HAProxy ACLs and Routing: Path-Based Routing, Host-Based Routing, Header Inspection, and Advanced Traffic Steering

Introduction

HAProxy's Access Control List (ACL) engine is one of its most powerful features, allowing you to inspect every facet of an incoming request — the path, hostname, HTTP headers, query strings, source IP, SSL attributes, and more — and then route, reject, or modify traffic accordingly. This article is a comprehensive, production-ready guide to building ACL rules that cover virtual hosting, microservice path routing, header-based canary deployments, geographic steering, and request sanitisation. Every example uses real HAProxy 2.8+ syntax and has been tested for correctness.

---

1. ACL Fundamentals

1.1 What Is an ACL?

An ACL is a named boolean test applied to request or response data. HAProxy evaluates ACLs in order and uses them inside

use_backend

,

http-request

, and

http-response

directives to make routing and policy decisions.

1.2 ACL Syntax

acl <name> <criterion> [flags] [operator] <value> ...

Key components:

• name — a descriptive identifier (e.g.,

  is_api

  ,

  host_blog

  ).
• criterion — the fetch method (e.g.,

  path_beg

  ,

  hdr(host)

  ,

  src

  ).
• flags — modifiers like

  -i

  (case-insensitive),

  -f

  (read from file),

  -m

  (match method).
• value — one or more values to match against.

1.3 Common Fetch Methods

# Layer 4
src                  # Client source IP
dst_port             # Destination port
ssl_fc               # 1 if connection is SSL

# Layer 7 — Host and Path
path                 # Exact path
path_beg             # Path begins with
path_end             # Path ends with
path_reg             # Path matches regex
path_sub             # Path contains substring
hdr(host)            # Host header value
hdr_beg(host)        # Host header begins with

# Layer 7 — Headers and Method
method               # HTTP method (GET, POST, etc.)
hdr(X-Forwarded-For) # Any header by name
hdr_cnt(header)      # Number of occurrences of a header
req.hdr(User-Agent)  # User-Agent value

# Layer 7 — Query string
url_param(name)      # Value of a URL parameter
query                # Full query string

1.4 Match Flags

-i      # Case-insensitive comparison
-f      # Load values from a file (one per line)
-m str  # Exact string match (default for most)
-m beg  # Begins with
-m end  # Ends with
-m sub  # Contains substring
-m reg  # POSIX regex
-m found # True if the fetch returns any value
-m len  # Match on length

---

2. Path-Based Routing

Path-based routing sends requests to different backend pools based on the URL path. This is the foundation of microservice routing.

2.1 Basic Path Prefix Routing

frontend http_front
    bind *:80
    mode http

    # Define ACLs
    acl is_api      path_beg /api
    acl is_static   path_beg /static /assets /images
    acl is_websocket path_beg /ws
    acl is_health   path /health

    # Route to backends
    use_backend api_servers      if is_api
    use_backend static_servers   if is_static
    use_backend websocket_servers if is_websocket
    use_backend health_check     if is_health
    default_backend web_servers

backend api_servers
    mode http
    balance leastconn
    option httpchk GET /api/ping
    http-check expect status 200
    server api1 10.0.1.10:8080 check inter 3s fall 3 rise 2
    server api2 10.0.1.11:8080 check inter 3s fall 3 rise 2

backend static_servers
    mode http
    balance roundrobin
    server static1 10.0.2.10:80 check
    server static2 10.0.2.11:80 check

backend websocket_servers
    mode http
    balance source
    timeout tunnel 3600s
    server ws1 10.0.3.10:8081 check
    server ws2 10.0.3.11:8081 check

backend web_servers
    mode http
    balance roundrobin
    server web1 10.0.4.10:80 check
    server web2 10.0.4.11:80 check

backend health_check
    mode http
    http-request return status 200 content-type text/plain string "OK"

2.2 Path Stripping (Rewriting) for Backends

Often, your API backend doesn't expect the

/api

prefix. Strip it before forwarding:

backend api_servers
    mode http
    balance leastconn
    # Strip /api prefix: /api/v1/users -> /v1/users
    http-request set-path %[path,regsub(^/api,,)]
    server api1 10.0.1.10:8080 check
    server api2 10.0.1.11:8080 check

2.3 Versioned API Routing

frontend http_front
    bind *:80
    mode http

    acl is_api_v1 path_beg /api/v1
    acl is_api_v2 path_beg /api/v2
    acl is_api_v3 path_beg /api/v3

    use_backend api_v1_servers if is_api_v1
    use_backend api_v2_servers if is_api_v2
    use_backend api_v3_servers if is_api_v3
    default_backend web_servers

backend api_v1_servers
    mode http
    server apiv1a 10.0.10.10:8080 check

backend api_v2_servers
    mode http
    server apiv2a 10.0.11.10:8080 check
    server apiv2b 10.0.11.11:8080 check

backend api_v3_servers
    mode http
    server apiv3a 10.0.12.10:8080 check
    server apiv3b 10.0.12.11:8080 check
    server apiv3c 10.0.12.12:8080 check

2.4 Regex-Based Path Routing

frontend http_front
    bind *:80
    mode http

    # Match /user/123/profile, /user/456/settings, etc.
    acl is_user_profile path_reg ^/user/[0-9]+/profile$
    acl is_user_settings path_reg ^/user/[0-9]+/settings$

    # Match file extensions
    acl is_image path_end .jpg .jpeg .png .gif .webp .svg
    acl is_document path_end .pdf .docx .xlsx

    use_backend profile_service if is_user_profile
    use_backend settings_service if is_user_settings
    use_backend cdn_servers if is_image
    use_backend document_servers if is_document
    default_backend web_servers

---

3. Host-Based Routing (Virtual Hosting)

Host-based routing multiplexes multiple domains or subdomains through a single HAProxy frontend.

3.1 Simple Multi-Domain Setup

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Host-based ACLs (case-insensitive)
    acl host_www      hdr(host) -i www.example.com example.com
    acl host_api      hdr(host) -i api.example.com
    acl host_blog     hdr(host) -i blog.example.com
    acl host_admin    hdr(host) -i admin.example.com
    acl host_grafana  hdr(host) -i grafana.example.com

    use_backend web_servers     if host_www
    use_backend api_servers     if host_api
    use_backend blog_servers    if host_blog
    use_backend admin_servers   if host_admin
    use_backend grafana_servers if host_grafana
    default_backend web_servers

3.2 Wildcard Subdomain Routing

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Match any subdomain of example.com
    acl host_example hdr_end(host) -i .example.com

    # Match specific subdomains first (more specific rules first)
    acl host_api hdr(host) -i api.example.com
    acl host_staging hdr_beg(host) -i staging.

    use_backend api_servers     if host_api
    use_backend staging_servers if host_staging host_example
    use_backend web_servers     if host_example
    default_backend fallback_servers

3.3 Host-Based Routing from a Map File

For environments with many domains, use a map file for cleaner configuration:

# /etc/haproxy/maps/domain-to-backend.map
www.example.com       web_servers
example.com           web_servers
api.example.com       api_servers
blog.example.com      blog_servers
admin.example.com     admin_servers
grafana.example.com   grafana_servers
app.clienta.com       clienta_servers
app.clientb.com       clientb_servers

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Use map file for dynamic backend selection
    use_backend %[req.hdr(host),lower,map(/etc/haproxy/maps/domain-to-backend.map,fallback_servers)]

This approach scales to hundreds of domains and can be updated at runtime via the HAProxy Runtime API:

# Add or update a map entry at runtime
echo "set map /etc/haproxy/maps/domain-to-backend.map app.clientc.com clientc_servers" | socat stdio /var/run/haproxy/admin.sock

# List all entries
echo "show map /etc/haproxy/maps/domain-to-backend.map" | socat stdio /var/run/haproxy/admin.sock

# Delete an entry
echo "del map /etc/haproxy/maps/domain-to-backend.map app.clientb.com" | socat stdio /var/run/haproxy/admin.sock

---

4. Header Inspection and Manipulation

4.1 Routing by Custom Header

frontend http_front
    bind *:80
    mode http

    # Canary deployment: route if X-Canary: true header is present
    acl is_canary hdr(X-Canary) -i true

    # Internal traffic detection
    acl is_internal hdr(X-Internal-Token) -i s3cretT0ken2026

    # Mobile app detection
    acl is_mobile_app hdr_sub(User-Agent) -i MobileApp/

    use_backend canary_servers   if is_canary
    use_backend internal_servers if is_internal
    use_backend mobile_backend   if is_mobile_app
    default_backend web_servers

4.2 Routing by HTTP Method

frontend http_front
    bind *:80
    mode http

    acl is_api path_beg /api
    acl is_read_method method GET HEAD OPTIONS
    acl is_write_method method POST PUT PATCH DELETE

    # Split read/write traffic to different backend pools
    use_backend api_read_replicas  if is_api is_read_method
    use_backend api_write_primary  if is_api is_write_method
    default_backend web_servers

backend api_read_replicas
    mode http
    balance roundrobin
    server read1 10.0.1.10:8080 check
    server read2 10.0.1.11:8080 check
    server read3 10.0.1.12:8080 check

backend api_write_primary
    mode http
    balance leastconn
    server write1 10.0.2.10:8080 check
    server write2 10.0.2.11:8080 check

4.3 Adding, Modifying, and Deleting Headers

frontend http_front
    bind *:80
    mode http

    # Add headers before forwarding
    http-request set-header X-Forwarded-Proto http
    http-request set-header X-Real-IP %[src]
    http-request set-header X-Request-ID %[uuid()]

    # Delete dangerous headers from client
    http-request del-header X-Forwarded-For
    http-request del-header X-Original-URL
    http-request del-header Proxy

    # Add security headers to response
    http-response set-header X-Content-Type-Options nosniff
    http-response set-header X-Frame-Options DENY
    http-response set-header Referrer-Policy strict-origin-when-cross-origin
    http-response del-header Server
    http-response del-header X-Powered-By

    default_backend web_servers

4.4 Content-Type Based Routing

frontend http_front
    bind *:80
    mode http

    acl is_api path_beg /api
    acl is_grpc hdr(Content-Type) -i application/grpc
    acl is_json hdr(Content-Type) -m sub application/json
    acl is_graphql path /graphql

    use_backend grpc_servers    if is_grpc
    use_backend graphql_servers if is_graphql
    use_backend api_servers     if is_api is_json
    default_backend web_servers

---

5. Query String and Cookie-Based Routing

5.1 Query Parameter Routing

frontend http_front
    bind *:80
    mode http

    # Route by query parameter: ?env=staging
    acl is_staging_param url_param(env) -i staging
    acl is_debug_param url_param(debug) -i true

    use_backend staging_servers if is_staging_param
    # Add debug header if debug mode requested
    http-request set-header X-Debug-Mode true if is_debug_param

    default_backend web_servers

5.2 Cookie-Based Routing

frontend http_front
    bind *:80
    mode http

    # Route based on a/b testing cookie
    acl is_variant_b cook(ab_test) -i variant_b
    acl is_beta_user cook(beta) -m found

    use_backend variant_b_servers if is_variant_b
    use_backend beta_servers if is_beta_user
    default_backend web_servers

---

6. Source IP and Geographic Routing

6.1 Source IP Allowlisting

# /etc/haproxy/lists/admin-ips.lst
10.0.0.0/8
172.16.0.0/12
192.168.0.0/16
203.0.113.45/32

frontend http_front
    bind *:80
    mode http

    acl is_admin_path path_beg /admin
    acl is_allowed_ip src -f /etc/haproxy/lists/admin-ips.lst

    # Block admin access from non-allowed IPs
    http-request deny deny_status 403 if is_admin_path !is_allowed_ip

    default_backend web_servers

6.2 GeoIP-Based Routing with Map Files

If you use a GeoIP Lua script or the

req.hdr(CF-IPCountry)

header from a CDN:

# /etc/haproxy/maps/country-to-backend.map
US    us_servers
CA    us_servers
GB    eu_servers
DE    eu_servers
FR    eu_servers
JP    apac_servers
AU    apac_servers

frontend http_front
    bind *:80
    mode http

    # Assuming CDN sets CF-IPCountry header
    use_backend %[req.hdr(CF-IPCountry),upper,map(/etc/haproxy/maps/country-to-backend.map,us_servers)]

---

7. Combining ACLs: AND, OR, and NOT Logic

7.1 Logical Operators

# AND — all conditions must be true (space-separated)
use_backend admin_servers if is_admin_path is_allowed_ip is_read_method

# OR — any condition can be true (|| operator)
use_backend static_servers if is_image || is_document || is_static

# NOT — negate with !
http-request deny if is_admin_path !is_allowed_ip

# Complex combination
# (is_api AND is_write_method) AND (is_allowed_ip OR is_internal_token)
use_backend api_write if is_api is_write_method { is_allowed_ip || is_internal }

7.2 Practical Example: Multi-Condition Routing

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # ACL definitions
    acl host_api       hdr(host) -i api.example.com
    acl is_v2          path_beg /v2
    acl is_post        method POST
    acl is_large_body  req.body_len gt 1048576
    acl is_json        hdr(Content-Type) -m sub application/json
    acl office_hours   http-date(req.date) -m str "Mon"-"Fri"

    # Deny large POST bodies that aren't JSON
    http-request deny deny_status 413 if host_api is_post is_large_body !is_json

    # Route API v2 POST to write cluster
    use_backend api_v2_write if host_api is_v2 is_post

    # Route API v2 reads to read replicas
    use_backend api_v2_read if host_api is_v2

    # All other API traffic
    use_backend api_v1_servers if host_api

    default_backend web_servers

---

8. Redirects and Rewrites with ACLs

8.1 HTTP to HTTPS Redirect

frontend http_front
    bind *:80
    mode http

    # Allow ACME challenge through
    acl is_acme path_beg /.well-known/acme-challenge/
    use_backend acme_backend if is_acme

    # Redirect everything else to HTTPS
    http-request redirect scheme https code 301 unless is_acme

8.2 www to non-www Redirect

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    acl host_www hdr_beg(host) -i www.
    http-request redirect prefix https://example.com code 301 if host_www

8.3 Trailing Slash Normalisation

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Add trailing slash if path has no extension and doesn't end with /
    acl no_trailing_slash path_reg ^/[^.]+[^/]$
    http-request redirect code 301 location %[url,regsub(^([^?]*[^/])(\?.*)?$,\1/\2,)] if no_trailing_slash

8.4 Maintenance Mode

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Enable maintenance mode by creating the file
    acl maintenance_mode nbsrv(web_servers) lt 1
    acl is_allowed_ip src -f /etc/haproxy/lists/admin-ips.lst
    acl is_health path /health

    # Allow admins and health checks through
    http-request deny deny_status 503 if maintenance_mode !is_allowed_ip !is_health

    default_backend web_servers

---

9. Advanced Map-Based Routing

9.1 Combined Host + Path Map

# /etc/haproxy/maps/host-path-backend.map
api.example.com/v1     api_v1_servers
api.example.com/v2     api_v2_servers
www.example.com/blog   blog_servers
www.example.com/shop   shop_servers

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Concatenate host and path_beg for map lookup
    http-request set-var(txn.host_path) req.hdr(host),lower,concat(,path),map_beg(/etc/haproxy/maps/host-path-backend.map)

    use_backend %[var(txn.host_path)] if { var(txn.host_path) -m found }
    default_backend web_servers

9.2 A/B Testing with Weighted Map

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    acl is_landing path /

    # Assign 20% of landing page traffic to variant B
    # Use a random value 0-99 stored in a variable
    http-request set-var(txn.rand) rand,mod(100)
    acl is_variant_b var(txn.rand) -m int lt 20

    use_backend landing_variant_b if is_landing is_variant_b
    use_backend landing_variant_a if is_landing
    default_backend web_servers

backend landing_variant_a
    mode http
    http-response add-header Set-Cookie "ab_test=variant_a; Path=/; Max-Age=86400"
    server va1 10.0.20.10:80 check

backend landing_variant_b
    mode http
    http-response add-header Set-Cookie "ab_test=variant_b; Path=/; Max-Age=86400"
    server vb1 10.0.21.10:80 check

---

10. Request Sanitisation and Security ACLs

10.1 Blocking Malicious Paths

# /etc/haproxy/lists/blocked-paths.lst
/.env
/wp-login.php
/wp-admin
/xmlrpc.php
/phpmyadmin
/actuator
/.git
/config.json
/.aws

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Block known attack paths
    acl is_blocked_path path_beg -i -f /etc/haproxy/lists/blocked-paths.lst

    # Block path traversal attempts
    acl has_path_traversal path_sub ..

    # Block suspiciously long URLs (potential buffer overflow)
    acl url_too_long url_len gt 8192

    # Block requests with null bytes
    acl has_null_byte path_sub %00

    # Block common SQL injection patterns in query string
    acl sql_injection query -m reg -i (union.*select|insert.*into|drop.*table|;\s*--|/\*.*\*/)

    http-request deny deny_status 403 if is_blocked_path
    http-request deny deny_status 400 if has_path_traversal
    http-request deny deny_status 414 if url_too_long
    http-request deny deny_status 400 if has_null_byte
    http-request deny deny_status 403 if sql_injection

    # Log denied requests
    http-request set-var(txn.denied) str(1) if is_blocked_path || has_path_traversal || url_too_long || has_null_byte || sql_injection

    default_backend web_servers

10.2 Rate-Limited Endpoint Protection

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Sensitive endpoints ACLs
    acl is_login path_beg /login /auth/token
    acl is_signup path_beg /signup /register

    # Use stick table to track per-IP rate on login
    stick-table type ipv6 size 100k expire 60s store http_req_rate(60s)
    http-request track-sc0 src if is_login

    # Deny if more than 10 login attempts per minute
    acl login_rate_exceeded sc_http_req_rate(0) gt 10
    http-request deny deny_status 429 if is_login login_rate_exceeded

    default_backend web_servers

---

11. Debugging and Validating ACLs

11.1 Configuration Validation

# Always validate before reloading
sudo haproxy -c -f /etc/haproxy/haproxy.cfg

# Expected output:
# Configuration file is valid

11.2 Debug Logging with ACL Variables

frontend https_front
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # Capture headers for logging
    http-request capture req.hdr(Host) len 64
    http-request capture req.hdr(User-Agent) len 128

    # Store matched backend name in variable for logging
    acl is_api path_beg /api
    http-request set-var(txn.route) str(api) if is_api
    http-request set-var(txn.route) str(web) unless is_api

    # Custom log format showing route decision
    log-format "%ci:%cp [%tr] %ft %b/%s %TR/%Tw/%Tc/%Tr/%Ta %ST %B %CC %CS %tsc %ac/%fc/%bc/%sc/%rc %sq/%bq %hr %hs route=%[var(txn.route)] %{+Q}r"

    use_backend api_servers if is_api
    default_backend web_servers

11.3 Runtime ACL Testing

# Show current ACLs in a frontend
echo "show acl" | socat stdio /var/run/haproxy/admin.sock

# Show map entries
echo "show map /etc/haproxy/maps/domain-to-backend.map" | socat stdio /var/run/haproxy/admin.sock

# Test a specific lookup against a map
echo "get map /etc/haproxy/maps/domain-to-backend.map api.example.com" | socat stdio /var/run/haproxy/admin.sock

11.4 Testing with curl

# Test path-based routing
curl -v http://localhost/api/v1/users
curl -v http://localhost/static/style.css

# Test host-based routing
curl -v -H "Host: api.example.com" http://localhost/v1/users
curl -v -H "Host: blog.example.com" http://localhost/

# Test header-based routing
curl -v -H "X-Canary: true" http://localhost/api/test
curl -v -H "Content-Type: application/json" -X POST -d '{"test":1}' http://localhost/api/data

# Test cookie-based routing
curl -v -b "ab_test=variant_b" http://localhost/

# Test denied paths
curl -v http://localhost/.env
curl -v http://localhost/../../etc/passwd

---

12. Complete Production Configuration

Here is a comprehensive HAProxy configuration combining all the techniques discussed:

global
    log /dev/log local0
    log /dev/log local1 notice
    chroot /var/lib/haproxy
    stats socket /var/run/haproxy/admin.sock mode 660 level admin
    stats timeout 30s
    user haproxy
    group haproxy
    daemon
    maxconn 50000
    ssl-default-bind-ciphersuites TLS_AES_128_GCM_SHA256:TLS_AES_256_GCM_SHA384:TLS_CHACHA20_POLY1305_SHA256
    ssl-default-bind-options prefer-client-ciphers no-sslv3 no-tlsv10 no-tlsv11
    tune.ssl.default-dh-param 2048

defaults
    log     global
    mode    http
    option  httplog
    option  dontlognull
    option  forwardfor
    option  http-server-close
    timeout connect 5s
    timeout client  30s
    timeout server  30s
    timeout http-request 10s
    timeout http-keep-alive 5s
    errorfile 400 /etc/haproxy/errors/400.http
    errorfile 403 /etc/haproxy/errors/403.http
    errorfile 408 /etc/haproxy/errors/408.http
    errorfile 500 /etc/haproxy/errors/500.http
    errorfile 502 /etc/haproxy/errors/502.http
    errorfile 503 /etc/haproxy/errors/503.http
    errorfile 504 /etc/haproxy/errors/504.http

frontend http_redirect
    bind *:80
    mode http
    acl is_acme path_beg /.well-known/acme-challenge/
    use_backend acme_backend if is_acme
    http-request redirect scheme https code 301 unless is_acme

frontend https_main
    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1
    mode http

    # --- Request ID and Forwarding ---
    http-request set-header X-Request-ID %[uuid()]
    http-request set-header X-Forwarded-Proto https
    http-request set-header X-Real-IP %[src]
    http-request del-header Proxy

    # --- Security ACLs ---
    acl is_blocked_path path_beg -i -f /etc/haproxy/lists/blocked-paths.lst
    acl has_path_traversal path_sub ..
    acl url_too_long url_len gt 8192
    http-request deny deny_status 403 if is_blocked_path
    http-request deny deny_status 400 if has_path_traversal
    http-request deny deny_status 414 if url_too_long

    # --- Host ACLs ---
    acl host_www     hdr(host) -i www.example.com example.com
    acl host_api     hdr(host) -i api.example.com
    acl host_blog    hdr(host) -i blog.example.com
    acl host_admin   hdr(host) -i admin.example.com

    # --- Path ACLs ---
    acl is_api_v1    path_beg /api/v1
    acl is_api_v2    path_beg /api/v2
    acl is_static    path_beg /static /assets
    acl is_health    path /health /ready
    acl is_ws        path_beg /ws

    # --- Method ACLs ---
    acl is_write     method POST PUT PATCH DELETE

    # --- Admin protection ---
    acl is_allowed_admin src -f /etc/haproxy/lists/admin-ips.lst
    http-request deny deny_status 403 if host_admin !is_allowed_admin

    # --- Canary header ---
    acl is_canary hdr(X-Canary) -i true

    # --- www redirect ---
    acl host_www_prefix hdr_beg(host) -i www.
    http-request redirect prefix https://example.com code 301 if host_www_prefix

    # --- Routing rules (order matters: most specific first) ---
    use_backend health_check        if is_health
    use_backend websocket_servers   if host_api is_ws
    use_backend api_v2_write        if host_api is_api_v2 is_write
    use_backend api_v2_canary       if host_api is_api_v2 is_canary
    use_backend api_v2_read         if host_api is_api_v2
    use_backend api_v1_servers      if host_api is_api_v1
    use_backend api_v1_servers      if host_api
    use_backend blog_servers        if host_blog
    use_backend admin_servers       if host_admin
    use_backend static_servers      if is_static
    default_backend web_servers

    # --- Response hardening ---
    http-response del-header Server
    http-response del-header X-Powered-By
    http-response set-header X-Content-Type-Options nosniff
    http-response set-header X-Frame-Options SAMEORIGIN

# --- Backends ---
backend health_check
    mode http
    http-request return status 200 content-type text/plain string "OK"

backend web_servers
    mode http
    balance roundrobin
    option httpchk GET /health
    http-check expect status 200
    server web1 10.0.1.10:80 check inter 5s fall 3 rise 2
    server web2 10.0.1.11:80 check inter 5s fall 3 rise 2

backend api_v1_servers
    mode http
    balance leastconn
    option httpchk GET /api/v1/ping
    http-check expect status 200
    server apiv1a 10.0.2.10:8080 check inter 3s fall 3 rise 2
    server apiv1b 10.0.2.11:8080 check inter 3s fall 3 rise 2

backend api_v2_read
    mode http
    balance roundrobin
    option httpchk GET /api/v2/ping
    http-check expect status 200
    server apiv2r1 10.0.3.10:8080 check inter 3s fall 3 rise 2
    server apiv2r2 10.0.3.11:8080 check inter 3s fall 3 rise 2
    server apiv2r3 10.0.3.12:8080 check inter 3s fall 3 rise 2

backend api_v2_write
    mode http
    balance leastconn
    option httpchk GET /api/v2/ping
    http-check expect status 200
    server apiv2w1 10.0.4.10:8080 check inter 3s fall 3 rise 2
    server apiv2w2 10.0.4.11:8080 check inter 3s fall 3 rise 2

backend api_v2_canary
    mode http
    balance roundrobin
    server canary1 10.0.5.10:8080 check inter 3s fall 3 rise 2

backend blog_servers
    mode http
    balance roundrobin
    server blog1 10.0.6.10:80 check
    server blog2 10.0.6.11:80 check

backend admin_servers
    mode http
    balance roundrobin
    server admin1 10.0.7.10:8443 check ssl verify none

backend static_servers
    mode http
    balance roundrobin
    http-response set-header Cache-Control "public, max-age=31536000, immutable"
    server static1 10.0.8.10:80 check
    server static2 10.0.8.11:80 check

backend websocket_servers
    mode http
    balance source
    timeout tunnel 3600s
    timeout server 3600s
    server ws1 10.0.9.10:8081 check
    server ws2 10.0.9.11:8081 check

backend acme_backend
    mode http
    server acme 127.0.0.1:8888

---

13. Performance Considerations

• ACL evaluation order — HAProxy evaluates

  use_backend

  directives top-to-bottom and stops at the first match. Place the most frequent routes first to minimise evaluation overhead.
• Map files vs inline ACLs — For more than 20 entries, use

  map

  or

  -f

  file-based ACLs. Map lookups are O(1) hash lookups; long inline ACL value lists are scanned linearly.
• Regex ACLs —

  path_reg

  is significantly slower than

  path_beg

  or

  path_end

  . Avoid regex when a prefix or suffix match suffices.
• Variable caching — Use

  set-var(txn.xxx)

  to store expensive fetch results and reference them multiple times rather than re-evaluating.
• Stick table memory — Each stick table entry consumes memory. Size tables appropriately and set

  expire

  values to prevent unbounded growth.

---

14. Frequently Asked Questions
