How to Install BIND9 on Ubuntu – Complete Step-by-Step Guide

What is BIND9?

BIND9 (Berkeley Internet Name Domain version 9) is the most widely deployed open-source DNS server. It is maintained by ISC (Internet Systems Consortium) and powers a significant portion of internet DNS infrastructure.

• Acts as an authoritative DNS server for your domain zones
• Acts as a recursive resolver for internal networks
• Fully standards-compliant (RFC 1034, 1035)

---

Prerequisites

• Ubuntu 20.04 / 22.04 / 24.04 (any LTS)
• Root or sudo privileges
• A static IP address configured on the server
• Port 53 TCP/UDP open in your firewall

---

Step 1 – Update the System

Always update packages before installing:

sudo apt update && sudo apt upgrade -y

---

Step 2 – Install BIND9

sudo apt install bind9 bind9utils bind9-doc -y

This installs:

• bind9 – the DNS server daemon (

  named

  )
• bind9utils – tools like

  named-checkconf

  ,

  named-checkzone

• bind9-doc – documentation

---

Step 3 – Verify Installation

named -v

Expected output:

BIND 9.18.x (Ubuntu)

---

Step 4 – Configure BIND9 (named.conf.options)

Edit the main options file:

sudo nano /etc/bind/named.conf.options

Replace the contents with a secure baseline configuration:

options {
    directory "/var/cache/bind";

    // Allow recursion only for trusted networks
    recursion yes;
    allow-recursion { 127.0.0.1; 10.0.0.0/8; 192.168.0.0/16; };

    // Listen on all interfaces
    listen-on { any; };
    listen-on-v6 { any; };

    // Forward unresolved queries to public DNS
    forwarders {
        8.8.8.8;
        8.8.4.4;
    };
    forward only;

    // Security hardening
    dnssec-validation auto;
    auth-nxdomain no;
    version none;
};

Important: Restrict

allow-recursion

to your internal subnets only. Never allow open recursion to the internet.

---

Step 5 – Create a Forward Zone

Edit

named.conf.local

to declare your zone:

sudo nano /etc/bind/named.conf.local

Add:

zone "example.local" {
    type master;
    file "/etc/bind/zones/db.example.local";
};

Create the zones directory and zone file:

sudo mkdir -p /etc/bind/zones
sudo cp /etc/bind/db.local /etc/bind/zones/db.example.local
sudo nano /etc/bind/zones/db.example.local

Edit to look like:

$TTL    604800
@   IN  SOA ns1.example.local. admin.example.local. (
              2026021501 ; Serial (YYYYMMDDnn)
              604800     ; Refresh
              86400      ; Retry
              2419200    ; Expire
              604800 )   ; Negative Cache TTL

; Name servers
@       IN  NS      ns1.example.local.

; A records
ns1     IN  A       192.168.1.10
@       IN  A       192.168.1.10
www     IN  A       192.168.1.20

---

Step 6 – Create a Reverse Zone (Optional but Recommended)

Add to

named.conf.local

:

zone "1.168.192.in-addr.arpa" {
    type master;
    file "/etc/bind/zones/db.192.168.1";
};

sudo cp /etc/bind/db.127 /etc/bind/zones/db.192.168.1
sudo nano /etc/bind/zones/db.192.168.1

$TTL    604800
@   IN  SOA ns1.example.local. admin.example.local. (
              2026021501
              604800
              86400
              2419200
              604800 )

@       IN  NS      ns1.example.local.
10      IN  PTR     ns1.example.local.
20      IN  PTR     www.example.local.

---

Step 7 – Validate Configuration

Check for syntax errors before restarting:

sudo named-checkconf

Check each zone file:

sudo named-checkzone example.local /etc/bind/zones/db.example.local
sudo named-checkzone 1.168.192.in-addr.arpa /etc/bind/zones/db.192.168.1

Expected output:

zone example.local/IN: loaded serial 2026021501
OK

---

Step 8 – Start & Enable BIND9

sudo systemctl enable --now named

Verify it is running:

sudo systemctl status named

Expected output:

● named.service - BIND Domain Name Server
   Active: active (running)

---

Step 9 – Configure Firewall

sudo ufw allow 53/tcp
sudo ufw allow 53/udp
sudo ufw reload

---

Step 10 – Test DNS Resolution

From a client on the same network:

nslookup www.example.local 192.168.1.10

Or using

dig

:

dig @192.168.1.10 www.example.local

Expected output:

;; ANSWER SECTION:
www.example.local.  604800  IN  A  192.168.1.20

---

✅ Best Practices

• Always use

  named-checkconf

  before restarting BIND9
• Restrict recursion to internal networks only
• Keep serial numbers updated (use YYYYMMDDNN format) on every zone change
• Enable DNSSEC for production zones
• Monitor BIND9 logs:

  sudo journalctl -u named -f

• Set

  version none;

  to hide BIND version from public

Remember: Always validate zone files after edits. A single syntax error can take down DNS for your entire domain.
