ Enable Loop Guard globally (
      spanning-tree loopguard default
      ).
    • ☐ Enable UDLD aggressive on all fiber uplinks.
    • ☐ Configure errdisable recovery for bpduguard and udld with a 300-second interval.
    • ☐ Use long pathcost method for 10G+ links.
    • ☐ Document the Root Bridge for every VLAN in your network diagram.
    • ☐ Never leave STP priority at default on distribution/core switches.
    • ☐ Monitor STP topology changes via SNMP traps or syslog.

    14 — STP and EtherChannel Interaction

    When using EtherChannel (Port-Channel), STP treats the entire bundle as a single logical port. This is critical for proper load balancing and loop prevention.

    ! STP cost is based on the aggregate bandwidth
    Switch# show spanning-tree interface Port-channel1 detail

     Port 65 (Port-channel1) of VLAN0010 is designated forwarding
       Port path cost 3, Port priority 128, Port Identifier 128.65.
       Link type is point-to-point

    Important: If an EtherChannel misconfiguration causes individual links to come up without bundling, STP may see multiple individual links and block some — or worse, create a loop. Always verify channel status:

    show etherchannel summary
    .


    15 — Monitoring STP with SNMP and Syslog

    15.1 Syslog Messages to Watch

    %SPANTREE-2-ROOTGUARD_BLOCK: Root guard blocking port Gi1/0/5 on VLAN0010.
    %SPANTREE-2-LOOPGUARD_BLOCK: Loop guard blocking port Gi1/0/49 on VLAN0010.
    %PM-4-ERR_DISABLE: bpduguard error detected on Gi1/0/24, putting Gi1/0/24 in err-disable state
    %SPANTREE-2-BLOCK_PVID_LOCAL: Blocking port Gi1/0/1 on VLAN0001. Inconsistent local vlan.
    %STP-6-TOPOLOGY_CHANGE: Topology change detected on port Gi1/0/1 VLAN 10

    15.2 SNMP Traps

    Switch(config)# snmp-server enable traps bridge newroot topologychange
    Switch(config)# snmp-server host 10.0.0.50 version 2c COMMUNITY bridge

    Monitor

    topologychange
    traps — frequent TCN events indicate unstable ports (flapping links, rogue devices).


    16 — Platform-Specific Notes

    16.1 Catalyst 9000 (IOS-XE 17.x)

    • Default STP mode is Rapid PVST+.
    • Supports long pathcost method by default.
    • Enhanced
      show spanning-tree
      with priority in decimal + VLAN system ID extension.
    • Use
      spanning-tree extend system-id
      (enabled by default, cannot be disabled).

    16.2 Catalyst 3850/3650 (IOS-XE 16.x)

    • Same Rapid PVST+ behavior as Cat 9000.
    • Check hardware STP table:
      show platform software fed active fwd-asic resource stp
      .

    16.3 Catalyst 2960-X/XR (IOS 15.2)

    • Default mode is PVST+ (classic). Always change to
      rapid-pvst
      .
    • Short pathcost method by default.
    • Extended system ID is always enabled.

    17 — Quick Reference: Essential Commands

    ! View STP status
    show spanning-tree
    show spanning-tree summary
    show spanning-tree vlan 10
    show spanning-tree root
    show spanning-tree blockedports
    show spanning-tree inconsistentports
    show spanning-tree interface Gi1/0/1 detail
    show spanning-tree mst configuration
    show spanning-tree mst 1

    ! Configuration
    spanning-tree mode rapid-pvst
    spanning-tree vlan 10 root primary
    spanning-tree vlan 10 priority 4096
    spanning-tree portfast default
    spanning-tree portfast bpduguard default
    spanning-tree loopguard default
    spanning-tree pathcost method long
    spanning-tree guard root
    spanning-tree bpduguard enable
    udld aggressive

    ! Err-disable
    show interfaces status err-disabled
    errdisable recovery cause bpduguard
    errdisable recovery interval 300

    Frequently Asked Questions

    Q1: What is the difference between PVST+, Rapid PVST+, and MST?

    PVST+ is Cisco's per-VLAN implementation of classic 802.1D with 30-50 second convergence. Rapid PVST+ is the per-VLAN implementation of 802.1w with sub-second convergence using proposal/agreement. MST (802.1s) maps multiple VLANs to fewer instances, reducing resource usage while maintaining rapid convergence.

    Q2: How do I determine which switch is the current Root Bridge?

    Run

    show spanning-tree root
    on any switch in the VLAN. The output shows the Root ID (priority + MAC) and the root cost. If the root cost is 0, that switch is the Root Bridge.

    Q3: What STP priority value should I use for the Root Bridge?

    Use 4096 for the primary root and 8192 for the secondary root. The default priority is 32768. Priority values must be multiples of 4096 due to the extended system-id adding the VLAN number to the priority field.

    Q4: Should I enable PortFast on trunk ports connected to servers?

    Yes, for servers running 802.1Q trunks (e.g., VMware ESXi with multiple VLANs), use

    spanning-tree portfast trunk
    . Always pair this with BPDU Guard to prevent loops if someone connects a switch to that port.

    Q5: What happens when BPDU Guard triggers on a port?

    The port is immediately placed into err-disabled state and stops forwarding traffic. To recover, either manually shut/no shut the interface, or configure

    errdisable recovery cause bpduguard
    with a recovery interval for automatic recovery.

    Q6: Can I use Root Guard and Loop Guard on the same port?

    No, they are mutually exclusive on a per-port basis. Use Root Guard on distribution downlinks to access switches (to prevent access switches from becoming root). Use Loop Guard on interswitch uplinks where unidirectional link failure could cause a loop.

    Q7: How does Rapid PVST+ achieve faster convergence than classic STP?

    RSTP uses the proposal/agreement mechanism on point-to-point full-duplex links. When a new link comes up, the upstream switch proposes the port as designated. The downstream switch syncs (blocks all non-edge ports), then sends an agreement back. The port transitions to Forwarding immediately — no 30-second timer wait.

    Q8: What is the maximum number of STP instances on a Cisco Catalyst switch?

    With Rapid PVST+, each VLAN has its own instance. Most Catalyst platforms support up to 128 STP instances. If you have more than 128 VLANs, excess VLANs share instances or you should migrate to MST. MST supports up to 16 instances (0-15) on most Cisco platforms.

    Q9: How do I troubleshoot frequent Topology Change Notifications (TCNs)?

    Run

    show spanning-tree detail | include topology|from
    to identify which port is generating TCNs. Common causes include: flapping links, devices being powered on/off, and ports without PortFast connected to end hosts. Enable PortFast on access ports to suppress TCNs from host ports. Monitor syslog for
    %STP-6-TOPOLOGY_CHANGE
    messages.

    Q10: Do all switches in an MST deployment need the same region configuration?

    Yes, for switches to be in the same MST region, they must have identical region name, revision number, and VLAN-to-instance mapping. Switches with different configurations form separate regions and communicate via the IST (Instance 0) boundary, which treats the other region as a single virtual bridge.

    Frequently Asked Questions

    What is the difference between PVST+, Rapid PVST+, and MST?

    PVST+ is Cisco's per-VLAN implementation of classic 802.1D with 30-50 second convergence. Rapid PVST+ is the per-VLAN implementation of 802.1w with sub-second convergence using proposal/agreement. MST (802.1s) maps multiple VLANs to fewer instances, reducing resource usage while maintaining rapid convergence.

    How do I determine which switch is the current Root Bridge?

    Run 'show spanning-tree root' on any switch in the VLAN. The output shows the Root ID (priority + MAC) and the root cost. If the root cost is 0, that switch is the Root Bridge.

    What STP priority value should I use for the Root Bridge?

    Use 4096 for the primary root and 8192 for the secondary root. The default priority is 32768. Priority values must be multiples of 4096 due to the extended system-id adding the VLAN number to the priority field.

    Should I enable PortFast on trunk ports connected to servers?

    Yes, for servers running 802.1Q trunks (e.g., VMware ESXi with multiple VLANs), use 'spanning-tree portfast trunk'. Always pair this with BPDU Guard to prevent loops if someone connects a switch to that port.

    What happens when BPDU Guard triggers on a port?

    The port is immediately placed into err-disabled state and stops forwarding traffic. To recover, either manually shut/no shut the interface, or configure 'errdisable recovery cause bpduguard' with a recovery interval for automatic recovery.

    Can I use Root Guard and Loop Guard on the same port?

    No, they are mutually exclusive on a per-port basis. Use Root Guard on distribution downlinks to access switches to prevent access switches from becoming root. Use Loop Guard on interswitch uplinks where unidirectional link failure could cause a loop.

    How does Rapid PVST+ achieve faster convergence than classic STP?

    RSTP uses the proposal/agreement mechanism on point-to-point full-duplex links. When a new link comes up, the upstream switch proposes the port as designated. The downstream switch syncs (blocks all non-edge ports), then sends an agreement back. The port transitions to Forwarding immediately — no 30-second timer wait.

    What is the maximum number of STP instances on a Cisco Catalyst switch?

    With Rapid PVST+, each VLAN has its own instance. Most Catalyst platforms support up to 128 STP instances. If you have more than 128 VLANs, excess VLANs share instances or you should migrate to MST. MST supports up to 16 instances (0-15) on most Cisco platforms.

    How do I troubleshoot frequent Topology Change Notifications (TCNs)?

    Run 'show spanning-tree detail | include topology|from' to identify which port is generating TCNs. Common causes include flapping links, devices being powered on/off, and ports without PortFast connected to end hosts. Enable PortFast on access ports to suppress TCNs from host ports.

    Do all switches in an MST deployment need the same region configuration?

    Yes, for switches to be in the same MST region, they must have identical region name, revision number, and VLAN-to-instance mapping. Switches with different configurations form separate regions and communicate via the IST (Instance 0) boundary, which treats the other region as a single virtual bridge.

    Related Articles
