Cisco vs Arista Switches: Key Differences Explained

Introduction

When architects and network engineers evaluate switching platforms for enterprise campus or data center deployments, two names dominate the conversation: Cisco and Arista. Cisco has been the incumbent leader in enterprise networking for decades, shipping hardware that runs IOS, IOS-XE, NX-OS, and IOS-XR across its Catalyst, Nexus, and ASR families. Arista entered the market in 2008 with a singular focus on high-performance data center switches running its Extensible Operating System (EOS). Today both vendors compete across data center, cloud, and increasingly campus workloads.

This article delivers a hands-on technical comparison across CLI paradigms, VLAN management, spanning tree, routing protocols, high availability, EtherChannel, management plane automation, and licensing. All configurations reference hostname sw-infrarunbook-01, username infrarunbook-admin, RFC 1918 addressing, and the domain solvethenetwork.com.

---

Operating System Architecture

The most fundamental difference between Cisco and Arista is how the operating system is built and how it interacts with the forwarding hardware.

Cisco IOS-XE introduced a Linux kernel underneath with IOS running as a daemon on top, improving modularity over classic IOS while retaining full backward-compatible CLI. NX-OS on Nexus platforms goes further by running on Linux with modular process isolation, enabling per-process restarts without a full system reload. Despite these improvements, IOS-XE still couples many control-plane functions tightly to the hardware abstraction layer.

Arista EOS is built on an unmodified Linux kernel (based on Fedora) with every switch feature running as a separate user-space process. True process isolation means that if the OSPF daemon crashes, the forwarding plane continues unaffected and the daemon restarts automatically without impacting traffic. All state changes in EOS pass through a central publish-subscribe database called SysDB, which completely decouples the control plane from the forwarding ASIC and makes the switch state queryable in a consistent, structured format at all times.

Key insight: EOS's SysDB model means switch state is always accessible in structured form, making automation via eAPI, NETCONF, and gNMI significantly more reliable than screen-scraping CLI output from IOS-XE across versions.

---

CLI Differences: IOS-XE vs EOS

Engineers familiar with Cisco CLI will find Arista EOS immediately recognizable — Arista deliberately modeled EOS syntax on IOS to reduce the learning curve. However, several key differences emerge in practice.

Cisco IOS-XE version and config inspection:

sw-infrarunbook-01# show version
Cisco IOS XE Software, Version 17.09.04a
Cisco IOS Software [Cupertino], Catalyst L3 Switch Software
Technical Support: http://www.cisco.com/techsupport

sw-infrarunbook-01# show running-config | section interface GigabitEthernet
sw-infrarunbook-01# show ip interface brief | exclude unassigned

Arista EOS version and config inspection:

sw-infrarunbook-01# show version
Arista DCS-7050CX3-32S
Hardware version:    11.00
Serial number:       JPE19430233
System MAC address:  28:99:3a:f8:00:00
Software image version: 4.32.0F
Architecture:           i686
Internal build version: 4.32.0F-12345678.4320F

sw-infrarunbook-01# show running-config | section interface Ethernet
sw-infrarunbook-01# show ip interface brief | exclude unassigned

Notable CLI behavioral differences include:

• Cisco uses

  configure terminal

  ; Arista accepts both

  configure

  and

  configure terminal

• Arista config-mode prompts show the abbreviated interface name:

  (config-if-Et1)

  vs Cisco's generic

  (config-if)

• Arista supports

  show running-config sanitized

  to mask passwords and sensitive strings in output
• EOS provides direct Linux shell access via

  sw-infrarunbook-01# bash

• Arista supports on-device aliases and Python scripting natively through FastCLI
• Cisco IOS-XE requires the guest-shell container for on-box Python scripting

---

VLAN Configuration

VLAN configuration syntax is nearly identical between the two platforms, but behavioral differences are worth understanding before deployment.

Cisco IOS-XE VLAN and access port configuration:

sw-infrarunbook-01# configure terminal
sw-infrarunbook-01(config)# vlan 10
sw-infrarunbook-01(config-vlan)# name SERVERS
sw-infrarunbook-01(config-vlan)# exit
sw-infrarunbook-01(config)# vlan 20
sw-infrarunbook-01(config-vlan)# name STORAGE
sw-infrarunbook-01(config-vlan)# exit
sw-infrarunbook-01(config)# interface GigabitEthernet1/0/1
sw-infrarunbook-01(config-if)# description SERVER-01
sw-infrarunbook-01(config-if)# switchport mode access
sw-infrarunbook-01(config-if)# switchport access vlan 10
sw-infrarunbook-01(config-if)# spanning-tree portfast
sw-infrarunbook-01(config-if)# spanning-tree bpduguard enable
sw-infrarunbook-01(config-if)# no shutdown
sw-infrarunbook-01(config-if)# end
sw-infrarunbook-01# write memory

Arista EOS VLAN and access port configuration:

sw-infrarunbook-01# configure
sw-infrarunbook-01(config)# vlan 10
sw-infrarunbook-01(config-vlan-10)# name SERVERS
sw-infrarunbook-01(config-vlan-10)# exit
sw-infrarunbook-01(config)# vlan 20
sw-infrarunbook-01(config-vlan-20)# name STORAGE
sw-infrarunbook-01(config-vlan-20)# exit
sw-infrarunbook-01(config)# interface Ethernet1
sw-infrarunbook-01(config-if-Et1)# description SERVER-01
sw-infrarunbook-01(config-if-Et1)# switchport mode access
sw-infrarunbook-01(config-if-Et1)# switchport access vlan 10
sw-infrarunbook-01(config-if-Et1)# spanning-tree portfast
sw-infrarunbook-01(config-if-Et1)# spanning-tree bpduguard enable
sw-infrarunbook-01(config-if-Et1)# no shutdown
sw-infrarunbook-01(config-if-Et1)# end
sw-infrarunbook-01# write memory

On Arista, VLANs can be created in bulk ranges:

vlan 10,20,30,100-200

. Arista also supports VLAN database mode for compatibility with engineers migrating from NX-OS environments. A key operational note: both platforms require VLANs to exist in the VLAN database before traffic is forwarded on trunk ports, and Arista's

show interfaces trunk

clearly marks VLANs that are allowed but not active in the database.

---

Spanning Tree Protocol

Both vendors support 802.1D, Rapid PVST+, and MSTP. Cisco Catalyst switches and Arista EOS both default to Rapid PVST+ on most platforms.

Cisco Rapid PVST+ root bridge and edge port configuration:

sw-infrarunbook-01(config)# spanning-tree mode rapid-pvst
sw-infrarunbook-01(config)# spanning-tree vlan 10,20 priority 4096
sw-infrarunbook-01(config)# spanning-tree vlan 30,40 priority 8192
sw-infrarunbook-01(config)# interface GigabitEthernet1/0/1
sw-infrarunbook-01(config-if)# spanning-tree portfast
sw-infrarunbook-01(config-if)# spanning-tree bpduguard enable
sw-infrarunbook-01(config-if)# end
sw-infrarunbook-01# show spanning-tree vlan 10 detail

Arista Rapid PVST+ root bridge and MSTP configuration:

sw-infrarunbook-01(config)# spanning-tree mode rapid-pvst
sw-infrarunbook-01(config)# spanning-tree vlan 10,20 priority 4096
sw-infrarunbook-01(config)# spanning-tree vlan 30,40 priority 8192
sw-infrarunbook-01(config)# interface Ethernet1
sw-infrarunbook-01(config-if-Et1)# spanning-tree portfast
sw-infrarunbook-01(config-if-Et1)# spanning-tree bpduguard enable
sw-infrarunbook-01(config-if-Et1)# end

! MSTP example on Arista
sw-infrarunbook-01(config)# spanning-tree mode mstp
sw-infrarunbook-01(config)# spanning-tree mst configuration
sw-infrarunbook-01(config-mst)# name solvethenetwork-core
sw-infrarunbook-01(config-mst)# revision 1
sw-infrarunbook-01(config-mst)# instance 1 vlan 10,20,30
sw-infrarunbook-01(config-mst)# instance 2 vlan 40,50,60
sw-infrarunbook-01(config-mst)# exit
sw-infrarunbook-01(config)# spanning-tree mst 1 priority 4096
sw-infrarunbook-01(config)# spanning-tree mst 2 priority 8192

Arista's

show spanning-tree topology status detail

provides richer diagnostic output than the equivalent IOS command, including per-port role, state, and cost in a single view. This is particularly useful when troubleshooting asymmetric topologies in MSTP environments.

---

EtherChannel and LACP

Both platforms implement IEEE 802.3ad LACP with nearly identical syntax for basic configuration.

Cisco LACP port-channel trunk:

sw-infrarunbook-01(config)# interface range GigabitEthernet1/0/1-2
sw-infrarunbook-01(config-if-range)# channel-group 1 mode active
sw-infrarunbook-01(config-if-range)# exit
sw-infrarunbook-01(config)# interface Port-channel1
sw-infrarunbook-01(config-if)# description UPLINK-TO-SPINE
sw-infrarunbook-01(config-if)# switchport mode trunk
sw-infrarunbook-01(config-if)# switchport trunk allowed vlan 10,20,30
sw-infrarunbook-01(config-if)# end
sw-infrarunbook-01# show etherchannel 1 summary

Arista LACP port-channel trunk:

sw-infrarunbook-01(config)# interface Ethernet1-2
sw-infrarunbook-01(config-if-Et1-2)# description UPLINK-TO-SPINE
sw-infrarunbook-01(config-if-Et1-2)# channel-group 1 mode active
sw-infrarunbook-01(config-if-Et1-2)# exit
sw-infrarunbook-01(config)# interface Port-Channel1
sw-infrarunbook-01(config-if-Po1)# switchport mode trunk
sw-infrarunbook-01(config-if-Po1)# switchport trunk allowed vlan 10,20,30
sw-infrarunbook-01(config-if-Po1)# end
sw-infrarunbook-01# show port-channel 1 summary

The significant architectural difference is multi-chassis aggregation. Arista ships MLAG (Multi-chassis Link Aggregation Group) as a built-in EOS feature on every platform — two Arista switches share a peer-link trunk and a keep-alive IP (typically in the management VRF) to present a single logical port-channel to downstream devices. Cisco's equivalent is vPC on Nexus or StackWise Virtual on Catalyst 9000. MLAG is generally simpler to configure and troubleshoot than vPC, which requires domain IDs, role priorities, and consistency checks that add operational overhead.

---

Routing Protocols: OSPF

OSPF syntax diverges in one important way: Arista strongly favors per-interface OSPF activation over the Cisco wildcard network statement, though both syntaxes are supported on EOS.

Cisco OSPF configuration:

sw-infrarunbook-01(config)# router ospf 1
sw-infrarunbook-01(config-router)# router-id 192.168.1.1
sw-infrarunbook-01(config-router)# network 192.168.10.0 0.0.0.255 area 0
sw-infrarunbook-01(config-router)# network 192.168.20.0 0.0.0.255 area 0
sw-infrarunbook-01(config-router)# passive-interface default
sw-infrarunbook-01(config-router)# no passive-interface GigabitEthernet1/0/1
sw-infrarunbook-01(config-router)# log-adjacency-changes detail
sw-infrarunbook-01(config-router)# end
sw-infrarunbook-01# show ip ospf neighbor

Arista OSPF configuration (preferred per-interface method):

sw-infrarunbook-01(config)# router ospf 1
sw-infrarunbook-01(config-router-ospf)# router-id 192.168.1.1
sw-infrarunbook-01(config-router-ospf)# passive-interface default
sw-infrarunbook-01(config-router-ospf)# log-adjacency-changes detail
sw-infrarunbook-01(config-router-ospf)# exit
sw-infrarunbook-01(config)# interface Ethernet1
sw-infrarunbook-01(config-if-Et1)# ip ospf 1 area 0.0.0.0
sw-infrarunbook-01(config-if-Et1)# ip ospf network point-to-point
sw-infrarunbook-01(config-if-Et1)# no ip ospf passive
sw-infrarunbook-01(config-if-Et1)# end
sw-infrarunbook-01# show ip ospf neighbor

The per-interface activation model is more explicit and avoids the subtle bugs that arise when wildcard network statements unintentionally match loopback interfaces or management interfaces on Cisco devices.

---

Routing Protocols: BGP

BGP configuration is where Arista's peer-group model and EVPN integration become most apparent in data center deployments.

Cisco BGP eBGP leaf-spine underlay:

sw-infrarunbook-01(config)# router bgp 65001
sw-infrarunbook-01(config-router)# bgp router-id 192.168.1.1
sw-infrarunbook-01(config-router)# bgp log-neighbor-changes
sw-infrarunbook-01(config-router)# neighbor 192.168.2.1 remote-as 65000
sw-infrarunbook-01(config-router)# neighbor 192.168.2.1 description SPINE-01
sw-infrarunbook-01(config-router)# neighbor 192.168.2.2 remote-as 65000
sw-infrarunbook-01(config-router)# neighbor 192.168.2.2 description SPINE-02
sw-infrarunbook-01(config-router)# address-family ipv4
sw-infrarunbook-01(config-router-af)# neighbor 192.168.2.1 activate
sw-infrarunbook-01(config-router-af)# neighbor 192.168.2.2 activate
sw-infrarunbook-01(config-router-af)# network 10.10.10.0 mask 255.255.255.0
sw-infrarunbook-01(config-router-af)# exit-address-family

Arista BGP eBGP leaf-spine underlay with peer-groups:

sw-infrarunbook-01(config)# router bgp 65001
sw-infrarunbook-01(config-router-bgp)# router-id 192.168.1.1
sw-infrarunbook-01(config-router-bgp)# bgp log-neighbor-changes
sw-infrarunbook-01(config-router-bgp)# neighbor SPINE peer group
sw-infrarunbook-01(config-router-bgp)# neighbor SPINE remote-as 65000
sw-infrarunbook-01(config-router-bgp)# neighbor SPINE send-community extended
sw-infrarunbook-01(config-router-bgp)# neighbor SPINE maximum-routes 12000
sw-infrarunbook-01(config-router-bgp)# neighbor 192.168.2.1 peer group SPINE
sw-infrarunbook-01(config-router-bgp)# neighbor 192.168.2.1 description SPINE-01
sw-infrarunbook-01(config-router-bgp)# neighbor 192.168.2.2 peer group SPINE
sw-infrarunbook-01(config-router-bgp)# neighbor 192.168.2.2 description SPINE-02
sw-infrarunbook-01(config-router-bgp)# address-family ipv4
sw-infrarunbook-01(config-router-bgp-af)# neighbor SPINE activate
sw-infrarunbook-01(config-router-bgp-af)# network 10.10.10.0/24
sw-infrarunbook-01(config-router-bgp-af)# exit

Arista has native, deeply integrated BGP EVPN (RFC 7432) support in EOS. Enabling VXLAN EVPN on Arista adds a handful of lines for the VTEP and the EVPN address family — the EOS EVPN implementation is widely regarded as the most straightforward in the industry. Cisco Nexus VXLAN EVPN requires NX-OS and significantly more scaffolding including fabric forwarding, NVE interfaces, and additional process configuration.

---

High Availability: HSRP vs VARP

For first-hop redundancy, Cisco relies on HSRP or VRRP in an active-standby model. Arista provides a proprietary feature called Virtual ARP (VARP) that fundamentally changes the high-availability model.

Cisco HSRPv2 on an SVI:

sw-infrarunbook-01(config)# interface Vlan10
sw-infrarunbook-01(config-if)# ip address 192.168.10.2 255.255.255.0
sw-infrarunbook-01(config-if)# standby version 2
sw-infrarunbook-01(config-if)# standby 10 ip 192.168.10.1
sw-infrarunbook-01(config-if)# standby 10 priority 110
sw-infrarunbook-01(config-if)# standby 10 preempt delay minimum 30
sw-infrarunbook-01(config-if)# standby 10 timers msec 250 msec 750
sw-infrarunbook-01(config-if)# end
sw-infrarunbook-01# show standby brief

Arista VARP on an SVI:

sw-infrarunbook-01(config)# ip virtual-router mac-address 00:1c:73:00:00:01
sw-infrarunbook-01(config)# interface Vlan10
sw-infrarunbook-01(config-if-Vl10)# ip address 192.168.10.2/24
sw-infrarunbook-01(config-if-Vl10)# ip virtual-router address 192.168.10.1
sw-infrarunbook-01(config-if-Vl10)# exit
sw-infrarunbook-01(config)# interface Vlan20
sw-infrarunbook-01(config-if-Vl20)# ip address 192.168.20.2/24
sw-infrarunbook-01(config-if-Vl20)# ip virtual-router address 192.168.20.1
sw-infrarunbook-01(config-if-Vl20)# end
sw-infrarunbook-01# show ip virtual-router

VARP is active-active by design — every switch in an MLAG pair (or all leaf nodes in an EVPN fabric) simultaneously responds to ARP requests for the virtual IP using a shared virtual MAC address. There is no election, no hello timer, no preemption, and no failover delay. When a leaf switch fails in a VARP-enabled fabric, hosts do not experience an FHRP convergence event — traffic simply routes through the surviving switches immediately. This is a significant operational and availability advantage over HSRP in large-scale data center topologies.

---

Management Plane: eAPI vs RESTCONF

One of Arista's most impactful differentiators is eAPI — a native HTTP/HTTPS JSON-RPC interface that exposes every CLI command as a machine-readable API call.

Enabling eAPI on Arista EOS:

sw-infrarunbook-01(config)# management api http-commands
sw-infrarunbook-01(config-mgmt-api-http-cmds)# protocol https
sw-infrarunbook-01(config-mgmt-api-http-cmds)# no shutdown
sw-infrarunbook-01(config-mgmt-api-http-cmds)# vrf MGMT
sw-infrarunbook-01(config-mgmt-api-http-cmds-vrf-MGMT)# no shutdown
sw-infrarunbook-01(config-mgmt-api-http-cmds-vrf-MGMT)# end
sw-infrarunbook-01# show management api http-commands

Once enabled, any CLI command can be executed via an HTTP POST to the switch management IP. An eAPI request body looks like this:

{
  "jsonrpc": "2.0",
  "method": "runCmds",
  "params": {
    "version": 1,
    "cmds": [
      "show bgp summary",
      "show interfaces status",
      "show ip route"
    ],
    "format": "json"
  },
  "id": "infrarunbook-admin"
}

Cisco IOS-XE supports RESTCONF (RFC 8040) and NETCONF (RFC 6241) using YANG data models. While standards-compliant, YANG model coverage varies significantly across IOS-XE versions, and model inconsistencies between 16.x and 17.x releases create fragile automation scripts. Arista's eAPI returns consistent structured JSON regardless of EOS version, making automation tooling substantially more portable across software upgrades. Arista also provides first-class support for pyeapi, Ansible arista.eos, Terraform, and OpenConfig via gNMI/gRPC.

---

Zero-Touch Provisioning

Both vendors support ZTP, but the maturity and ease of use differ considerably in practice.

Arista ZTP boots factory-fresh switches in ZTP mode by default. The switch sends a DHCP request on the management interface, receives an IP from the provisioning server at

192.168.100.10

(internal to solvethenetwork.com infrastructure), and fetches a startup-config or Python provisioning script via the DHCP option 67 boot-file URL. The ZTP script runs with full access to the EOS Python environment including pyeapi, allowing sophisticated Day-0 provisioning workflows: LLDP-based rack position detection, dynamic config generation, and post-provision validation are all achievable in a single ZTP script.

Cisco ZTP on IOS-XE uses a similar DHCP-based mechanism to fetch a startup-config or Python script. On Catalyst 9000, the guest-shell (a Linux container) must be explicitly enabled for Python-based Day-0 automation. Cisco DNA Center provides a more GUI-driven PnP (Plug and Play) workflow that works well in managed environments, but requires DNA Center licensing.

---

Licensing Models

Cisco's licensing model is substantially more complex than Arista's and has evolved significantly over the years.

• Cisco Smart Licensing: Requires registration with Cisco Smart Software Manager (CSSM) or an on-premises satellite. Feature tiers (Network Essentials, Network Advantage, DNA Essentials, DNA Advantage) gate capabilities including SD-Access, advanced telemetry, and encrypted traffic analytics. Licenses are enforced and non-compliant switches generate persistent warnings and eventually enter restricted mode.
• Arista EOS Licensing: Full Layer 2 and Layer 3 feature sets — including BGP, OSPF, EIGRP, VXLAN, EVPN, MLAG, VARP, QoS, and ACLs — are included with EOS at no additional charge. CloudVision Portal (CVP) for centralized telemetry, change control, and provisioning is licensed separately. There are no per-feature licenses on EOS switches themselves.

This distinction is operationally significant. A misconfigured or expired Cisco DNA Advantage license can disable production features in an SD-Access fabric. On Arista, the risk of a licensing event disrupting network functionality is essentially zero for the base switching features used in most deployments.

---

Hardware Forwarding Architecture

Cisco Catalyst 9000 switches use custom ASICs — the UADP (Unified Access Data Plane) series, currently at version 3.0 — that are tightly integrated with IOS-XE. This enables Cisco-specific capabilities like Encrypted Traffic Analytics (ETA) and fine-grained programmable QoS that go beyond what merchant silicon supports. The tradeoff is vendor lock-in and slower adoption of new forwarding capabilities dependent on ASIC silicon revisions.

Arista platforms are built on merchant silicon — primarily Broadcom Trident 4, Tomahawk 4, and Jericho 2 series ASICs depending on the platform role. Merchant silicon provides faster time-to-market for new hardware capabilities, excellent price-per-port ratios, and well-documented, predictable behavior. The Arista 7050 series targets ToR access, 7060 serves 100G spine roles, 7260 handles aggregation, and the 7800 chassis addresses large-scale core deployments.

---

Summary of Key Differences

• OS Architecture: Arista EOS is fully process-isolated on Linux with SysDB; Cisco IOS-XE runs IOS as a daemon on Linux with tighter coupling
• CLI: Near-identical syntax; differences in interface naming and OSPF activation model
• FHRP: Arista VARP is active-active with zero failover delay; Cisco HSRP/VRRP is active-standby
• Multi-chassis LAG: Arista MLAG is simpler to operate than Cisco vPC on Nexus
• EVPN/VXLAN: Both support it; Arista EOS implementation is more concise and widely deployed in production DC fabrics
• Automation: Arista eAPI provides consistent structured JSON; Cisco RESTCONF/NETCONF YANG coverage varies by IOS-XE version
• Licensing: Arista includes full feature set in EOS; Cisco requires tiered licensing for advanced features
• Campus/SD-Access: Cisco is the stronger choice with DNA Center, ISE integration, and mature SD-Access workflows
• Data Center Fabric: Arista is the dominant choice for leaf-spine EVPN deployments in enterprise and cloud-adjacent environments

---

Frequently Asked Questions

Q: Can a Cisco engineer use Arista EOS without significant retraining?

A: Yes, with minimal adjustment. Arista intentionally modeled EOS CLI on Cisco IOS to minimize the learning curve. Commands like

show interfaces

,

show running-config

,

write memory

, and most routing protocol syntax work identically or near-identically. The main adjustments are interface naming conventions (Ethernet1 vs GigabitEthernet1/0/1), the per-interface OSPF activation model, and MLAG configuration in place of vPC.

Q: Does Arista EOS support HSRP?

A: Yes, Arista EOS fully supports both HSRPv1/v2 and VRRP. However, the preferred Arista design for data center deployments is VARP, which is active-active with no election process and no convergence delay. HSRP is available on EOS primarily for compatibility during migrations from Cisco environments or in campus scenarios where HSRP interoperability with upstream Cisco devices is required.

Q: What is the Arista equivalent of Cisco vPC?

A: Arista's equivalent is MLAG (Multi-chassis Link Aggregation Group). MLAG allows two Arista switches to present a single logical port-channel to a downstream device, providing link redundancy without STP blocking. Unlike Cisco vPC, which requires Nexus-family hardware, MLAG is supported on every Arista switching platform and uses a peer-link trunk plus a keep-alive IP for peer-health monitoring. MLAG configuration is generally considered simpler and less error-prone than vPC.

Q: Is Arista EOS supported by Ansible?

A: Yes. Arista maintains an official Ansible collection (

arista.eos

) available on Ansible Galaxy that covers interface configuration, VLAN management, BGP, OSPF, ACLs, MLAG, and more. The collection communicates via eAPI under the hood, providing reliable structured data exchange without screen scraping. Cisco has equivalent collections for IOS-XE (

cisco.ios

) and NX-OS (

cisco.nxos

), though the consistency of YANG/API responses between IOS-XE versions can affect playbook reliability.

Q: How does Arista handle in-service software upgrades compared to Cisco?

A: Arista EOS supports ISSU (In-Service Software Upgrade) on modular chassis platforms such as the 7800 series. On fixed-form-factor platforms, upgrades require a brief reload, but EOS boot times are typically under 60 seconds on modern hardware. Cisco IOS-XE supports ISSU on Catalyst 9400 and 9600 chassis platforms. Both vendors provide pre-upgrade health-check commands. Arista CloudVision adds a change-control workflow that performs automated pre/post-change validation across the entire fleet, which reduces upgrade risk at scale.

Q: Can I run Python scripts directly on an Arista switch?

A: Yes. EOS includes a Python 3 interpreter and the

pyeapi

library accessible natively via the

bash

CLI command or as scheduled on-device EOS SDK agents. Scripts can query SysDB directly or call eAPI to configure the switch programmatically. Cisco IOS-XE provides a guest-shell Linux container for on-box Python scripting, but it requires explicit enablement with

iox

and

app-hosting

configuration and is less integrated into the switch operating environment than Arista's native Python access.

Q: Which platform is better for BGP EVPN VXLAN leaf-spine fabrics?

A: Both Cisco NX-OS and Arista EOS support BGP EVPN VXLAN. In practice, Arista's EOS implementation is widely regarded as the industry benchmark for ease of configuration and operational stability. Arista's EVPN integrates tightly with MLAG, VARP, and eAPI telemetry, and the configuration syntax is concise. Many enterprise and cloud-adjacent data centers standardize on Arista for leaf-spine EVPN fabrics. For campus overlay use cases, Cisco's SD-Access with DNA Center is the more complete solution.

Q: Does Arista EOS support DHCP snooping and Dynamic ARP Inspection?

A: Yes. Arista EOS supports both DHCP snooping and Dynamic ARP Inspection (DAI) with syntax nearly identical to Cisco IOS-XE. DHCP snooping is enabled per-VLAN with

ip dhcp snooping vlan 10

, trusted uplink interfaces are designated with

ip dhcp snooping trust

, and DAI uses the DHCP snooping binding table for ARP validation. Port-security is also supported on Arista EOS with

switchport port-security

configuration, matching Cisco's feature behavior.

Q: What are the main differences in AAA and TACACS+ configuration between Cisco and Arista?

A: Both platforms support TACACS+ for centralized authentication and per-command authorization. Cisco requires

aaa new-model

to enable AAA globally and configures servers in

tacacs server

named blocks. Arista uses

aaa authentication

stanzas and

tacacs-server host 192.168.100.5 key 7 <hash>

syntax. Arista additionally supports role-based access control (RBAC) natively within EOS, allowing read-only, read-write, and custom privilege roles without requiring full TACACS+ command authorization on the AAA server — useful for smaller deployments where a full ACS or ISE deployment is not justified.

Q: How does the MAC address table work on Arista vs Cisco?

A: The command is identical on both platforms:

show mac address-table

. Both support filtering by VLAN (

show mac address-table vlan 10

), by interface, or by specific MAC address. Arista additionally offers

show mac address-table count

for a quick TCAM utilization summary, and the output format is consistent across EOS versions — making it straightforward to parse programmatically via eAPI for automated capacity monitoring.

Q: What is Arista CloudVision and how does it compare to Cisco DNA Center?

A: Arista CloudVision Portal (CVP) is a centralized management, telemetry, and change-control platform. It uses streaming telemetry via gNMI/gRPC rather than SNMP polling, delivering near-real-time visibility into interface counters, BGP state, EVPN table sizes, and hardware resource utilization across all managed switches. CVP enforces structured change-control workflows where every configuration change is reviewed, approved, and automatically validated pre/post-push. Cisco DNA Center is more feature-rich for campus use cases including SD-Access policy enforcement and ISE integration for dynamic VLAN assignment. For data center automation and telemetry pipelines, CVP is the stronger platform.

Q: Is NTP configuration the same on Cisco and Arista?

A: Very similar. On Cisco IOS-XE:

ntp server 192.168.100.5 prefer

. On Arista EOS:

ntp server 192.168.100.5 prefer

. Arista adds an important operational extension: you can bind NTP to a specific VRF with

ntp server vrf MGMT 192.168.100.5 prefer

, which is essential when the management interface is in a non-default VRF — an increasingly common design in modern switches where data-plane and management-plane traffic are strictly separated.
