HAProxy Backend Health Checks: TCP, HTTP, Custom Checks, Inter, Fall/Rise Tuning, and Agent Checks

Introduction

Backend health checks are the heartbeat of any HAProxy deployment. Without proper health checking, HAProxy blindly sends traffic to servers that may be down, degraded, or in a maintenance window — causing 502 errors, timeouts, and user-facing outages. This guide covers every health check mechanism HAProxy offers, from simple TCP connect probes to sophisticated external agent checks, with real production configurations you can deploy today.

We will walk through TCP checks, Layer 7 HTTP checks, custom check scripts, external agent checks, advanced

http-check

directives introduced in HAProxy 2.2+, and the critical timing parameters (

inter

,

fall

,

rise

,

timeout check

) that control how fast HAProxy detects failures and recovers servers.

---

1. Understanding HAProxy Health Check Architecture

HAProxy health checks run in a dedicated subsystem, separate from data-path connections. Each backend server gets its own check task that operates on an independent timer. Key concepts:

• Check interval (inter) — how often HAProxy probes the server
• Fall threshold — how many consecutive failed checks before marking server DOWN
• Rise threshold — how many consecutive passed checks before marking server UP
• Check timeout — how long to wait for a health check response before declaring failure
• Check address/port — optionally probe a different IP or port than the data path

The default behavior (no

option

directive) is a Layer 4 TCP connect check — HAProxy opens a TCP socket and considers the server healthy if the three-way handshake completes. This is fast but tells you nothing about application health.

---

2. Layer 4 TCP Health Checks

TCP checks are the simplest and lowest-overhead option. HAProxy performs a TCP connect to the server's IP and port, then immediately closes the connection.

2.1 Basic TCP Check

backend bk_infrarunbook_app
    mode tcp
    balance roundrobin
    option tcp-check
    server srv-infrarunbook-01 10.10.50.11:3306 check inter 5s fall 3 rise 2
    server srv-infrarunbook-02 10.10.50.12:3306 check inter 5s fall 3 rise 2

When you add the

check

keyword to a server line, HAProxy enables health checking. The

option tcp-check

line explicitly selects Layer 4 mode (this is also the default when no other check option is specified).

2.2 TCP Check with Send/Expect Sequences

For protocols that require a handshake (MySQL, Redis, SMTP), you can script the conversation:

backend bk_infrarunbook_redis
    mode tcp
    balance roundrobin
    option tcp-check
    tcp-check connect
    tcp-check send "PING\r\n"
    tcp-check expect string +PONG
    server redis-infrarunbook-01 10.10.50.21:6379 check inter 3s fall 3 rise 2
    server redis-infrarunbook-02 10.10.50.22:6379 check inter 3s fall 3 rise 2

This sends the Redis

PING

command and expects

+PONG

in response. If the server responds with an error or the connection is refused, the check fails.

2.3 MySQL TCP Health Check

backend bk_infrarunbook_mysql
    mode tcp
    balance leastconn
    option tcp-check
    tcp-check connect
    tcp-check expect binary 0a   # MySQL greeting starts with protocol version 10 (0x0a)
    server db-infrarunbook-01 10.10.50.31:3306 check inter 5s fall 3 rise 2
    server db-infrarunbook-02 10.10.50.32:3306 check inter 5s fall 3 rise 2

2.4 SMTP TCP Health Check

backend bk_infrarunbook_smtp
    mode tcp
    option tcp-check
    tcp-check connect
    tcp-check expect rstring ^220
    tcp-check send "EHLO solvethenetwork.com\r\n"
    tcp-check expect rstring ^250
    tcp-check send "QUIT\r\n"
    tcp-check expect rstring ^221
    server smtp-infrarunbook-01 10.10.50.41:25 check inter 10s fall 3 rise 2

---

3. Layer 7 HTTP Health Checks

HTTP health checks are the most common choice for web application backends. HAProxy sends a real HTTP request and inspects the response status code, headers, or body.

3.1 Basic HTTP Check (Legacy Syntax)

backend bk_infrarunbook_web
    mode http
    balance roundrobin
    option httpchk GET /healthz HTTP/1.1\r\nHost:\ app.solvethenetwork.com
    http-check expect status 200
    server web-infrarunbook-01 10.10.50.51:8080 check inter 3s fall 3 rise 2
    server web-infrarunbook-02 10.10.50.52:8080 check inter 3s fall 3 rise 2
    server web-infrarunbook-03 10.10.50.53:8080 check inter 3s fall 3 rise 2

The

option httpchk

directive defines the HTTP method, path, and optional headers. The

http-check expect

line tells HAProxy what a healthy response looks like.

3.2 Modern HTTP Check Syntax (HAProxy 2.2+)

HAProxy 2.2 introduced a structured

http-check

syntax that is cleaner and more powerful:

backend bk_infrarunbook_api
    mode http
    balance leastconn

    option httpchk
    http-check connect
    http-check send meth GET uri /api/v1/health ver HTTP/1.1 hdr Host app.solvethenetwork.com hdr User-Agent "HAProxy-HealthCheck/2.8"
    http-check expect status 200

    server api-infrarunbook-01 10.10.50.61:8443 check inter 3s fall 3 rise 2 ssl verify none
    server api-infrarunbook-02 10.10.50.62:8443 check inter 3s fall 3 rise 2 ssl verify none
    server api-infrarunbook-03 10.10.50.63:8443 check inter 3s fall 3 rise 2 ssl verify none

3.3 Multiple Expect Conditions

You can chain multiple expectations. HAProxy 2.2+ supports complex matching:

backend bk_infrarunbook_portal
    mode http
    option httpchk
    http-check send meth GET uri /healthz ver HTTP/1.1 hdr Host portal.solvethenetwork.com
    http-check expect status 200
    http-check expect header name "Content-Type" value "application/json"
    http-check expect string "status":"healthy"

    server portal-infrarunbook-01 10.10.50.71:8080 check inter 5s fall 3 rise 2
    server portal-infrarunbook-02 10.10.50.72:8080 check inter 5s fall 3 rise 2

3.4 Expect Patterns Reference

• http-check expect status 200

  — exact status code match

• http-check expect status 200-299

  — status code range

• http-check expect ! status 503

  — negation (anything except 503)

• http-check expect string OK

  — body contains exact string

• http-check expect rstring ^{"status":"(ok|healthy)"}

  — body matches regex

• http-check expect header name "X-Health" value "up"

  — response header match

3.5 Checking a Different Port

Some applications expose a health endpoint on a management port separate from the data port:

backend bk_infrarunbook_grpc
    mode tcp
    balance roundrobin

    option httpchk
    http-check send meth GET uri /healthz ver HTTP/1.1 hdr Host grpc.solvethenetwork.com
    http-check expect status 200

    server grpc-infrarunbook-01 10.10.50.81:50051 check port 8081 inter 5s fall 3 rise 2
    server grpc-infrarunbook-02 10.10.50.82:50051 check port 8081 inter 5s fall 3 rise 2

The

check port 8081

directive tells HAProxy to run the HTTP health check against port 8081 while forwarding real traffic to port 50051.

3.6 Checking a Different IP Address

    server app-infrarunbook-01 10.10.50.91:8080 check addr 10.10.50.91 port 8081 inter 3s fall 3 rise 2

The

addr

keyword lets you probe a different IP (useful when health endpoints listen on a management interface).

---

4. Inter, Fall, Rise, and Timeout Tuning

Getting these parameters right is the difference between sub-second failover and minutes of downtime.

4.1 Parameter Definitions

• inter <time> — interval between checks when server is in its current state (default: 2s)
• fastinter <time> — interval between checks during a state transition (optional, defaults to inter)
• downinter <time> — interval between checks when server is DOWN (optional, defaults to inter)
• fall <count> — consecutive failed checks to mark server DOWN (default: 3)
• rise <count> — consecutive passed checks to mark server UP (default: 2)
• timeout check <time> — maximum time to wait for a check response (uses

  timeout server

  if not set)

4.2 Calculating Failover Time

The worst-case time to detect a failure is:

detection_time = inter × fall

# Example: inter 3s, fall 3
detection_time = 3s × 3 = 9 seconds (worst case)

The average detection time is roughly:

avg_detection_time = inter × (fall - 0.5)

# Example: inter 3s, fall 3
avg_detection_time = 3s × 2.5 = 7.5 seconds

4.3 Aggressive Health Checking for Low-Latency Failover

backend bk_infrarunbook_critical
    mode http
    balance roundrobin
    option httpchk
    http-check send meth GET uri /healthz ver HTTP/1.1 hdr Host critical.solvethenetwork.com
    http-check expect status 200
    timeout check 2s

    default-server inter 1s fastinter 500ms downinter 5s fall 2 rise 3

    server crit-infrarunbook-01 10.10.50.101:8080 check
    server crit-infrarunbook-02 10.10.50.102:8080 check
    server crit-infrarunbook-03 10.10.50.103:8080 check

This configuration yields:

• Worst-case detection: 1s × 2 = 2 seconds
• During transitions, checks run every 500ms for faster resolution
• Once a server is confirmed DOWN, checks slow to every 5s to reduce load
• A server must pass 3 consecutive checks (3 × 500ms = 1.5s minimum) before returning to UP

4.4 Conservative Health Checking for Stable Backends

backend bk_infrarunbook_static
    mode http
    balance roundrobin
    option httpchk
    http-check send meth GET uri /ping ver HTTP/1.1 hdr Host static.solvethenetwork.com
    http-check expect status 200
    timeout check 5s

    default-server inter 10s fall 5 rise 3

    server static-infrarunbook-01 10.10.50.111:80 check
    server static-infrarunbook-02 10.10.50.112:80 check

Slower checks, higher fall threshold — less probe traffic and more tolerance for transient glitches.

4.5 Tuning Guidelines Table

┌─────────────────────┬────────────┬──────────┬───────────┬───────────────────────┐
│ Use Case            │ inter      │ fall     │ rise      │ Worst-Case Detection  │
├─────────────────────┼────────────┼──────────┼───────────┼───────────────────────┤
│ Real-time API       │ 1s         │ 2        │ 3         │ 2 seconds             │
│ Standard web app    │ 3s         │ 3        │ 2         │ 9 seconds             │
│ Background workers  │ 10s        │ 5        │ 3         │ 50 seconds            │
│ Database proxy      │ 5s         │ 3        │ 2         │ 15 seconds            │
│ CDN / static files  │ 30s        │ 3        │ 2         │ 90 seconds            │
└─────────────────────┴────────────┴──────────┴───────────┴───────────────────────┘

---

5. External Check (Script-Based)

For complex health validation that can't be expressed in TCP or HTTP patterns, HAProxy can execute an external script. The script's exit code determines the check result (0 = success, non-zero = failure).

5.1 Enable External Checks in Global Section

global
    log /dev/log local0
    external-check
    insecure-fork-wanted

Security Note: External checks fork a new process for every check. This has performance implications and requires

insecure-fork-wanted

in HAProxy 2.x. Use external checks only when TCP/HTTP checks are insufficient.

5.2 External Check Script

Create the check script at

/etc/haproxy/checks/check_infrarunbook_app.sh

:

#!/bin/bash
# External health check for infrarunbook application
# Arguments passed by HAProxy:
#   $1 = server address
#   $2 = server port
#   $3 = server name

SERVER_ADDR="$1"
SERVER_PORT="$2"

# Check application health endpoint
RESPONSE=$(curl -s -o /dev/null -w "%{http_code}" \
  --connect-timeout 2 \
  --max-time 5 \
  "http://${SERVER_ADDR}:${SERVER_PORT}/healthz")

if [ "$RESPONSE" = "200" ]; then
    # Check that the app reports healthy database connectivity
    DB_STATUS=$(curl -s --connect-timeout 2 --max-time 5 \
      "http://${SERVER_ADDR}:${SERVER_PORT}/healthz" | \
      python3 -c "import sys,json; print(json.load(sys.stdin).get('database','unknown'))" 2>/dev/null)
    if [ "$DB_STATUS" = "connected" ]; then
        exit 0
    fi
fi

exit 1

chmod 755 /etc/haproxy/checks/check_infrarunbook_app.sh
chown haproxy:haproxy /etc/haproxy/checks/check_infrarunbook_app.sh

5.3 Backend Configuration

backend bk_infrarunbook_complex
    mode http
    balance roundrobin
    option external-check
    external-check path "/usr/bin:/usr/local/bin:/bin"
    external-check command /etc/haproxy/checks/check_infrarunbook_app.sh

    server complex-infrarunbook-01 10.10.50.121:8080 check inter 10s fall 3 rise 2
    server complex-infrarunbook-02 10.10.50.122:8080 check inter 10s fall 3 rise 2

---

6. Agent Health Checks

Agent checks are a powerful mechanism where HAProxy connects to a small agent daemon running on each backend server. The agent responds with a string that can dynamically control the server's state, weight, and administrative status — enabling graceful draining and load-aware balancing.

6.1 Agent Protocol

The agent is a TCP service that returns one or more keywords separated by commas:

• up

  — mark server operationally UP

• down

  — mark server operationally DOWN

• drain

  — stop sending new connections (existing ones continue)

• maint

  — put server in maintenance mode

• ready

  — remove administrative drain/maint status

• 50%

  — set server weight to 50% of its configured value

• maxconn:100

  — set dynamic maxconn limit

6.2 Simple Agent Script (Python)

Create

/opt/infrarunbook/haproxy-agent.py

:

#!/usr/bin/env python3
"""HAProxy agent check for infrarunbook application.

Listens on port 9707 and returns server status.
"""
import socket
import subprocess
import sys

def get_status():
    """Check local application health and return agent string."""
    try:
        # Check if application is running
        result = subprocess.run(
            ['systemctl', 'is-active', 'infrarunbook-app'],
            capture_output=True, text=True, timeout=3
        )
        if result.stdout.strip() != 'active':
            return 'down\n'

        # Check application load (CPU-based weight adjustment)
        with open('/proc/loadavg', 'r') as f:
            load_1m = float(f.read().split()[0])

        import multiprocessing
        cpu_count = multiprocessing.cpu_count()
        load_pct = (load_1m / cpu_count) * 100

        if load_pct > 95:
            return 'drain\n'
        elif load_pct > 80:
            return 'up 25%\n'
        elif load_pct > 60:
            return 'up 50%\n'
        elif load_pct > 40:
            return 'up 75%\n'
        else:
            return 'up 100%\n'
    except Exception:
        return 'down\n'

def main():
    server = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
    server.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEADDR, 1)
    server.bind(('0.0.0.0', 9707))
    server.listen(5)
    print('HAProxy agent listening on port 9707', flush=True)

    while True:
        client, addr = server.accept()
        try:
            status = get_status()
            client.sendall(status.encode())
        finally:
            client.close()

if __name__ == '__main__':
    main()

6.3 Systemd Service for the Agent

[Unit]
Description=HAProxy Agent Check for infrarunbook
After=network.target

[Service]
ExecStart=/usr/bin/python3 /opt/infrarunbook/haproxy-agent.py
Restart=always
RestartSec=5
User=nobody
Group=nogroup

[Install]
WantedBy=multi-user.target

systemctl daemon-reload
systemctl enable --now haproxy-agent-infrarunbook.service

6.4 HAProxy Backend with Agent Checks

backend bk_infrarunbook_dynamic
    mode http
    balance roundrobin
    option httpchk
    http-check send meth GET uri /healthz ver HTTP/1.1 hdr Host app.solvethenetwork.com
    http-check expect status 200

    server dyn-infrarunbook-01 10.10.50.131:8080 check inter 3s fall 3 rise 2 agent-check agent-port 9707 agent-inter 5s
    server dyn-infrarunbook-02 10.10.50.132:8080 check inter 3s fall 3 rise 2 agent-check agent-port 9707 agent-inter 5s
    server dyn-infrarunbook-03 10.10.50.133:8080 check inter 3s fall 3 rise 2 agent-check agent-port 9707 agent-inter 5s

This combines both a standard HTTP health check and an agent check. The HTTP check gates UP/DOWN status, while the agent dynamically adjusts weight. Both must pass for the server to receive traffic.

---

7. Graceful Server Drain with Health Checks

Before taking a server out for maintenance, you want to drain existing connections gracefully.

7.1 Using the Runtime API

# Set server to DRAIN mode (no new connections, existing ones finish)
echo "set server bk_infrarunbook_web/web-infrarunbook-01 state drain" | \
  socat stdio /var/run/haproxy/admin.sock

# Check current sessions
echo "show servers state bk_infrarunbook_web" | \
  socat stdio /var/run/haproxy/admin.sock

# Wait for connections to drain, then set to MAINT
echo "set server bk_infrarunbook_web/web-infrarunbook-01 state maint" | \
  socat stdio /var/run/haproxy/admin.sock

# After maintenance, bring server back
echo "set server bk_infrarunbook_web/web-infrarunbook-01 state ready" | \
  socat stdio /var/run/haproxy/admin.sock

7.2 Using the Agent Check for Zero-Downtime Deploys

Your deployment script can toggle the agent response:

#!/bin/bash
# deploy-infrarunbook.sh — Zero-downtime deploy
SERVER="dyn-infrarunbook-01"
BACKEND="bk_infrarunbook_dynamic"
SOCK="/var/run/haproxy/admin.sock"

# 1. Signal drain via agent file
echo "drain" > /opt/infrarunbook/agent-status.txt
sleep 30  # Wait for connections to drain

# 2. Deploy new version
systemctl stop infrarunbook-app
rsync -a /opt/infrarunbook/releases/latest/ /opt/infrarunbook/current/
systemctl start infrarunbook-app
sleep 5  # Let app warm up

# 3. Signal ready
echo "up 100%" > /opt/infrarunbook/agent-status.txt

---

8. Monitoring Health Check Status

8.1 Stats Page

frontend ft_infrarunbook_stats
    bind 10.10.50.1:9000
    mode http
    stats enable
    stats uri /haproxy-stats
    stats realm "InfraRunBook HAProxy Stats"
    stats auth infrarunbook-admin:S3cur3P@ssw0rd!
    stats refresh 5s
    stats show-legends
    stats show-node

The stats page displays each server's check status, last check duration, number of consecutive failures, and current weight — essential for health check debugging.

8.2 Prometheus Metrics

frontend ft_infrarunbook_prometheus
    bind 10.10.50.1:8405
    mode http
    http-request use-service prometheus-exporter if { path /metrics }
    no log

Key metrics to watch:

• haproxy_server_check_failures_total

  — cumulative check failures

• haproxy_server_check_duration_seconds

  — check latency

• haproxy_server_status

  — current UP/DOWN/DRAIN/MAINT status

• haproxy_server_weight

  — effective weight (affected by agent checks)

8.3 Log-Based Monitoring

Enable check logging to see state transitions in your syslog:

global
    log /dev/log local0 info

defaults
    log global
    option log-health-checks

With

option log-health-checks

, HAProxy logs every state transition:

Feb 17 09:42:15 lb-infrarunbook-01 haproxy[2847]: Health check for server bk_infrarunbook_web/web-infrarunbook-02 failed, reason: Layer7 wrong status, code: 503, check duration: 12ms, status: 2/3 DOWN.
Feb 17 09:42:18 lb-infrarunbook-01 haproxy[2847]: Health check for server bk_infrarunbook_web/web-infrarunbook-02 failed, reason: Layer7 wrong status, code: 503, check duration: 8ms, status: 0/3 DOWN.
Feb 17 09:42:48 lb-infrarunbook-01 haproxy[2847]: Health check for server bk_infrarunbook_web/web-infrarunbook-02 succeeded, reason: Layer7 check passed, code: 200, check duration: 5ms, status: 3/3 UP.

---

9. Complete Production Configuration

Here is a full, production-ready configuration combining all techniques:

#---------------------------------------------------------------------
# Global settings — lb-infrarunbook-01
#---------------------------------------------------------------------
global
    log /dev/log    local0
    log /dev/log    local1 notice
    chroot /var/lib/haproxy
    stats socket /var/run/haproxy/admin.sock mode 660 level admin expose-fd listeners
    stats timeout 30s
    user haproxy
    group haproxy
    daemon
    maxconn 50000
    ssl-default-bind-ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256
    ssl-default-bind-ciphersuites TLS_AES_128_GCM_SHA256:TLS_AES_256_GCM_SHA384
    ssl-default-bind-options ssl-min-ver TLSv1.2 no-tls-tickets
    tune.ssl.default-dh-param 2048

#---------------------------------------------------------------------
# Defaults
#---------------------------------------------------------------------
defaults
    log     global
    option  httplog
    option  dontlognull
    option  log-health-checks
    timeout connect 5s
    timeout client  30s
    timeout server  30s
    timeout check   3s
    retries 3
    default-server inter 3s fall 3 rise 2

#---------------------------------------------------------------------
# Stats frontend
#---------------------------------------------------------------------
frontend ft_infrarunbook_stats
    bind 10.10.50.1:9000
    mode http
    stats enable
    stats uri /haproxy-stats
    stats auth infrarunbook-admin:S3cur3P@ssw0rd!
    stats refresh 5s

#---------------------------------------------------------------------
# Main HTTP frontend
#---------------------------------------------------------------------
frontend ft_infrarunbook_https
    bind *:443 ssl crt /etc/haproxy/certs/solvethenetwork.com.pem alpn h2,http/1.1
    mode http
    http-request set-header X-Forwarded-Proto https

    acl is_api path_beg /api/
    acl is_static path_beg /static/ /assets/ /images/
    acl is_ws hdr(Upgrade) -i websocket

    use_backend bk_infrarunbook_api if is_api
    use_backend bk_infrarunbook_static if is_static
    use_backend bk_infrarunbook_ws if is_ws
    default_backend bk_infrarunbook_web

#---------------------------------------------------------------------
# Web backend — HTTP health check
#---------------------------------------------------------------------
backend bk_infrarunbook_web
    mode http
    balance roundrobin
    option httpchk
    http-check send meth GET uri /healthz ver HTTP/1.1 hdr Host app.solvethenetwork.com
    http-check expect status 200

    server web-infrarunbook-01 10.10.50.51:8080 check weight 100
    server web-infrarunbook-02 10.10.50.52:8080 check weight 100
    server web-infrarunbook-03 10.10.50.53:8080 check weight 100 backup

#---------------------------------------------------------------------
# API backend — HTTP check + agent check for load-aware balancing
#---------------------------------------------------------------------
backend bk_infrarunbook_api
    mode http
    balance leastconn
    option httpchk
    http-check send meth GET uri /api/v1/health ver HTTP/1.1 hdr Host api.solvethenetwork.com
    http-check expect status 200
    http-check expect string "status":"healthy"

    default-server inter 2s fastinter 500ms fall 2 rise 3

    server api-infrarunbook-01 10.10.50.61:8080 check agent-check agent-port 9707 agent-inter 5s
    server api-infrarunbook-02 10.10.50.62:8080 check agent-check agent-port 9707 agent-inter 5s
    server api-infrarunbook-03 10.10.50.63:8080 check agent-check agent-port 9707 agent-inter 5s

#---------------------------------------------------------------------
# Static backend — lightweight check, long interval
#---------------------------------------------------------------------
backend bk_infrarunbook_static
    mode http
    balance roundrobin
    option httpchk
    http-check send meth HEAD uri /static/health.txt ver HTTP/1.1 hdr Host static.solvethenetwork.com
    http-check expect status 200

    default-server inter 15s fall 3 rise 2

    server static-infrarunbook-01 10.10.50.111:80 check
    server static-infrarunbook-02 10.10.50.112:80 check

#---------------------------------------------------------------------
# WebSocket backend — TCP check with longer timeouts
#---------------------------------------------------------------------
backend bk_infrarunbook_ws
    mode http
    balance source
    option httpchk
    http-check send meth GET uri /ws/health ver HTTP/1.1 hdr Host ws.solvethenetwork.com
    http-check expect status 200
    timeout tunnel 3600s

    server ws-infrarunbook-01 10.10.50.141:8080 check inter 5s fall 3 rise 2
    server ws-infrarunbook-02 10.10.50.142:8080 check inter 5s fall 3 rise 2

---

10. Troubleshooting Health Checks

10.1 Common Issues and Solutions

• All servers showing DOWN on stats page: Check that the health endpoint returns the expected status code. Test manually with curl:

  curl -v http://10.10.50.51:8080/healthz

• Flapping servers (rapidly switching UP/DOWN): Increase

  fall

  and

  rise

  thresholds; check for intermittent application errors
• Health checks passing but application broken: Your health endpoint isn't checking enough. Add database connectivity, cache availability, and dependency checks to your

  /healthz

  endpoint
• High CPU on backend servers from health checks: Increase

  inter

  or use

  downinter

  to reduce checks against known-DOWN servers; consider

  HEAD

  instead of

  GET

• Check timeout errors: Increase

  timeout check

  or investigate why your health endpoint is slow

10.2 Runtime API Diagnostic Commands

# Show all servers and their check status
echo "show servers state" | socat stdio /var/run/haproxy/admin.sock

# Show detailed backend info
echo "show stat" | socat stdio /var/run/haproxy/admin.sock | \
  cut -d, -f1,2,18,19,20,21,37 | column -s, -t

# Force a health check immediately
echo "set server bk_infrarunbook_web/web-infrarunbook-01 health up" | \
  socat stdio /var/run/haproxy/admin.sock

# Manually disable health checks (USE WITH CAUTION)
echo "disable health bk_infrarunbook_web/web-infrarunbook-01" | \
  socat stdio /var/run/haproxy/admin.sock

# Re-enable health checks
echo "enable health bk_infrarunbook_web/web-infrarunbook-01" | \
  socat stdio /var/run/haproxy/admin.sock

10.3 Simulating Health Check Requests

# Replicate exactly what HAProxy sends
curl -v \
  -H "Host: app.solvethenetwork.com" \
  -H "User-Agent: HAProxy-HealthCheck/2.8" \
  http://10.10.50.51:8080/healthz

# For SSL backend checks
curl -vk \
  -H "Host: api.solvethenetwork.com" \
  https://10.10.50.61:8443/api/v1/health

---

11. Best Practices Summary

1. Always use application-level (HTTP) checks for HTTP backends — TCP checks only prove the port is open, not that the app is healthy
2. Design meaningful health endpoints — check database connections, cache availability, disk space, and critical dependencies
3. Use

   fastinter

   to accelerate state transitions without increasing steady-state probe frequency
4. Use

   downinter

   to reduce load on servers that are already confirmed DOWN
5. Combine HTTP checks with agent checks for load-aware balancing in dynamic environments
6. Set

   timeout check

   explicitly — don't rely on the server timeout for health checks
7. Enable

   option log-health-checks

   so state transitions appear in your logs and alerting
8. Use

   default-server

   to avoid repeating check parameters on every server line
9. Test health checks manually with curl before deploying to production
10. Monitor check duration metrics — increasing check latency is an early warning of server degradation
