HAProxy Rate Limiting and DDoS Protection Setup

Prerequisites

Before diving in, you'll need HAProxy 2.4 or newer — ideally 2.6+ if you want the full stick table feature set including

sc_http_req_rate

,

sc_bytes_in_rate

, and the newer sample fetch functions. On Ubuntu 22.04 or Debian 12 the default repository version is sufficient. On older distributions, pull from the official HAProxy PPA or compile from source.

You'll also need root or sudo access on sw-infrarunbook-01 (your HAProxy host), a working rsyslog or syslog-ng setup capturing from

local0

, and — critically — a baseline understanding of your normal traffic patterns. In my experience, the single biggest mistake teams make with HAProxy rate limiting is setting thresholds before they know what "normal" looks like. You end up either blocking legitimate users or setting limits so high they're useless against an actual attack.

Also think hard about your network topology before writing a single ACL. If your HAProxy instance sits behind a CDN or another reverse proxy, the

src

sample fetch returns the edge node's IP, not the attacker's. In that case you need to extract the real client IP from a header like

X-Forwarded-For

— but only from upstream sources you actually control. Trusting that header blindly is how attackers spoof their way past your rate limits.

Understanding HAProxy's Rate Limiting Primitives

HAProxy doesn't have a single "rate limiting" toggle. It's built from composable primitives you wire together: stick tables, sample fetches, ACLs, and actions. Stick tables are the core of it. They're in-memory key-value stores that track state per connection source. Each entry can hold counters like concurrent connection count, connection rate, HTTP request rate, HTTP error rate, and bytes transferred — all with configurable sliding time windows.

Think of a stick table entry like this: for source IP

10.0.5.42

, we're tracking how many HTTP requests it has made in the last 10 seconds. When that counter crosses a threshold, an ACL condition evaluates to true, and you act — deny the connection, return a 429, tarpit the socket, redirect to a captcha, whatever fits your policy.

Stick tables have a finite size and an expiry window. Entries that haven't been updated within the expiry interval get evicted. This is intentional — you don't want to hold per-IP state indefinitely — but it means your expiry window must be at least as long as your longest rate window. If you track

http_req_rate(30s)

but set

expire 10s

, entries evict before the window closes and your counters never accumulate. That's a silent misconfiguration that's embarrassingly easy to ship.

Step 1: Kernel Tuning on sw-infrarunbook-01

Get your kernel ready before touching HAProxy config. Under a real SYN flood, the kernel's SYN backlog fills before HAProxy ever sees the connection. Add the following to

/etc/sysctl.d/99-haproxy.conf

:

net.ipv4.ip_local_port_range = 1024 65535
net.ipv4.tcp_tw_reuse = 1
net.core.somaxconn = 65535
net.ipv4.tcp_max_syn_backlog = 65535
net.core.netdev_max_backlog = 65535
net.ipv4.tcp_fin_timeout = 15
net.ipv4.tcp_syncookies = 1

Apply with

sysctl --system

. The

tcp_syncookies

setting is particularly important — it lets the kernel respond to SYN packets without allocating a backlog entry, which is your first line of defense against SYN floods at the kernel level before HAProxy is even involved. Also bump HAProxy's file descriptor limit. Set

maxconn 500000

in your global section and make sure the systemd service override (or

/etc/security/limits.conf

) allows at least that many open files for the haproxy user.

Step 2: Define Your Stick Tables

Stick tables are defined inside

frontend

sections. Here's a table definition that tracks four counters we'll actually use:

frontend fe_https
    bind 10.10.1.10:443 ssl crt /etc/haproxy/certs/solvethenetwork.com.pem alpn h2,http/1.1

    # 200k entries, 60-second expiry
    # Tracks: concurrent connections, connection rate (10s), HTTP request rate (10s),
    # HTTP error rate (10s), inbound bytes rate (10s)
    stick-table type ip size 200k expire 60s \
        store conn_cur,conn_rate(10s),http_req_rate(10s),http_err_rate(10s),bytes_in_rate(10s)

For 200k entries tracking five counters, expect roughly 100-120 MB of memory. On a busy frontend during a real DDoS, you'll want a larger table — I've run 500k-entry tables on 8 GB HAProxy nodes without issue. Size to your threat model, not to what fits comfortably on a development VM.

The

bytes_in_rate(10s)

counter is one I added after dealing with an HTTP POST flood where the attacker was sending multi-megabyte payloads to an upload endpoint. Standard request rate limiting didn't catch it — it was only a handful of requests per second. But the byte rate was enormous and immediately obvious once I was tracking it. Always think about the specific attack surface your application creates, not just generic request rates.

Step 3: Track and Deny at the HTTP Layer

Once the table exists, populate it on every request with

http-request track-sc0

, then define ACL conditions against the stored counters:

    # Populate stick table on every HTTP request
    http-request track-sc0 src

    # Whitelist: internal subnets never get rate limited
    acl src_trusted       src 192.168.100.0/24 10.10.1.0/24

    # ACL conditions from stick table counters
    acl abuse_conn_rate   sc_conn_rate(0)      gt 60
    acl abuse_req_rate    sc_http_req_rate(0)  gt 300
    acl abuse_err_rate    sc_http_err_rate(0)  gt 50
    acl abuse_bytes_in    sc_bytes_in_rate(0)  gt 500000

    # Block high-rate abusers with 429
    http-request deny deny_status 429 if abuse_req_rate  !src_trusted
    http-request deny deny_status 429 if abuse_conn_rate !src_trusted
    http-request deny deny_status 413 if abuse_bytes_in  !src_trusted

    # Tarpit error-heavy IPs (scanners probing endpoints)
    http-request tarpit if abuse_err_rate !src_trusted

The

sc_http_req_rate(0)

sample fetch reads from counter slot 0 — the one populated by

track-sc0

. HAProxy supports three counter slots (

sc0

,

sc1

,

sc2

), which lets you track different keys in the same frontend simultaneously. You could track per-IP in slot 0 and per-URL in slot 1, for example, and make ACL decisions based on either or both.

The error rate ACL deserves special attention. Scanners and credential-stuffing bots generate a disproportionate number of 404s and 401s compared to legitimate traffic. Catching them on error rate often fires before they cross the request rate threshold, because they're not actually hammering you with volume — they're probing methodically. I've caught entire botnet scans this way that would have completely slipped past a pure request-rate limit.

Step 4: Reject Floods at the TCP Layer

HTTP-level rate limiting is great, but it runs after the TLS handshake completes. For a connection flood, you want to reject abusive IPs before burning CPU on TLS negotiation. Use

tcp-request connection

rules for this:

    # TCP-level tracking fires before TLS handshake
    tcp-request connection track-sc0 src
    tcp-request connection reject if { sc_conn_rate(0) gt 100 } !{ src 192.168.100.0/24 10.10.1.0/24 }
    tcp-request connection reject if { sc_conn_cur(0)  gt 200 } !{ src 192.168.100.0/24 10.10.1.0/24 }

Notice the inline ACL syntax here —

{ sc_conn_rate(0) gt 100 }

— rather than named ACLs. Both work, but for TCP-level rules I find inline conditions cleaner since there are typically only one or two of them. The

tcp-request connection reject

sends a TCP RST immediately, before any application data is exchanged. Under a real connection flood, this makes a significant difference in CPU and memory pressure on the HAProxy host.

Step 5: Protect Against Slowloris

Slowloris-style attacks don't flood you with connections — they hold them open indefinitely by sending HTTP headers one byte at a time, preventing the server from ever completing request parsing. You don't need ACLs for this. HAProxy has a dedicated timeout:

defaults
    timeout http-request 10s
    timeout http-keep-alive 5s

timeout http-request

is the maximum time HAProxy will wait to receive a complete HTTP request after the connection is established. If a client hasn't sent a full request within 10 seconds, the connection is dropped. This kills Slowloris without any stick table involvement. I have seen production configs where this timeout was missing or set to 60s+, and a single low-bandwidth attacker was able to exhaust the frontend's connection slots in minutes.

Step 6: Protect Your Backends with Hard Limits

Even with frontend rate limiting in place, always define hard connection limits on your backend servers. This protects against misconfiguration, a new frontend that bypasses your ACLs, or a sudden traffic spike that your rate limits don't catch in time:

backend be_app
    balance leastconn
    option  httpchk GET /health HTTP/1.1\r\nHost:\ solvethenetwork.com
    http-check expect status 200
    timeout queue 10s

    server app01 10.10.1.20:8080 maxconn 400 check inter 5s fall 3 rise 2
    server app02 10.10.1.21:8080 maxconn 400 check inter 5s fall 3 rise 2
    server app03 10.10.1.22:8080 maxconn 400 check inter 5s fall 3 rise 2

The

maxconn

on each server tells HAProxy to queue excess requests rather than dumping them all onto a backend that can't handle them. Combined with

timeout queue 10s

, requests that wait longer than 10 seconds in the queue get a 503, which is far better than an overloaded backend timing out after 30 seconds.

Full Configuration Example

Here's a complete, production-ready HAProxy configuration for sw-infrarunbook-01 with all the rate limiting and DDoS protection layers assembled:

global
    log         127.0.0.1 local0
    log         127.0.0.1 local1 notice
    maxconn     500000
    user        haproxy
    group       haproxy
    daemon
    stats socket /var/run/haproxy/admin.sock mode 660 level admin expose-fd listeners
    stats timeout 30s
    tune.ssl.default-dh-param 2048

defaults
    log     global
    mode    http
    option  httplog
    option  dontlognull
    option  forwardfor
    option  http-server-close
    timeout connect      5s
    timeout client       30s
    timeout server       30s
    timeout queue        10s
    timeout http-request 10s
    timeout http-keep-alive 5s

#---------------------------------------------------------------------
# HTTPS Frontend with rate limiting and DDoS protection
#---------------------------------------------------------------------
frontend fe_https
    bind 10.10.1.10:443 ssl crt /etc/haproxy/certs/solvethenetwork.com.pem alpn h2,http/1.1

    # Stick table: 200k entries, 60s expiry
    # Counters: concurrent conns, conn rate (10s), HTTP req rate (10s),
    #           HTTP error rate (10s), inbound bytes rate (10s)
    stick-table type ip size 200k expire 60s \
        store conn_cur,conn_rate(10s),http_req_rate(10s),http_err_rate(10s),bytes_in_rate(10s)

    # --- TCP layer: reject floods before TLS handshake ---
    tcp-request connection track-sc0 src
    tcp-request connection reject if { sc_conn_rate(0) gt 100 } \
        !{ src 192.168.100.0/24 10.10.1.0/24 }
    tcp-request connection reject if { sc_conn_cur(0)  gt 200 } \
        !{ src 192.168.100.0/24 10.10.1.0/24 }

    # --- HTTP layer ---
    http-request track-sc0 src

    # Trusted: internal monitoring and management subnets
    acl src_trusted       src 192.168.100.0/24 10.10.1.0/24

    # Rate limit ACLs
    acl abuse_conn_rate   sc_conn_rate(0)      gt 60
    acl abuse_req_rate    sc_http_req_rate(0)  gt 300
    acl abuse_err_rate    sc_http_err_rate(0)  gt 50
    acl abuse_bytes_in    sc_bytes_in_rate(0)  gt 500000

    # Hard deny for volumetric abusers
    http-request deny deny_status 429 if abuse_req_rate  !src_trusted
    http-request deny deny_status 429 if abuse_conn_rate !src_trusted
    http-request deny deny_status 413 if abuse_bytes_in  !src_trusted

    # Tarpit scanners (error-heavy, low request rate)
    http-request tarpit if abuse_err_rate !src_trusted

    # Expose current request rate in response header (useful for debugging)
    http-response set-header X-RateLimit-Req-Rate "%[sc_http_req_rate(0)]"

    # Route API traffic to application backend
    use_backend be_app    if { path_beg /api/ }
    default_backend be_static

#---------------------------------------------------------------------
# HTTP Frontend: redirect to HTTPS only
#---------------------------------------------------------------------
frontend fe_http
    bind 10.10.1.10:80
    redirect scheme https code 301

#---------------------------------------------------------------------
# Backend: Application servers
#---------------------------------------------------------------------
backend be_app
    balance leastconn
    option  httpchk GET /health HTTP/1.1\r\nHost:\ solvethenetwork.com
    http-check expect status 200
    timeout queue 10s

    server app01 10.10.1.20:8080 maxconn 400 check inter 5s fall 3 rise 2
    server app02 10.10.1.21:8080 maxconn 400 check inter 5s fall 3 rise 2
    server app03 10.10.1.22:8080 maxconn 400 check inter 5s fall 3 rise 2

#---------------------------------------------------------------------
# Backend: Static content
#---------------------------------------------------------------------
backend be_static
    balance roundrobin
    option  httpchk GET /ping
    http-check expect status 200

    server static01 10.10.1.20:8081 maxconn 800 check inter 5s fall 3 rise 2
    server static02 10.10.1.21:8081 maxconn 800 check inter 5s fall 3 rise 2

#---------------------------------------------------------------------
# Stats page: internal access only, never expose publicly
#---------------------------------------------------------------------
listen stats
    bind 127.0.0.1:8404
    stats enable
    stats uri /stats
    stats refresh 10s
    stats auth infrarunbook-admin:StrongPassHere
    stats show-legends
    stats show-node

A few configuration decisions worth explaining. The

option http-server-close

in defaults tells HAProxy to close the connection to the backend after each request even if the client wants keep-alive. This forces connection reuse through HAProxy itself rather than pinning backend connections open, which matters a lot under load. Combined with

balance leastconn

on the app backend, requests get distributed based on actual active connections rather than simple round-robin, which handles workloads where some requests take much longer than others.

The

X-RateLimit-Req-Rate

response header is something I add to every rate-limited frontend. It lets your application developers see how close they are to the limit in real time from their curl output or browser dev tools, which saves a lot of "why am I getting 429s" support tickets.

Verification Steps

After reloading with

systemctl reload haproxy

, verify everything actually works. Don't skip this. A clean reload with no config errors does not mean your ACL logic is correct.

First, confirm your stick table exists and is tracking entries:

echo "show table fe_https" | socat stdio /var/run/haproxy/admin.sock

Initially this returns nothing — entries appear only after connections are tracked. Hit your frontend from a workstation, then run it again. You should see output like:

# table: fe_https, type: ip, size:204800, used:1
0x55a4b2c3d180: key=10.10.1.50 use=0 exp=59812 shard=0 conn_cur=0 \
    conn_rate(10000)=2 http_req_rate(10000)=6 http_err_rate(10000)=0 \
    bytes_in_rate(10000)=4096

To test that rate limiting actually fires, use

ab

(Apache Bench) from a test machine on the same network. Send a burst of requests and confirm you start receiving 429 responses:

ab -n 600 -c 30 https://solvethenetwork.com/api/test
# Watch for non-2xx responses in the output — you should see 429s appearing
# after the first ~300 requests cross the threshold

Then check your HAProxy logs on sw-infrarunbook-01. Denied requests look like this:

Apr 12 14:32:01 sw-infrarunbook-01 haproxy[12483]: 10.10.1.50:54321 \
    [12/Apr/2026:14:32:01.043] fe_https be_app/app01 \
    0/0/0/1/1 429 212 - - ---- 241/241/0/0/0 0/0 "GET /api/test HTTP/1.1"

The

429

in the status field confirms the deny rule is firing. If you want to confirm which specific ACL matched, temporarily add

http-request capture req.hdr(User-Agent) len 100

to your frontend and review the capture output in logs — it won't tell you the ACL name directly, but combined with the status code and timing it's usually obvious.

To verify TCP-layer protection specifically, you can simulate a connection rate spike using

hping3

from a test machine:

hping3 -S -p 443 --flood 10.10.1.10
# On the HAProxy host, watch:
watch -n1 "echo 'show table fe_https' | socat stdio /var/run/haproxy/admin.sock"

You should see the source IP's

conn_rate

counter climb rapidly and then new connections from that IP start getting rejected. The stick table output updates in real time, which makes it an excellent live debugging tool during an actual incident.

Finally, pull up the stats page by SSH-tunneling to sw-infrarunbook-01 and opening

http://127.0.0.1:8404/stats

in your browser. The "Sessions" column showing queued requests is your early warning for backend saturation. The "Denied" counter on your frontend climbs when rate limiting is active — if it's climbing during normal business hours, your thresholds might be too aggressive.

Common Mistakes

The most common mistake I see is forgetting to whitelist monitoring and internal subnets before deploying. Your uptime monitoring service hits the frontend constantly. If its source IP crosses the request rate threshold, HAProxy starts returning 429s, your monitoring alerts fire, and you spend an hour debugging what looks like a service outage but is just your own prober getting rate limited. Add your monitoring subnets to the trusted ACL before you go live, and test the whitelist explicitly.

The second mistake is mismatching expiry and rate windows. If your stick table has

expire 5s

but you're tracking

http_req_rate(30s)

, entries expire before the rate window closes. The counter resets and the rate limit never fires. Make your expiry at least 2x your longest rate window. I use

expire 60s

as a default for any table tracking 10s windows — it gives enough buffer without holding memory longer than needed.

Third: not accounting for NAT. If a significant portion of your users sit behind corporate NAT or a mobile carrier's large-scale NAT, all their traffic appears as one or a few source IPs. A strict per-IP request rate limit will block an entire company's worth of legitimate users. I usually set IP-level limits conservatively high for this reason and rely on application-layer controls for tighter enforcement where I have session context to work with.

Fourth: confusing tarpit and deny semantics. A tarpit accepts the TCP connection but never responds, holding the attacker's socket open until it times out. This ties up a connection slot on your side too. Against a high-volume flood, tarpitting can actually hurt you by exhausting your own connection table. Use tarpit for low-rate scanners where you want to waste their resources; use hard deny for high-rate floods where speed of rejection matters.

Fifth: leaving the admin socket over-permissioned or the stats page on a public interface. The admin socket at

/var/run/haproxy/admin.sock

can drain servers, change weights, and clear stick tables. Keep it mode 660, owned by the haproxy group, and never let untrusted processes near it. The stats page in this config binds to

127.0.0.1:8404

specifically — never bind it to a public interface, regardless of password protection.

One final thing worth being direct about: HAProxy rate limiting is not a substitute for upstream DDoS mitigation when the attack is volumetric. If an attacker is sending 20 Gbps at your network pipe, HAProxy never sees the packets — your upstream provider's links fill up first. HAProxy's rate limiting is excellent for application-layer attacks: HTTP floods, credential stuffing, scanner bots, API key abuse, scraping. For volumetric L3/L4 floods, you need BGP blackholing or a scrubbing center upstream. The right architecture uses both layers together — upstream mitigation for volume, HAProxy for application-layer precision.

---

Related Articles

• [HAProxy] HAProxy Stick Tables: Rate Limiting, Connection Tracking, and DDoS Mitigation
• [HAProxy] HAProxy Connection Limits Reached
• [Nginx] Nginx Rate Limiting: limit_req, limit_conn, Burst Control, and DDoS Mitigation
• [HAProxy] HAProxy SSL Termination Issues
