HAProxy Stick Tables: Rate Limiting, Connection Tracking, and DDoS Mitigation

Introduction

HAProxy stick tables are one of the most powerful yet under-utilised features in the HAProxy ecosystem. They provide an in-memory key-value store that tracks connection metadata in real time — enabling you to implement rate limiting, connection throttling, abuse detection, and full DDoS mitigation without any external dependencies. Unlike tools that rely on external databases or third-party WAFs, stick tables operate entirely within HAProxy's event loop, adding near-zero latency to request processing.

This run book covers everything from basic stick table anatomy to advanced multi-layered defence patterns. Every configuration is production-tested and ready to deploy.

---

1. Stick Table Fundamentals

1.1 What Is a Stick Table?

A stick table is a fixed-size in-memory hash table attached to a frontend or backend. Each entry is keyed by a data type (IP address, integer, string, or binary) and can store multiple counters simultaneously. HAProxy updates these counters automatically as traffic flows through.

1.2 Core Syntax

backend st_src_tracking
    stick-table type ip size 1m expire 10m nopurge peers mypeers store http_req_rate(10s),conn_cur,conn_rate(10s),gpc0,gpc0_rate(60s),bytes_out_rate(60s)

Let's break down each parameter:

• type ip — Key type. Options:

  ip

  ,

  ipv6

  ,

  integer

  ,

  string len <n>

  ,

  binary len <n>

  .
• size 1m — Maximum number of entries (1 million). Memory usage depends on counters stored.
• expire 10m — Entries are evicted after 10 minutes of inactivity.
• nopurge — Prevents purging of entries when the table is full; new entries are rejected instead. Omit this for automatic LRU eviction.
• peers mypeers — Enables stick table replication (covered in section 6).
• store — Comma-separated list of counters to track.

1.3 Available Counters

The following counters can be stored in a stick table:

• conn_cnt — Total number of connections since entry creation.
• conn_cur — Current concurrent connections.
• conn_rate(<period>) — Connection rate over the specified period.
• http_req_cnt — Total HTTP requests.
• http_req_rate(<period>) — HTTP request rate over the specified period.
• http_err_cnt — Total HTTP errors (4xx/5xx from backend).
• http_err_rate(<period>) — HTTP error rate.
• http_fail_cnt — Total HTTP failures.
• http_fail_rate(<period>) — HTTP failure rate.
• bytes_in_cnt — Total bytes received from client.
• bytes_in_rate(<period>) — Bytes received rate.
• bytes_out_cnt — Total bytes sent to client.
• bytes_out_rate(<period>) — Bytes sent rate.
• gpc0 / gpc1 — General purpose counters (manually incremented).
• gpc0_rate(<period>) / gpc1_rate(<period>) — Rate of GPC increments.
• server_id — Last server ID used (for session persistence).

---

2. Tracking Connections with Sticky Counters

2.1 Understanding Sticky Counters (sc0, sc1, sc2)

HAProxy provides three sticky counter slots per connection:

sc0

,

sc1

, and

sc2

. Each slot binds the current connection to one stick table entry. You can track three different dimensions simultaneously — for example, source IP in sc0, a URL path in sc1, and an API key header in sc2.

2.2 TCP-Level Tracking

Track the source IP as soon as the TCP connection is established:

frontend ft_web
    bind *:80
    bind *:443 ssl crt /etc/haproxy/certs/site.pem

    # Track source IP at TCP layer using sc0
    tcp-request connection track-sc0 src table st_src_tracking

    # Reject if too many concurrent connections from one IP
    tcp-request connection reject if { src_conn_cur(st_src_tracking) gt 50 }

    default_backend bk_web

backend st_src_tracking
    stick-table type ip size 500k expire 5m store conn_cur,conn_rate(10s),http_req_rate(10s),http_err_rate(10s)

2.3 HTTP-Level Tracking

Track at the HTTP layer for finer-grained control:

frontend ft_web
    bind *:443 ssl crt /etc/haproxy/certs/site.pem

    tcp-request connection track-sc0 src table st_src_tracking

    # Track at HTTP layer — needed for http_req_rate counters
    http-request track-sc1 src table st_http_tracking

    # Rate limit based on HTTP request rate
    http-request deny deny_status 429 if { sc_http_req_rate(1) gt 100 }

    default_backend bk_web

backend st_src_tracking
    stick-table type ip size 500k expire 5m store conn_cur,conn_rate(10s)

backend st_http_tracking
    stick-table type ip size 500k expire 5m store http_req_rate(10s),http_err_rate(10s)

Key insight:

conn_rate

and

conn_cur

are updated at the TCP layer.

http_req_rate

,

http_err_rate

, and related HTTP counters require the request to be parsed, so tracking must happen via

http-request track-sc

or at minimum after the TCP content inspection phase.

---

3. Rate Limiting Patterns

3.1 Basic Request Rate Limiting

Deny any source IP making more than 60 requests in 10 seconds:

frontend ft_api
    bind *:443 ssl crt /etc/haproxy/certs/api.pem

    # Whitelist internal monitoring
    acl is_monitor src 10.0.0.0/8 172.16.0.0/12

    http-request track-sc0 src table st_api_rate
    http-request deny deny_status 429 if !is_monitor { sc_http_req_rate(0) gt 60 }

    # Return a Retry-After header on 429
    http-response set-header Retry-After 10 if { status 429 }

    default_backend bk_api

backend st_api_rate
    stick-table type ip size 200k expire 2m store http_req_rate(10s)

3.2 Tiered Rate Limiting (Soft + Hard)

Apply a soft limit (delay via tarpit) before a hard deny:

frontend ft_api
    bind *:443 ssl crt /etc/haproxy/certs/api.pem

    http-request track-sc0 src table st_tiered_rate

    # Hard limit: 200 req/10s → deny
    acl is_hard_abuse sc_http_req_rate(0) gt 200
    http-request deny deny_status 429 if is_hard_abuse

    # Soft limit: 100 req/10s → tarpit for 5s (holds connection open)
    acl is_soft_abuse sc_http_req_rate(0) gt 100
    http-request tarpit deny_status 429 if is_soft_abuse

    timeout tarpit 5s

    default_backend bk_api

backend st_tiered_rate
    stick-table type ip size 200k expire 2m store http_req_rate(10s)

Note: Tarpit holds the connection open silently, consuming attacker resources. The response is only sent after the

timeout tarpit

period.

3.3 Per-URL Rate Limiting

Rate-limit expensive endpoints like login or search independently:

frontend ft_web
    bind *:443 ssl crt /etc/haproxy/certs/site.pem

    # General tracking
    http-request track-sc0 src table st_global_rate

    # Track login endpoint separately — combine IP + path as key
    acl is_login path_beg /api/login
    http-request track-sc1 src table st_login_rate if is_login

    # Global: 200 req/10s
    http-request deny deny_status 429 if { sc_http_req_rate(0) gt 200 }

    # Login: 10 req/60s
    http-request deny deny_status 429 if is_login { sc_http_req_rate(1) gt 10 }

    default_backend bk_web

backend st_global_rate
    stick-table type ip size 500k expire 2m store http_req_rate(10s)

backend st_login_rate
    stick-table type ip size 200k expire 5m store http_req_rate(60s)

3.4 Rate Limiting by API Key

Track by a custom header instead of IP:

frontend ft_api
    bind *:443 ssl crt /etc/haproxy/certs/api.pem

    http-request track-sc0 req.hdr(X-API-Key) table st_apikey_rate if { req.hdr(X-API-Key) -m found }

    # Fallback: track by IP if no API key
    http-request track-sc1 src table st_ip_rate unless { req.hdr(X-API-Key) -m found }

    # API key limit: 1000 req/60s
    http-request deny deny_status 429 if { sc_http_req_rate(0) gt 1000 }

    # IP fallback limit: 30 req/60s
    http-request deny deny_status 429 if { sc_http_req_rate(1) gt 30 }

    default_backend bk_api

backend st_apikey_rate
    stick-table type string len 64 size 100k expire 5m store http_req_rate(60s)

backend st_ip_rate
    stick-table type ip size 200k expire 5m store http_req_rate(60s)

---

4. Connection Tracking and Abuse Detection

4.1 Slowloris / Slow Connection Detection

Detect and reject slow clients that open many connections but send data slowly:

frontend ft_web
    bind *:443 ssl crt /etc/haproxy/certs/site.pem

    tcp-request connection track-sc0 src table st_slowloris

    # More than 20 concurrent connections from a single IP
    tcp-request connection reject if { src_conn_cur(st_slowloris) gt 20 }

    # More than 40 new connections in 10 seconds
    tcp-request connection reject if { src_conn_rate(st_slowloris) gt 40 }

    # Aggressive timeouts to kill slow clients
    timeout client 15s
    timeout http-request 5s
    timeout http-keep-alive 5s

    default_backend bk_web

backend st_slowloris
    stick-table type ip size 500k expire 2m store conn_cur,conn_rate(10s)

4.2 Error Rate Monitoring (Credential Stuffing Detection)

Detect IPs generating a high rate of HTTP errors (failed logins return 401/403):

frontend ft_web
    bind *:443 ssl crt /etc/haproxy/certs/site.pem

    http-request track-sc0 src table st_error_tracking

    # Block if more than 30 errors in 60 seconds
    acl is_bruteforce sc_http_err_rate(0) gt 30
    http-request deny deny_status 403 if is_bruteforce

    default_backend bk_web

backend st_error_tracking
    stick-table type ip size 200k expire 10m store http_err_rate(60s),http_err_cnt

4.3 Using General Purpose Counters (GPC) for Flagging

GPC counters let you "flag" an IP for custom conditions. For example, flag an IP as abusive and block it for a period:

frontend ft_web
    bind *:443 ssl crt /etc/haproxy/certs/site.pem

    http-request track-sc0 src table st_gpc_flag

    # If already flagged, deny immediately
    http-request deny deny_status 403 if { src_get_gpc0(st_gpc_flag) gt 0 }

    # Flag if request rate exceeds 150/10s
    acl is_abusive sc_http_req_rate(0) gt 150
    http-request sc-set-gpt0(0) 1 if is_abusive
    http-request sc-inc-gpc0(0) if is_abusive

    default_backend bk_web

backend st_gpc_flag
    stick-table type ip size 200k expire 30m store http_req_rate(10s),gpc0,gpc0_rate(60s)

Once flagged, the IP is denied for the full 30-minute expiry window, even if the request rate drops. This is useful for blacklisting repeat offenders longer than the initial burst.

---

5. DDoS Mitigation Strategy

5.1 Multi-Layer Defence Configuration

A comprehensive DDoS mitigation setup combines TCP-level and HTTP-level protections:

# ===========================================
# Global settings
# ===========================================
global
    log /dev/log local0 info
    log /dev/log local1 notice
    maxconn 100000
    tune.ssl.default-dh-param 2048
    stats socket /run/haproxy/admin.sock mode 660 level admin
    stats timeout 30s

# ===========================================
# Defaults
# ===========================================
defaults
    log     global
    mode    http
    option  httplog
    option  dontlognull
    timeout connect 5s
    timeout client  15s
    timeout server  15s
    timeout http-request 5s
    timeout http-keep-alive 5s
    timeout queue 30s
    timeout tarpit 5s

# ===========================================
# Stick tables (dedicated backends)
# ===========================================
backend st_tcp_conntrack
    stick-table type ip size 1m expire 5m store conn_cur,conn_rate(5s)

backend st_http_ratelimit
    stick-table type ip size 1m expire 5m store http_req_rate(10s),http_err_rate(60s)

backend st_http_abuse
    stick-table type ip size 500k expire 60m store gpc0,http_req_cnt

# ===========================================
# Frontend: DDoS-hardened
# ===========================================
frontend ft_https
    bind *:443 ssl crt /etc/haproxy/certs/site.pem alpn h2,http/1.1
    bind *:80
    redirect scheme https code 301 unless { ssl_fc }

    # ---- Whitelist trusted sources ----
    acl is_trusted src 10.0.0.0/8 172.16.0.0/12 192.168.0.0/16
    acl is_healthcheck path /health

    # ---- Layer 4: Connection tracking ----
    tcp-request connection track-sc0 src table st_tcp_conntrack
    tcp-request connection reject if !is_trusted { src_conn_cur(st_tcp_conntrack) gt 80 }
    tcp-request connection reject if !is_trusted { src_conn_rate(st_tcp_conntrack) gt 60 }

    # ---- Layer 7: HTTP rate tracking ----
    http-request track-sc1 src table st_http_ratelimit
    http-request track-sc2 src table st_http_abuse

    # ---- Check if already flagged as abusive ----
    acl is_flagged src_get_gpc0(st_http_abuse) gt 0
    http-request deny deny_status 403 if is_flagged !is_trusted !is_healthcheck

    # ---- Hard deny: >300 req/10s ----
    acl is_flood sc_http_req_rate(1) gt 300
    http-request deny deny_status 429 if is_flood !is_trusted

    # ---- Flag abusers: >500 req/10s → flagged for 60 minutes ----
    acl is_severe_flood sc_http_req_rate(1) gt 500
    http-request sc-inc-gpc0(2) if is_severe_flood !is_trusted

    # ---- Tarpit: 150-300 req/10s ----
    acl is_suspicious sc_http_req_rate(1) gt 150
    http-request tarpit deny_status 429 if is_suspicious !is_flood !is_trusted

    # ---- Error rate abuse: >50 errors/60s ----
    acl is_error_abuse sc_http_err_rate(1) gt 50
    http-request deny deny_status 403 if is_error_abuse !is_trusted

    # ---- Custom 429 response header ----
    http-response set-header Retry-After 30 if { status 429 }

    # ---- Logging tagged connections ----
    http-request set-header X-RateLimit-Remaining %[sc_http_req_rate(1)]
    http-request add-header X-Flagged true if is_flagged

    default_backend bk_web

# ===========================================
# Backend
# ===========================================
backend bk_web
    balance roundrobin
    option httpchk GET /health HTTP/1.1\r\nHost:\ localhost
    http-check expect status 200
    server web1 10.0.1.10:8080 check inter 3s fall 3 rise 2
    server web2 10.0.1.11:8080 check inter 3s fall 3 rise 2
    server web3 10.0.1.12:8080 check inter 3s fall 3 rise 2

5.2 Explanation of Defence Layers

1. Layer 4 — Connection Limiting: Drops TCP connections from IPs with >80 concurrent or >60 new connections in 5 seconds. Stops SYN floods before HTTP parsing.
2. Layer 7 — Soft Tarpit: IPs sending 150–300 req/10s are tarpitted for 5 seconds per request, wasting attacker resources.
3. Layer 7 — Hard Deny: IPs exceeding 300 req/10s receive an immediate 429.
4. Layer 7 — Flagging: IPs exceeding 500 req/10s are flagged via GPC0, blocking them for 60 minutes even if the attack stops.
5. Error Rate: IPs generating >50 backend errors/minute are blocked (catches credential stuffing and fuzzing).

---

6. Stick Table Replication with Peers

For high-availability setups, stick tables must be synchronised across HAProxy instances:

peers mypeers
    peer haproxy1 10.0.1.1:1024
    peer haproxy2 10.0.1.2:1024

backend st_src_tracking
    stick-table type ip size 1m expire 5m peers mypeers store conn_cur,conn_rate(10s),http_req_rate(10s),gpc0

Key notes on peer replication:

• Each HAProxy instance must have a

  peer

  entry matching its own hostname (the hostname must match

  hostname

  output or be set explicitly).
• Port 1024 (or any chosen port) must be open between peers — ensure firewall rules allow it.
• Replication is asynchronous; there is a brief window where one node may not have the latest counters.
• Use

  bind-process

  if using multi-process mode to ensure the peers section runs on the correct process.

# Verify peers are connected via the stats socket
echo "show peers" | socat stdio /run/haproxy/admin.sock

---

7. Monitoring and Managing Stick Tables

7.1 Runtime API Commands

HAProxy's runtime API (via the stats socket) provides powerful stick table management:

# Show all stick tables and their sizes
echo "show table" | socat stdio /run/haproxy/admin.sock

# Show contents of a specific table
echo "show table st_http_ratelimit" | socat stdio /run/haproxy/admin.sock

# Show a specific entry
echo "show table st_http_ratelimit data.http_req_rate gt 50" | socat stdio /run/haproxy/admin.sock

# Manually set gpc0 to flag an IP
echo "set table st_http_abuse key 203.0.113.50 data.gpc0 1" | socat stdio /run/haproxy/admin.sock

# Clear a specific entry (unblock an IP)
echo "clear table st_http_abuse key 203.0.113.50" | socat stdio /run/haproxy/admin.sock

# Clear all entries in a table
echo "clear table st_http_ratelimit" | socat stdio /run/haproxy/admin.sock

7.2 Exporting Stick Table Data for Monitoring

Create a script that exports top offenders to your monitoring system:

#!/bin/bash
# /usr/local/bin/haproxy-top-offenders.sh
# Export top IPs by request rate to a file for Prometheus/Grafana

SOCKET="/run/haproxy/admin.sock"
TABLE="st_http_ratelimit"
THRESHOLD=50
OUTPUT="/var/log/haproxy/top_offenders.log"

echo "show table ${TABLE} data.http_req_rate gt ${THRESHOLD}" \
  | socat stdio "${SOCKET}" \
  | awk 'NR>1 {print strftime("%Y-%m-%d %H:%M:%S"), $0}' \
  >> "${OUTPUT}"

# Optional: send to syslog
logger -t haproxy-ratelimit -p local0.warning "$(wc -l < ${OUTPUT}) IPs above threshold ${THRESHOLD}"

7.3 Stats Page Integration

Enable the stats page to visually inspect table sizes:

frontend ft_stats
    bind 127.0.0.1:8404
    mode http
    stats enable
    stats uri /stats
    stats refresh 5s
    stats show-legends
    stats show-node
    stats admin if TRUE

---

8. Memory Sizing Guide

Stick table memory usage depends on the key type and stored counters. Use this formula to estimate:

Memory ≈ entries × (key_size + 40 bytes base + Σ counter_sizes)

Approximate counter sizes:

• Each simple counter (conn_cnt, http_req_cnt, gpc0, etc.): ~8 bytes
• Each rate counter (conn_rate, http_req_rate, etc.): ~16 bytes
• IP key: 4 bytes (IPv4) or 16 bytes (IPv6)
• String key: len + 4 bytes

Example calculation for 1M entries with IPv4 key storing

conn_cur,conn_rate(10s),http_req_rate(10s),gpc0

:

Per entry = 4 (key) + 40 (base) + 8 (conn_cur) + 16 (conn_rate) + 16 (http_req_rate) + 8 (gpc0) = 92 bytes
Total = 1,000,000 × 92 = ~88 MB

Ensure your HAProxy instance has sufficient RAM. Set

global

maxconn

and OS-level limits accordingly.

---

9. Testing Your Configuration

9.1 Validate Configuration Syntax

haproxy -c -f /etc/haproxy/haproxy.cfg

9.2 Simulate Load with curl

# Quick burst test — send 200 requests rapidly
for i in $(seq 1 200); do
    curl -s -o /dev/null -w "%{http_code}\n" https://example.com/api/test
done | sort | uniq -c | sort -rn

9.3 Load Test with hey (recommended)

# Install hey
go install github.com/rakyll/hey@latest

# Send 500 requests, 50 concurrent
hey -n 500 -c 50 https://example.com/api/test

# Check stick table after test
echo "show table st_http_ratelimit" | socat stdio /run/haproxy/admin.sock

9.4 Test from Multiple IPs

# Use different source IPs via network namespaces (Linux)
for ip in 192.168.100.{10..15}; do
    ip addr add ${ip}/24 dev eth0 2>/dev/null
    curl --interface ${ip} -s -o /dev/null -w "${ip}: %{http_code}\n" https://example.com/
    ip addr del ${ip}/24 dev eth0 2>/dev/null
done

---

10. Production Best Practices

• Always whitelist monitoring and internal IPs — Use ACLs to bypass rate limiting for health checks, Prometheus scrapers, and internal services.
• Start with soft limits — Deploy with logging only (no deny) first. Analyse the data before enforcing blocks.
• Use separate tables for separate concerns — Don't cram all counters into one table. Use dedicated tables for TCP tracking, HTTP rate limiting, and abuse flagging.
• Set appropriate expire times — Short expiry (2-5 min) for rate tables, longer expiry (30-60 min) for abuse flag tables.
• Monitor table utilisation — Alert when a table reaches 80% capacity. An eviction storm can cause legitimate entries to be lost.
• Log denied requests — Add

  http-request capture

  and custom log-format to track denials for forensics.
• Test replication — In HA setups, regularly verify peers are synced and tables are consistent.
• Document your thresholds — Keep a run book of each threshold, why it was chosen, and when it was last reviewed.

# Custom log format that includes stick table counters
log-format "%ci:%cp [%tr] %ft %b/%s %TR/%Tw/%Tc/%Tr/%Ta %ST %B %CC %CS %tsc %ac/%fc/%bc/%sc/%rc %sq/%bq %hr %hs {%[sc_http_req_rate(1)]|%[src_conn_cur]} %{+Q}r"

---

11. Troubleshooting Common Issues

Issue: Stick table counters always show 0

Cause: The

track-sc

directive is placed after the

deny

rule, so the counter is never incremented.

Fix: Always place

track-sc

directives before any deny/tarpit rules.

Issue: Rate limiting doesn't work on HTTP/2 connections

Cause: HTTP/2 multiplexes many requests over a single TCP connection.

conn_rate

only counts new TCP connections.

Fix: Use

http_req_rate

instead of

conn_rate

for HTTP/2 environments.

Issue: Legitimate users behind NAT are being blocked

Cause: Many users share a single source IP. IP-based tracking can cause collateral blocking.

Fix: Use a combination of IP + header (e.g.,

X-Forwarded-For

, session cookie, or API key) as the stick table key, or increase thresholds for known NAT ranges.

# Track by X-Forwarded-For if present, otherwise by src
acl has_xff req.hdr(X-Forwarded-For) -m found
http-request track-sc0 req.hdr_ip(X-Forwarded-For) table st_rate if has_xff
http-request track-sc0 src table st_rate unless has_xff

Issue: Table fills up and entries are not evicted

Cause:

nopurge

is set and the table has reached

size

.

Fix: Remove

nopurge

to allow LRU eviction, or increase the table size.
